VEHICLE CHARACTERISTICS
How your vehicle differs from other vehicles
SUV and trucks can differ from
some other vehicles in a few
noticeable ways. Your vehicle may
be:
•Higher – to allow higher load
carrying capacity and to allow it
to travel over rough terrain
without getting hung up or
damaging underbody components.
•Shorter – to give it the capability
to approach inclines and drive
over the crest of a hill without
getting hung up or damaging
underbody components. All other
things held equal, a shorter
wheelbase may make your vehicle
quicker to respond to steering inputs than a vehicle with a longer
wheelbase.
•Narrower — to provide greater
maneuverability in tight spaces,
particularly in off-road use.
As a result of the above dimensional
differences, SUV’s and trucks often
will have a higher center of gravity
and a greater difference in center of
gravity between the loaded and
unloaded condition.
These differences that make your
vehicle so versatile also make it
handle differently than an ordinary
passenger car.
2008 Econoline(eco)
Owners Guide (post-2002-fmt)
USA(fus)
Tires, Wheels and Loading
114
ProCarManuals.com

GCWR (Gross Combined Weight Rating)/Trailer Weights
EngineRear
axle
ratioMaximum
GCWR - lb.
(kg)Maximum
Loaded
Trailer Weight
- lb. (kg)Maximum
frontal area of
trailer - ft
2
(m2)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Regular Wagon (11/12–passenger) (8800 GVWR)
5.4L 3.73 13000 (5897) 6700 (3039) 60 (5.52)
E-350 Extended Wagon (11–passenger) (9300 GVWR)
5.4L 3.73 13000 (5897) 6500 (2948) 60 (5.52)
E-350 Extended Wagon (14/15–passenger) (9100 GVWR)
5.4L 3.73 13000 (5897) 6400 (2903) 60 (5.52)
E-350 Cutaway (138” wheelbase, single rear wheel)
(9600 GVWR)
5.4L 4.10 13000 (5897) 8000 (3629) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Extended Cutaway (138” wheelbase, single rear wheel)
(9600 GVWR)
5.4L 4.10 10600 (4808) 5700 (2585) 60 (5.52)
E-350 Cutaway (138” wheelbase, dual rear wheel)
(10000 GVWR)
5.4L 4.10 13000 (5897) 7800 (3538) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Cutaway (158” wheelbase, dual rear wheel)
(10000 GVWR)
5.4L 4.10 13000 (5897) 7800 (3538) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Cutaway (138” wheelbase, dual rear wheel)
(11500 GVWR)
5.4L 4.10 13000 (5897) 7800 (3538) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Cutaway (158” wheelbase, dual rear wheel)
(11500 GVWR)
5.4L 4.10 13000 (5897) 7700 (3493) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
2008 Econoline(eco)
Owners Guide (post-2002-fmt)
USA(fus)
Tires, Wheels and Loading
154
ProCarManuals.com

GCWR (Gross Combined Weight Rating)/Trailer Weights
EngineRear
axle
ratioMaximum
GCWR - lb.
(kg)Maximum
Loaded
Trailer Weight
- lb. (kg)Maximum
frontal area of
trailer - ft
2
(m2)
E-350 Cutaway (158” wheelbase, dual rear wheel)
(12500 GVWR)
5.4L 4.10 13000 (5897) 7800 (3538) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Cutaway (176” wheelbase, dual rear wheel)
(10000 GVWR)
5.4L 4.10 13000 (5897) 7800 (3538) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Cutaway (176” wheelbase, dual rear wheel)
(12500 GVWR)
5.4L 4.10 13000 (5897) 7800 (3538) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Stripped Chassis (138” wheelbase, single rear wheel)
(9000 GVWR)
5.4L 3.73 13000 (5897) 8600 (3901) 60 (5.52)
5.4L 4.10 13000 (5897) 8600 (3901) 60 (5.52)
E-350 Stripped Chassis (158” wheelbase, single rear wheel)
(9600 GVWR)
5.4L 3.73 13000 (5897) 8600 (3901) 60 (5.52)
5.4L 4.10 13000 (5897) 8600 (3901) 60 (5.52)
E-350 Stripped Chassis (138” wheelbase, dual rear wheel)
(10000 GVWR)
5.4L 4.10 13000 (5897) 8400 (3810) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Stripped Chassis (138” wheelbase, dual rear wheel)
(11500 GVWR)
5.4L 4.10 13000 (5897) 8400 (3810) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
2008 Econoline(eco)
Owners Guide (post-2002-fmt)
USA(fus)
Tires, Wheels and Loading
155
ProCarManuals.com

GCWR (Gross Combined Weight Rating)/Trailer Weights
EngineRear
axle
ratioMaximum
GCWR - lb.
(kg)Maximum
Loaded
Trailer Weight
- lb. (kg)Maximum
frontal area of
trailer - ft
2
(m2)
E-350 Stripped Chassis (158” wheelbase, dual rear wheel)
(10000 GVWR)
5.4L 4.10 13000 (5897) 8500 (3855) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Stripped Chassis (158” wheelbase, dual rear wheel)
(12500 GVWR)
5.4L 4.10 13000 (5897) 8300 (3765) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Stripped Chassis (176” wheelbase, dual rear wheel)
(10000 GVWR)
5.4L 4.10 13000 (5897) 8300 (3765) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-350 Stripped Chassis (176” wheelbase, dual rear wheel)
(12500 GVWR)
5.4L 4.10 13000 (5897) 8300 (3765) 60 (5.52)
6.8L 4.10 18500 (8391) 10000 (4536) 60 (5.52)
E-450 Cutaway (158” wheelbase, dual rear wheel)
(14050 GVWR)
5.4L 4.56 14050 (6373) 8500 (3855) 60 (5.52)
E-450 Cutaway (176” wheelbase, dual rear wheel)
(14050 GVWR)
5.4L 4.56 14050 (6373) 8400 (3810) 60 (5.52)
E-450 Cutaway (158” wheelbase, dual rear wheel)
(14500 GVWR)
6.8L 4.56 20000 (9072) 10000 (4536) 60 (5.52)
E-450 Cutaway (176” wheelbase, dual rear wheel)
(14500 GVWR)
6.8L 4.56 20000 (9072) 10000 (4536) 60 (5.52)
2008 Econoline(eco)
Owners Guide (post-2002-fmt)
USA(fus)
Tires, Wheels and Loading
156
ProCarManuals.com

GCWR (Gross Combined Weight Rating)/Trailer Weights
EngineRear
axle
ratioMaximum
GCWR - lb.
(kg)Maximum
Loaded
Trailer Weight
- lb. (kg)Maximum
frontal area of
trailer - ft
2
(m2)
E-450 Stripped Chassis (158” wheelbase, dual rear wheel)
(14050 GVWR)
5.4L 4.56 14050 (6373) 9200 (4173) 60 (5.52)
E-450 Stripped Chassis (176” wheelbase, dual rear wheel)
(14050 GVWR)
5.4L 4.56 14050 (6372) 9100 (4128) 60 (5.52)
E-450 Stripped Chassis (158” wheelbase, dual rear wheel)
(14500 GVWR)
6.8L 4.56 20000 (9072) 10000 (4536) 60 (5.52)
E-450 Stripped Chassis (176” wheelbase, dual rear wheel)
(14500 GVWR)
6.8L 4.56 20000 (9072) 10000 (4536) 60 (5.52)
Maximum trailer weight for all cutaway (E-350 and E-450) vehicles
must be calculated by subtracting the weight of the vehicle (including
incomplete vehicle weight and payload which includes second unit
body weight, cargo and passengers) from the GCW. Otherwise,
maximum trailer weight is 10,000 lb. (4536 kg).
For high altitude operation reduce GCWR by 2% per 1,000 ft.
(300 meters) elevation.
To determine the maximum trailer weight designed for your particular
vehicle as equipped, follow the sectionVehicle loadingearlier in this
chapter.
Your vehicle’s load capacity is designated by weight, not by volume, so
you cannot necessarily use all available space when loading a vehicle.
Distribute the load so that only 10–15% of the total is on the tongue. Tie
down the load so that it does not shift and change the weight on the
hitch.
Towing a trailer places an additional load on your vehicle’s engine,
transmission, axle, brakes, tires and suspension. Inspect these
components carefully after any towing operation.
Do not exceed trailer weight of 5,000 lb (2,268 kg) when towing with
bumper only.
2008 Econoline(eco)
Owners Guide (post-2002-fmt)
USA(fus)
Tires, Wheels and Loading
157
ProCarManuals.com

Item Capacity Ford part nameFord part number /
Ford specification
Fuel tank–all regular and extended
length vans and wagons35.0 gallons
(132.4L)
—— Fuel tank–138 inch wheelbase
(except E-Super Duty)37.0 gallons
(140.0L)
Fuel tank–158 inch wheelbase
(except E-Super Duty)37.0 gallons
(140.0L)
8
Fuel tank–176 inch wheelbase
(except E-Super Duty)37.0 gallons
(140.0L)
8
Fuel tank–158 inch and 176 inch
wheelbase (E-Super Duty)55.0 gallons
(208.0L)
1Add the coolant type originally equipped in your vehicle.2Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the requirements of Ford
specification WSS-M2C930-A and the API Certification mark.3Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size, if equipped with an
in-tank cooler, if equipped with an oil to air cooler and if equipped with a remote filter assembly. The amount of
transmission fluid and fluid level should be set by the indication on the dipstick’s normal operating range.4Automatic transmissions that require MERCON
V should only use MERCON
V fluid. Refer toscheduled
maintenance informationto determine the correct service interval. Use of any fluid other than the recommended
fluid may cause transmission damage.
Automatic transmissions that require MERCON
SP should only use MERCON
SP fluid. Use of a dual usage fluid in
an automatic transmission requiring MERCON
SP may cause transmission damage. Refer toscheduled
maintenance informationto determine the correct service interval. Use of any fluid other than the recommended
fluid may cause transmission damage.5Dana limited-slip axle (M60) requires 8 oz. (228 ml) of Additive Friction Modifier XL-3 or equivalent meeting Ford
specification EST-M2C118-A.6If your vehicle’s rear axle is filled with a synthetic rear axle lubricant it is considered lubricated for life. These
lubricants do not need to be checked or changed unless a leak is suspected, service is required or the axle assembly
has been submerged in water. The axle lubricant should be changed any time the rear axle has been submerged in
water.7Fill Dana rear axles to 1/4 inch to 9/16 inch (6 mm to 14 mm) below bottom of fill hole.8Optional fuel tank 55.0 gallons (208.0L).
