MAIN LINE BETWEEN TCM AND LASER CIRCUITLAN-63
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN TC
M AND LASER CIRCUIT
Diagnosis ProcedureINFOID:0000000001282441
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector F14
- Harness connector E5
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
- A/T assembly
- Harness connectors F14 and E5
2. Check the continuity between the A/T asse mbly harness connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the A/T assembly and the harness connector F14.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of ICC sensor.
2. Check the continuity between the harness connector and the ICC sensor harness connector.
Is the inspection result normal?
YES (Present error)>>Check the following items again. • Decision of CAN system type.
• Not received CONSULT-III data [SELF-DIAG RESULTS, CAN DIAG SUPPORT MNTR (“ECU
list” included)].
• Procedure for detecting root cause.
YES (Past error)>>Error was detected in the main line between the A/T assembly and the ICC sensor.
NO >> Repair the main line between the harness connector E5 and the ICC sensor.
A/T assembly harness connector Harness connector
Continuity
Connector No. Terminal No.Connector No. Terminal No.
F9 3
F14 5
Existed
8 15Existed
Harness connector ICC sensor harness connector
Continuity
Connector No. Terminal No.Connector No. Terminal No.
E5 5
E42 2
Existed
15 3Existed
Revision: March 2010 2008 QX56

LAN-64
< COMPONENT DIAGNOSIS >[CAN]
MAIN LINE BETWEEN LASER AND ICC CIRCUIT
MAIN LINE BETWEEN LA
SER AND ICC CIRCUIT
Diagnosis ProcedureINFOID:0000000001282444
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side and harness side).
- Harness connector E34
- Harness connector B40
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
- ICC sensor
- Harness connectors E34 and B40
2. Check the continuity between the ICC sens or harness connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the ICC sensor and the harness connector E34.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of ICC unit.
2. Check the continuity between the harness connector and the ICC unit harness connector.
Is the inspection result normal?
YES (Present error)>>Check the following items again. • Decision of CAN system type.
• Not received CONSULT-III data [SELF-DIAG RESULTS, CAN DIAG SUPPORT MNTR (“ECUlist” included)].
• Procedure for detecting root cause.
YES (Past error)>>Error was detected in the ma in line between the ICC sensor and the ICC unit.
NO >> Repair the main line between the harness connector B40 and the ICC unit.
ICC sensor harness connector Harness connector
Continuity
Connector No. Terminal No.Connector No. Terminal No.
E42 2
E34 24
Existed
3 23Existed
Harness connector ICC unit harness connector
Continuity
Connector No. Terminal No.Connector No. Terminal No.
B40 24
B13 14
Existed
23 5Existed
Revision: March 2010 2008 QX56

LAN
TCM BRANCH LINE CIRCUITLAN-71
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001282417
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the A/T assembly for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of A/T assembly.
2. Check the resistance between the A/T assembly harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the TCM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the TCM. Refer to TM-92, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the control valve with TCM. Refer to TM-201, "Control Valve with TCM and A/
T Fluid Temperature Sensor 2".
YES (Past error)>>Error was detected in the TCM branch line.
NO >> Repair the power supply and the ground circuit.
A/T assembly harness connector Resistance (Ω)
Connector No. Terminal No.
F9 3 8 Approx. 54 – 66
Revision: March 2010 2008 QX56

LAN-72
< COMPONENT DIAGNOSIS >[CAN]
LASER BRANCH LINE CIRCUIT
LASER BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001282449
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the ICC s ensor for damage, bend and loose connection (unit side
and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ICC sensor.
2. Check the resistance between the ICC sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the ICC sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the ICC sensor. Refer to CCS-47, "
Wiring Diagram".
Is the inspection result normal?
YES (Present error)>>Replace the ICC sensor. Refer to CCS-71, "ICC Sensor".
YES (Past error)>>Error was detect ed in the ICC sensor branch line.
NO >> Repair the power supply and the ground circuit.
ICC sensor harness connector Resistance (Ω)
Connector No. Terminal No.
E42 23Approx. 54 – 66
Revision: March 2010 2008 QX56

LAN
STRG BRANCH LINE CIRCUITLAN-81
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
STRG BRANCH
LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001282426
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the steer ing angle sensor for damage, bend and loose connection
(unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of steering angle sensor.
2. Check the resistance between the steering angle sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the steering angle sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the steering angle sensor. Refer to BRC-61, "
Diagnosis Pro-
cedure".
Is the inspection result normal?
YES (Present error)>>Replace the steering angle sensor. Refer to BRC-118, "Removal and Installation".
YES (Past error)>>Error was detected in the steering angle sensor branch line.
NO >> Repair the power supply and the ground circuit.
Steering angle sensor harness connector Resistance (Ω)
Connector No. Terminal No.
M17 4 5 Approx. 54 – 66
Revision: March 2010 2008 QX56
