2008 HONDA CR-V TPMS

To saf ely operate your vehicle, your
tires must be the proper type and
size, in good condition with adequate
tread, and correctly inf lated.
The f ollowing pages give more
detailed inf ormation on how to take
care of your tires and what to do
when they need to be replaced.Keeping the tires properly inf lated
provides the best combination of
handling, tread lif e, and riding
comf ort.
Underinf lated tires wear unevenly,
adversely affect handling and fuel
economy, and are more likely to
fail from being overheated.
Overinf lated tires can make your
vehicleridemoreharshly,are
more prone to damage f rom road
hazards, and wear unevenly. The tire pressure monitoring system
(TPMS) warns you when a tire
pressure is low. See page f or
more inf ormation.
Even though your vehicle is
equipped with TPMS, we
recommend that you visually check
your tires every day. If you think a
tire might be low, check it
immediately with a tire gauge.
258
Inf lation Guidelines
Tires
302
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
\f—\f—y


\fy
(,
\fy\f\fy
2008 CR- V

When the tires are rotated, make
sure the air pressures are checked.
To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the information display. Move the
tires to the positions shown in the
diagram each time they are rotated.
If you purchase directional tires,
rotate only front-to-back.Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.
TheABSworksbycomparingthe
speed of the wheels. When replacing
tires, use the same size originally
supplied with the vehicle. Tire size
and construction can affect wheel
speed and may cause the system to
activate.It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
If you ever replace a wheel, make
sure that the wheel’s specif ications
match those of the original wheels.
Also be sure you use only TPMS
specif ic wheels. If you do not, the
tire pressure monitoring system will
notworkonthattire.
Replacement wheels are available at
your dealer.
T ire Rotation Replacing T ires and Wheels
Tires
306
Front Front
(For Non-directional
Tires and Wheels) (For Directional
Tires and Wheels)
\f—\f—y

y
(,
\fy\f

y
2008 CR- V

Replace the tire when you can see
the tread wear indicator bars. The
replacement should be the same size
and design tire, mounted on the
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed f or mounting a regular tire.
Do not mount snow chains on the
compact spare tire.
Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.
Check the inf lation pressure of the
compact spare tire every time you
check the other tires. It should be
inf lated to:
Follow these precautions:
Never exceed 50 mph (80 km/h).
This tire gives a harsher ride and
less traction on some road
surf aces. Use greater caution
while driving. Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel.
The low tire pressure indicator
comes on and stays on af ter you
replace the flat tire with the
compact spare tire. Af ter several
miles (kilometers) driving with the
compact spare tire, the TPMS
indicator comes on and the low
tire pressure indicator goes of f .
Compact Spare Tire
312
INDICATOR LOCATION MARK
TREAD WEAR INDICATOR BAR
60 psi (420 kPa , 4.2 kgf/cm)
\f—\f—y

y
(,
\fy\f
y
2008 CR- V

ÎÎ
Î
Î
µ µ
µ
Î
No.
No. Circuits Protected Circuits Protected
Amps. Amps.
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19 TPMS
Headlight Low Beam
Not used
Not used
Moonroof
Door Lock
Front Left Power Window
HAC Option
Rear Accessory Socket
Accessory
Front Right Power Window
Accessory Power Socket on
the Center Table
Rear Right Power Window
Rear Left power window
ACC Radio
ACC Key lock
HAC
Daytime Running Lights
Front Wiper
Power Window Relay
Fuel Pump
ACG
ABS/VSA
Heated Seats
Front Fog Lights
Not used
Rear Wiper
ODS (Occupant Detection
System)
Meter
SRS
Right Headlight High Beam
Left Headlight High Beam
Small Light (Interior)
Small Light (Exterior)
Right Headlight Low Beam
Left Headlight Low Beam
Main Headlight High Beam
Small Lights MAIN
7.5 A
15 A
10 A
7.5 A
(15 A)
(20 A)
10 A
7.5 A
7.5 A 10 A
10 A
10 A
7.5 A
7.5 A 10 A
10 A
20 A
15 A 7.5 A
20 A
(20 A) 20 A
20 A
(20 A) 15 A
15 A
20 A
(15 A)
20 A
20 A
7.5 A
7.5 A 10 A
7.5 A 30 A
: If equipped
Fuse Locations
330
INTERIOR FUSE BOX
\f—\f—y

y
(,
\fy\fy
2008 CR- V

µ
Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.
................
Identif ication Numbers .334
................................
Specif ications .336
DOT Tire Quality Grading
......................
(U.S. Vehicles) .338
Unif orm Tire Quality ..................................
Grading .338
.................................
Treadwear .338
......................................
Traction .338
.............................
Temperature .339
.................................
Tire Labeling .340
Tire Pressure Monitoring System
(TPMS) Required Federal ............................
Explanation .342 .......................
Emissions Controls .344
.....................
The Clean Air Act .344
Crankcase Emissions Control
....................................
System .344
Evaporative Emissions Control ....................................
System .344
Onboard Ref ueling Vapor ................................
Recovery .344
...
Exhaust Emissions Controls .345
....................
PGM-FI System .345
Ignition Timing Control
................................
System .345
Exhaust Gas Recirculation ...................
(EGR) System .345
Three Way Catalytic ...........................
Converter .345
....................
Replacement Parts .345
..
Three Way Catalytic Converter .346
........................
Emissions Testing .347
T echnical Inf ormation
Technical Inf ormation
333
\f—\f—y

\fy
(,
\fy\fy
2008 CR- V

µ
Each tire, including the spare (if
provided), should be checked
monthly when cold and inf lated to
the inf lation pressure recommended
by the vehicle manuf acturer on the
vehicle placard or tire inf lation
pressure label.
(If your vehicle has tires of a
dif f erent size than the size indicated
on the vehicle placard or tire
inf lation pressure label, you should
determine the proper tire inf lation
pressure f or those tires.)Accordingly, when the low tire
pressure telltale illuminates, you
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure.Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Please note that the TPMS is not a
substitute for proper tire
maintenance, and it is the driver’s
responsibility to maintain correct tire
pressure, even if under-inf lation has
not reached the level to trigger
illumination of the TPMS low tire
pressure telltale.
As an added safety feature, your
vehicle has been equipped with a tire
pressure monitoring system (TPMS)
that illuminates a low tire pressure
telltale
when one or more of your tires is
signif icantly under-inf lated.
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
342
\f—\f—y
\fy
(,
\fy\fy
2008 CR- V

µ
Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is provided by
a separate telltale, which displays the
symbol ‘‘TPMS’’ when illuminated.
When the malf unction indicator is
illuminated,
the system may not be able to detect
or signal low tire pressure as
intended.
TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly.
Tire Pressure Monitoring System (TPMS) Required Federal Explanation
Technical Inf ormation
343
\f—\f—y
\fy
(,
\fy\fy
2008 CR- V

CONT INUED
..................................................
Keys .79
Indicators
......
ABS (Anti-Lock Brake) .61,254
Brake (Parking and Brake
............................
System) .60,326
................
Charging System .60,324
.............................
Cruise Control .62
DRL (Daytime Running
......................................
Lights) .63
...................................
High Beam .63
........
Key (Immobilizer System) .61
......................................
Low Fuel .63
................
Low Oil Pressure .60,324
..............
Low Tire Pressure .64,258
..........
Maintenance Minder .65,273
Malf unction Indicator
................................
Lamp .60,325
.................
Passenger Airbag Of f .32
...........................
Side Airbag Of f .61
...............................................
SRS .61
...................................
TPMS .64,259
Turn Signal and Hazard
...................................
Warning .63
VSA (Vehicle Stability ..............................
Assist) .62,256
..............................
Washer Level .65
.........
Indicators, Instrument Panel .59 ...............................
Inf ant Restraint .39
......................................
Inf ant Seats .39
............
Tether Anchorage Point .48
...................
Inf lation, Proper Tire .302
........
Recommended Pressures .303
.................................
Inside Mirror .111
.............................
Inspection, Tire .304
....................
Installing a Child Seat .42
............................
Instrument Panel .59
........
Instrument Panel Brightness .76
..............
Instruments and Controls .57
...............................
Interior Lights .122
........................................
Introduction .i
.................
Jacking up the Vehicle .314
.......................................
Jack, Tire .315
................................
Jump Starting .320 .......................
Label, Certif ication .334
.................
Lane Change, Signaling .74
..................
Lap/Shoulder Belts .14,19
...........
LATCH Anchorage System .43
Lights
....................
Bulb Replacement .291
.......................................
Indicator .64
.........................................
Parking .74
..................................
Turn Signal .74
....................................
Load Limits .237
......
LOCK (Ignition Key Position) .81
Locks
.......
Anti-thef t Steering Column .81
..........................
Childproof Door .88
............................
Fuel Fill Door .227
..........................
Glove Box .117,118
.................................
Power Door .82
........................................
Tailgate .92
........................
Low Coolant Level .230
.........................
Low Fuel Indicator .63
...
Low Oil Pressure Indicator .60,324
................................
Lower Anchors .43
