PARKING SENSORS
(where provided)
Parking sensors inform the driver about
the presence of obstacles behind the car
(versions fitted with 4 rear sensors) or be-
hind and in front of the car (versions fit-
ted with 4 rear sensors and 4 front sen-
sors).
This system is therefore an aid for the dri-
ver when parking the car since it detects
obstacles out of the driver’s sight range.
The driver is warned of the presence and
distance from the obstacle by an inter-
mittent buzzer (the sound of the buzzer
becomes more frequent as the reduction
of distance between the car and the ob-
stacle decreases).
SENSORS
To detect obstacles the system used 4
sensors located on the front bumper
(where provided) fig. 105and 4 sensors
located on the rear bumper fig. 106.
ACTIVATION
Version with 4 sensors
In the version with 4 rear sensors, the sys-
tem turns on automatically when reverse
is engaged.
99
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
Version with 8 sensors
In the version with 4 rear sensors and 4
front sensors, the system activates when
reverse is engaged or when the button is
pressed tfig. 107.
When reverse is released, the rear sen-
sors and front sensors remain active un-
til a speed of approximately 15 km/h is ex-
ceeded to allow the parking manoeuvre
to be completed.The system may be activated by pressing
the button tfig. 107located on the
centre panel: a warning light on the but-
ton comes on when the system is active.
The sensors are deactivated by pressing
the tfig. 107again or exceeding a
speed of 15 km/h: the warning light on the
button is off when the system is inactive.
When the sensors are activated, the sys-
tem begins to emit acoustic signals from
the front or rear indicators as soon as an
obstacle is detected. The frequency aris-
es as soon as the car approaches the ob-
stacle.
fig. 105F0Q0745m
fig. 106F0Q0603m
fig. 107F0Q0035m
083-104 BRAVO GB 29-10-2008 12:37 Pagina 99

100
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
BUZZER WARNINGS
The driver is warned of the presence and
distance from the obstacle by the buzzers
installed in the passenger compartment:
❒in versions with 4 rear sensors, a
buzzer located in the front dashboard
area warns of the presence of rear ob-
stacles;
❒In versions with 8 rear sensors (4 front
and 4 rear) a front buzzer warns of the
presence of front obstacles and a
buzzer at the rear warns of the pres-
ence of rear obstacles. This feature
gives the driver a sense of directional-
ity (front/rear) about the presence of
obstacles.
When the reverse gear is engaged an in-
termittent acoustic signal is automatically
activated.
The acoustic signal:
❒becomes louder as the reduction of
distance between the car and the ob-
stacle decreases;
❒becomes continuous when the distance
between the car and the obstacle is less
that 30 cm and stops immediately if the
distance raises;
❒is constant if the distance is unvaried. If
this situation takes place for side sen-
sors, the signal is stopped after about
3 seconds to prevent sound indications
when performing manoeuvres near
walls.
For proper operation, the
parking sensors set on the
bumpers shall be clean from
mud, dirt, snow or ice. When
cleaning the sensors, take the utmost
care to prevent their damaging; do not
use therefore dry or rough clothes. Sen-
sors shall be washed with clean water
and car detergent, if required. In wash-
ing stations, clean sensors quickly keep-
ing the vapour jet/high pressure wash-
ing nozzles at 10 cm at least from the
sensors.
Any repainting of bumpers or
touch/up in sensor areas shall
be carried out at Fiat Dealer-
ship only. Improper painting
could impair the regular operation of
parking sensors.
Parking manoeuvres howev-
er are always under the dri-
ver’s responsibility that shall always
check the absence of people (special-
ly children) or animals in the ma-
noeuvre space. This system is just a
help for the driver but she/he shall nev-
er reduce attention during dangerous
manoeuvres even if performed at low
speed.
WARNING
When the obstacle is located at a distance
of less than 30 cm, the device emits a con-
tinuous sound. Depending on the position
of the obstacle (in front or behind) the
sound is emitted by the corresponding
acoustic indicators (front or rear). The ob-
stacle closest to the vehicle is indicated
in all cases.
The beep will stop immediately if the dis-
tance raises. Beep tone is constant if the
distance detected by central sensors is un-
varied. If this situation takes place for side
sensors, the signal is stopped after about
3 seconds to prevent sound indications
when performing manoeuvres near walls.
083-104 BRAVO GB 29-10-2008 12:37 Pagina 100

101
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
FAILURE INDICATIONS
In the event of sensor failures, when en-
gaging the reverse gear the driver is
warned by the turning on of warning light
èon the instrument panel or by symbol
t, together with the message on the dis-
play (see section “Warning lights and mes-
sages”).
GENERAL WARNINGS
When parking, take the utmost care to
obstacles set above or under the sensors.
Objects set close to the car front or rear
part, under certain circumstances are not
detected and could therefore cause dam-
ages to the car.
Parking sensors regular operation could
be affected by the following conditions:
❒Indications sent by the sensors can be
altered by dirt, snow or ice deposited
on the sensors or by multiple painting.
❒Sensors detect non-existing objects,
“echo disturbances” due to: car washing,
rain (with very strong wind), hail, etc.
❒Indications sent by the sensors can al-
so be altered by ultrasound systems
(e.g.: truck pneumatic brakes or pneu-
matic hammers) set nearby the car.
❒Parking sensors performance can also
be affected by sensor position; for ex-
ample changes to the car set-up due to
shock-absorber wear, suspensions,
changing tyres, loading the car too
much, implementing special tuning to
lower the car.
❒Presence of obstacles at the upper side
of the car not be detected since the sys-
tem detects obstacles that could knock
into the lower side of the car. SENSOR DETECTION RANGE
