5. Assemble the jack and tools as follows:
Front Tire Flat:If the at tire is on a front tire of
the vehicle, you will need to use the jack handle and
both jack handle extensions. Attach the wheel
wrench to the jack handle extensions. Attach the
jack handle to the jack. From the front of the vehicle
position the jack on the front lower control arm
along the bar that runs front to back. Turn the wheel
wrench clockwise to raise the vehicle. Raise the
vehicle far enough off the ground so there is enough
room for the spare tire to clear the ground.Refer to the graphic above to locate the placement
of the jack if the at tire is on the rear of the
vehicle. Front Position
Rear Positions
5-85

Rear Tire Flat:You will need to use the jack
handle and both jack handle extensions. Attach the
wheel wrench to the jack extensions. Attach the
jack handle to the jack. From the rear of the vehicle
align the jack under the rear axle. Turn the wheel
wrench clockwise to raise the vehicle. Raise
the vehicle far enough off the ground so there is
enough room for the spare tire to clear the ground.6. Turn the wheel wrench clockwise to raise the jack
head to the lifting point.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get
under a vehicle when it is supported only by
a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
5-86

11. Tighten each wheel nut by hand. Then use the
wheel wrench to tighten the nuts until the wheel
is held against the hub.
12. Turn the wheel wrench counterclockwise to lower
the vehicle. Lower the jack completely.
{CAUTION:
Incorrect or improperly tightened wheel nuts
can cause the wheel to come loose and even
come off. This could lead to a crash. If you
have to replace them, be sure to get new
original equipment wheel nuts. Stop
somewhere as soon as you can and have the
nuts tightened with a torque wrench to the
proper torque specication. SeeCapacities
and Specifications on page 5-107for wheel nut
torque specication.Notice:Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specication. SeeCapacities and
Specifications on page 5-107for the wheel nut
torque specication.
13. Tighten the nuts rmly
in a crisscross
sequence as shown by
turning the wheel
wrench clockwise.
14. After installing the wheel and tire, you must reinstall
the center cap. Place the cap on the wheel and tap
it into place until it sits ush with the wheel.
5-88

5. Reinstall the center tire cover onto the spare or
at tire.
6. If your vehicle has a spare tire cover close the
cover and latch the side latch.
To store the jack tool bag and jack:
1. Return the tools to the jack tool bag.
2. Secure the tool bag to the jack by securely wrapping
the straps around the jack. Then, slide the straps
through the rings on the bag and secure.
3. Position the jack and jack tool bag in the
swing-gate.
When reinstalling the jack and jack tool bag, make
sure the jack base is securely seated behind
the tabs in the swing-gate.4. Reinstall the wing nut retainer to fasten the jack
and tool bag in the storage compartment.
Make sure that the wing nut passes through the tool
bag and the jack before you tighten it.
5. Turn the wing nut retainer clockwise to secure.
6. Reinstall the compartment cover by inserting
the locator tabs in the holes in the swing-gate.
Push the latches down to secure.
5-90
