2008 HONDA CIVIC COUPE engine coolant

If Honda antif reeze/coolant is not
available, you may use another
major-brand non-silicate coolant as a
temporaryreplacement.Makesureit
is a high-quality coolant
recommended f or aluminum engines.
Continued use of any non-Honda
coolant can result in corrosion,
causing the cooling system to
malf unction or f ail. Have the cooling
system f lushed and ref illed with
Honda antif reeze/coolant as soon as
possible.
If the reserve tank is completely
empty, you should also check the
coolant level in the radiator.Make sure the engine and radiator
are cool.
Relieve any pressure in the cooling
system by turning the radiator cap
counterclockwise, without
pressing down.
1. 2.
CONT INUED
Engine Coolant
Maint enance
239
RADIATOR CAP
DX, Canadian DX-G, LX, EX, EX-LRemoving the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
——

y

y
(+yy

Pour coolant into the reserve tank.
Fill it to half way between the MAX
and MIN marks. Put the cap back
on the reserve tank.
Do not add any rust inhibitors or
other additives to your vehicle’s
cooling system. They may not be
compatible with the coolant or
engine components.
The coolant level should be up to
the base of the f iller neck. Add
coolant if it is low.
Pourthecoolantslowlyand
caref ully so you do not spill any.
Clean up any spill immediately; it
could damage components in the
engine compartment.
Put the radiator cap back on, and
tighten it fully.
Remove the radiator cap by
pushing down and turning
counterclockwise.
3.
4. 5.6.
Engine Coolant
240
Si
SiRESERVE TANK
RADIATOR CAP RESERVE TANK
DX, Canadian DX-G, LX, EX, EX-L
——

y

y
(+yy

Put the radiator cap back on
tightly. Run the engine, and check
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (seeon page ).
If you do not see steam or spray,
leave the engine running and
watch the temperature gauge. If
the high heat is due to overloading,
the engine should start to cool
down almost immediately. If it
does, wait until the temperature
gauge comes down to the midpoint,
then continue driving.
If the temperature gauge stays at
the red mark, turn of f the engine.
Look f or any obvious coolant leaks,
such as a split radiator hose.
Everything is still extremely hot,
so use caution. If you f ind a leak, it
must be repaired bef ore you
continue driving (see
on page ).
If you don’t f ind an obvious leak,
check the coolant level in the
radiator reserve tank (see page ). Add coolant if the level is
below the MIN mark. Start the engine, and set the
temperature control dial to
maximum heat. Add coolant to the
radiator up to the base of the f iller
neck. If you do not have the
proper coolant mixture available,
you can add plain water.
Remember to have the cooling
system drained and ref illed with
the proper mixture as soon as you
can.
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back on
tightly.
Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without pushing
down, to the f irst stop. Af ter the
pressure releases, push down on
the cap, and turn it until it comes
off.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the reading
reaches the middle of the
temperature gauge, or lower,
bef ore checking the radiator.
7. 8. 9.
3. 4. 5. 6. 290
191 290
10. 11.
Emergency
Towing
Emergency
Towing
If theEngineOverheats
280
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
——

y
y
(+yy

µµ
Î Î ÎΠεµµ µ µµµµµµµµ
Î
Î Î
Î ÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎ
Specif ications
T echnical Inf ormation
297
Air Conditioning
Lights
Capacities
Refrigerant type
Charge quantity
Lubricant oil typeHFC-134a (R-134a)
14.1 15.9 oz (400 450 g)
SP-10
Headlights (HI)
Headlights (LO)
Front turn signal/Side marker/
Parking light
Rear turn signal lights
Stop/Taillights
Rear side marker lights
Back-up lights
High-mount brake light
License plate lights
Ceiling light
Spotlights
Trunk light 60 W
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V 51 W
28/8 W
21 W
21/5 W
3CP
18 W
21 W
3CP8W8W5W
Including the coolant in the reserve tank and that remaining in
the engine
Reserve tank capacity:
Excluding the oil remaining in the engine 13.2 US gal (50)
1.45 US gal (5.5)
1.37 US gal (5.2)
1.19 US gal (4.5)
1.88 US gal (7.1)
1.72 US gal (6.5)
1.80 US gal (6.8)
3.9 US qt (3.7
)
4.6 US qt (4.4)
3.7 US qt (3.5)
4.4 US qt (4.2)
4.8 US qt (4.5)
5.8 US qt (5.5)
1.5 US qt (1.4)
1.6 US qt (1.5)
1.7 US qt (1.6)
1.8 US qt (1.7)
2.5 US qt (2.4)
6.2 US qt (5.9)
2.6 US qt (2.5
)
4.8 US qt (4.5)
0.11 US gal (0.4
)
Fuel tank
Engine
coolant
Engine oil Manual
transmission
fluid Automatic
transmission
fluid
Windshield
washer
reservoir
Change Total
Change
Including
filter
Without filter
Total
ChangeTotal
Change Total
U.S. Vehicles
Canada
Vehicles Approx.
1: 2: 3:
4: Si A/T
M/T
A/T
M/T
:(HB3)(HB4)
EX, EX-L, Si:
Canada: DX, DX-G, LX, EX, EX-L
U.S.: DX, LX, EX, EX-L Replacement of the light should be done by yourdealer.
U.S. DX and LX
Canada: DX, DX-G, LX
1 2 3 34334
3434343434
——

y
y
(+yy

CONT INUED
...
Accessories and Modif ications . 195
ACCESSORY (Ignition Key
.......................................
Position) . 78
............
Accessory Power Sockets . 108
................
Adding Engine Coolant . 238
....................
Additives, Engine Oil . 235
.......
Adjusting the Steering Wheel . 75
.........
Advice f or Pregnant Women . 16
...............................
Airbag (SRS) . 9, 21
..............
Air Conditioning System . 114
.........................................
Usage . 117
...............
Air Pressure, Tires . 255, 257
.......................
Alcohol in Gasoline . 187
......................................
Antif reeze . 238
Anti-lock Brakes (ABS)
...............................
Indicator . 59, 214
...................................
Operation . 214
..............
Anti-thef t, Audio System . 179
Anti-thef t Steering Column
..............................................
Lock . 78
................................
Audio System . 119
.....
Auto Door Locking/Unlocking . 81
...
Automatic Seat Belt Tensioners . 19
.............
Automatic Speed Control . 182 ..............
Automatic Transmission . 208
..........................
Capacity, Fluid . 297
...............
Checking Fluid Level . 242
.......................................
Shif ting . 208
Shif t Lever Position
...............................
Indicators . 208
................
Shif t Lever Positions . 209
....................
Shif t Lock Release . 211
Battery Charging System ...........................
Indicator . 57, 281
............................
Jump Starting . 277
..............................
Maintenance . 265
............................
Specif ications . 298
..............................
Bef ore Driving . 185
....................................
Belts,Seat .8,18
.........................
Beverage Holders . 107
..................................
Booster Seats . 47
Brakes
...........
Anti-lock System (ABS) . 214
.............
Break-in, New Linings . 186
....................
Bulb Replacement . 250
...........................................
Fluid . 244 .......................................
Parking . 105
..........................
System Design . 213
.................
System Indicator . 58, 283
........................
Wear Indicators . 213
.............................
Braking System . 213
.................
Break-in, New Vehicle . 186
..
Brightness Control, Instruments . 73
........................
Brights, Headlights . 72
Bulb Replacement
..........................
Back-up Lights . 250
..............................
Brake Lights . 250
................
Front Parking Lights . 249
........
Front Side Marker Lights . 249
.................................
Headlights . 246
.........
High-mount Brake Light . 251
............................
Specif ications . 297
....................
Turn Signal Lights . 249
..............................
Bulbs, Halogen . 246
............................
Capacities Chart . 297
.............
Carbon Monoxide Hazard . 50
.............................
Carrying Cargo . 197
Index
A
B
C
INDEX
I
——

y
y
(+yy

..............
CAUTION, Explanation of . ii
.........................................
CD Care . 174
..........................
CD Changer . 135, 157
.....
CD Changer Error Messages . 137
..............................
CD Player . 130, 150
.
CD Player Error Messages . 136, 158
..................................
Ceiling Light . 111
........................
Certif ication Label . 294
.................................
Chains, Tires . 263
....................
Changing a Flat Tire . 271
Changing Oil
........................................
How to . 236
......................................
When to . 225
...
Charging System Indicator . 57, 281
..............
Check Fuel Cap Message . 68
............
Checklist, Bef ore Driving . 203
.....................................
Child Saf ety . 32
..............................
Booster Seats . 47
...................................
Child Seats . 39
Important Saf ety
.........................
Reminders . 32, 35
..........................................
Inf ants . 37
............................
Large Children . 46
.........................................
LATCH . 41
......................
Risks with Airbags . 33
.............................
Small Children . 38 .........................................
Tethers . 45
...........................
Warning Labels . 51
.........
Where Should a Child Sit? . 33
Child Seats ......................................
Installing . 40
...........................
Lower Anchors . 41
......................................
Selecting . 39
................
Tether Anchor Points . 45
Cleaning ...................................
Seat Belts . 251
..............................................
Clock . 180
...................................
Clutch Fluid . 245
........................
CO in the Exhaust . 305
......................................
Coat Hook . 108
............
Cold Weather, Starting in . 204
......................
Compact Spare Tire . 270
.................
Console Compartment . 107
.................
Consumer Inf ormation . 312
.............
Controls, Instruments and . 53
Coolant
........................................
Adding . 238
....................................
Checking . 191
.........................
Proper Solution . 238
...................
Temperature Gauge . 68
Crankcase Emissions Control ........................................
System . 305 ................
Cruise Control Indicator . 62
............
Cruise Control Operation . 182
...................................
Cup Holders . 107
....
Customer Service Inf ormation . 312
................
DANGER, Explanation of . ii
...................................
Dashboard . 3, 54
................
Daytime Running Lights . 73
Daytime Running Lights
.......................................
Indicator . 63
.................................
Dead Battery . 277
............
Def ects, Reporting Saf ety . 314
................
Def ogger, Rear Window . 74
..............
Def rosting the Windows . 118
....................................
Dimensions . 296
...............
Dimming the Headlights . 72
Dipstick
..........
Automatic Transmission . 242
..................................
Engine Oil . 189
..........................
Directional Signals . 72
........
Disc Brake Wear Indicators . 213
.......................................
Disc Care . 174
............................
Disc Player . 130, 150
..................
Display Change Button . 66
Index
D
II
——

y
y
(+yy

Î
CONT INUED
.....................
Disposal of Used Oil . 238
Doors
.
Auto Door Locking/Unlocking . 81
..............
Locking and Unlocking . 79
......................
Power Door Locks . 80
........
DOT Tire Quality Grading . 299
Downshif ting, Manual
.............................
Transmission . 205
...........
Driver and Passenger Safety . 5
...........................................
Driving . 201
....................................
Economy . 192
..................
Dust and Pollen Filter . 253
..............................
Economy, Fuel . 192
..................................
Emergencies . 269
.............
Battery, Jump Starting . 277
...........
Brake System Indicator . 283
................
Changing a Flat Tire . 271
.....
Charging System Indicator . 281
..................
Checking the Fuses . 284
.........
Hazard Warning Flashers . 74
............................
Jump Starting . 277
.....
Low Oil Pressure Indicator . 281
...
Malf unction Indicator Lamp . 282 ..................
Overheated Engine . 279
.......................................
Towing . 290
.........................
Emergency Brake . 105
......................
Emergency Flashers . 74
......................
Emergency Towing . 290
............
Emergency Trunk Opener . 91
.......................
Emissions Controls . 305
........................
Emissions Testing . 308Engine
............
Adding Engine Coolant . 238
....
Coolant Temperature Gauge . 68
.........................
If It Won’t Start . 275
Malf unction Indicator
................................
Lamp . 57, 282
.......................
Oil Lif e Indicator . 225
........
Oil Pressure Indicator . 57, 281
.............................
Oil, Synthetic . 235
..............
Oil, What Kind to Use . 234
...............................
Overheating . 279
............................
Specif ications . 296
....................
Speed Limiter . 207, 210
.......................................
Starting . 204
......................
Ethanol in Gasoline . 187
.
Evaporative Emissions Controls . 305
...............................
Exhaust Fumes . 50 Expectant Mothers, Use of Seat
........................................
Belts by . 16
....................................
Fan Control . 115
.........................................
Features . 113
....................
Filling the Fuel Tank . 187
Filters
.........................
Dust and Pollen . 253
...............................................
Oil . 236
.............
Flashers, Hazard Warning . 74
...................
Flat Tire, Changing a . 271
Fluids
..........
Automatic Transmission . 242
..........................................
Brake . 244
.........................................
Clutch . 245
..............
Manual Transmission . 243
..........................
Power Steering . 245
..................
Windshield Washer . 241
FM Stereo Radio ...................................
Reception . 172
...........................
Folding Rear Seat . 98
..........................
Four-way Flashers . 74
Index
E F
INDEX
III
——

y

y
(+yy

..............................
Front Airbags . 9, 23
Front Seat
......................................
Adjusting . 92
.....................................
Airbags . 9, 23
.................................................
Fuel . 186
..........
Check Fuel Cap Message . 68
....................................
Economy . 192
......................
Fill Door and Cap . 187
...........................................
Gauge . 68
.....................
Low Fuel Indicator . 64
................
Octane Requirement . 186
...............................
Oxygenated . 187
........................
Tank, Ref ueling . 187
..............................
Fuse Locations . 288
.....................
Fuses, Checking the . 284
...............
Gas Mileage, Improving . 192
.........................................
Gasoline . 186
...........................................
Gauge . 68
.....................
Low Fuel Indicator . 64
................
Octane Requirement . 186
........................
Tank, Ref ueling . 187
................
Gas Station Procedures . 187 Gauges
...
Engine Coolant Temperature . 68
...............................................
Fuel . 68
Gearshif t Lever Positions ..........
Automatic Transmission . 208
..............
Manual Transmission . 206
......................................
Glove Box . 107
Gross Axle Weight Rating
.....................................
(GAWR) . 199
Gross Vehicle Weight Rating .....................................
(GVWR) . 199
.............
Halogen Headlight Bulbs . 246
..............
Hazard Warning Flashers . 74
Headlights
........................................
Aiming . 246
............
Daytime Running Lights . 73
..................
High Beam Indicator . 63
........................
Reminder Beeper . 72
........
Replacing Halogen Bulbs . 246
...................................
Turning on . 72
..............................
Head Restraints . 95
.............................
Heated Mirrors . 105
.....................
Heating and Cooling . 114 .............
High Altitude, Starting at . 204
............................
High Beam Lever . 72
..............
High-mount Brake Light . 251
..
Hood, Opening and Closing the . 188
..............................................
Horn .4,70
...........................
Hydraulic Clutch . 244
...
Identif ication Number, Vehicle . 294
..............
If the Engine Overheats . 279
..............
If the Engine Wont Start . 275
Ignition
..............................................
Keys . 76
...........................................
Switch . 78
............
Timing Control System . 306
........................
Immobilizer System . 77
.........
Important Safety Precautions . 6
Indicators
..............
ABS (Anti-Lock Brake) . 59
Brake (Parking and Brake
....................................
System) . 58
................
Charging System . 57, 281
.............................
Cruise Control . 62
DRL (Daytime Running
......................................
Lights) . 63
Index
G H I
IV
——

y
y
(+yy
