To change the bulb, proceed as follows:
❒remove the light unit Alevering in the
point shown by the arrow;
❒replace the bulb Breleasing it from
the side contacts making sure that the
new bulb is correctly clamped be-
tween the contacts.
fig. 45F0L0092m
If a fuse switches off again,
contact the Fiat Service Net-
work .
WARNING
fig. 44F0L0091m
IF A FUSE BLOWS
GENERAL fig. 45
The fuse is a protective device for the
electric system: it comes into action (i.e.
it cuts off) mainly due to a fault or im-
proper action on the system.
When a device does not work, check the
efficiency of its fuse: the conductor ele-
ment Amust be intact. If not, replace the
fuse with one of the same amp rating
(same colour).
Bundamaged fuse
Cfuse with damaged filament.
To replace a fuse, use the pliers Dhooked
to the fusebox on the dashboard.
157-192 Croma TRW GB 10-11-2008 13:15 Pagina 181

FUSE LOCATION
The vehicle’s fuses are grouped in three
central units that are located on the in-
strument dashboard, in the engine com-
partment and inside the boot (left side).
On the battery’s positive pole there is a
fourth control unit that contains large ca-
pacity fuses (MEGA-FUSE, MIDI-FUSE,
MAXI-FUSE).
To replace these fuses, con-
tact the Fiat Service Net-
work.
WARNING
182
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
Before replacing a fuse, make
sure the ignition key has been
removed and that all the oth-
er services are switched off
and/or disengaged.
If a general fuse (MEGA-
FUSE, MIDI-FUSE, MAXI-
FUSE) cuts in, do not attempt any re-
pair and contact a Fiat Dealership.
WARNINGNever replace a fuse with met-
al wires or anything else.
Never change a fuse with
another with a higher amp
rating, DANGER OF FIRE.
WARNING
157-192 Croma TRW GB 10-11-2008 13:15 Pagina 182

fig. 47F0L0093m
Fuse box on the dashboard
fig. 46-47
To gain access to the fuses in the fuse box
on the dashboard, loosen the fastening
screw Aand remove the cover.
fig. 46F0L0145m
183
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
157-192 Croma TRW GB 10-11-2008 13:15 Pagina 183

184
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
Fuse box in engine compartment
fig. 48-49
To gain access to the fuses in the fuse box
next to the battery, remove the protec-
tion cover.
fig. 48
fig. 49F0L0094m
F0L0095m
157-192 Croma TRW GB 10-11-2008 13:15 Pagina 184

185
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
Fuse box in the boot fig. 50-51
To gain access to the fuse box located on
the left side of boot open the relevant
door (as shown in the figure).
fig. 50
fig. 51F0L0217m
F0L0213m
157-192 Croma TRW GB 10-11-2008 13:15 Pagina 185

186
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
F 12
F 13
F 31
F 32
F 33
F 34
F 35
F 36
F 37
F 38
F 39
F 40
F 41
F 42
F 43
F 4415
15
7.5
15
20
20
7.5
20
10
15
10
30
7.5
7.5/15 (*)
30
20 FUSE SUMMARY TABLE
