2008 DODGE RAM 2500 POWER WAGON tailgate

NSunroof Maintenance...................159
NSunroof Fully Closed...................159
mElectrical Power Outlets..................159
mCigar Lighter And Ash Receiver............161
mCupholders...........................162
NFront Instrument Panel Cupholders........162
NRear Cupholder Ð Quad Cab Ð
If Equipped.........................162
mStorage..............................163
NCenter Storage Compartment Ð If Equipped . . 163NStorage And Seats Ð If Equipped..........164
mRear Window Features...................165
NElectric Rear Window Defroster And Heated
Side View Mirrors Ð If Equipped..........165
NPower Sliding Rear Window Ð If Equipped . . 165
NSliding Rear Window Ð If Equipped.......166
mFold Flat Load Floor Ð If Equipped.........166
mPickup Box...........................169
mSlide-In Campers.......................171
mEasy-Off Tailgate.......................171
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83
3

There are stampings in the sheet metal on the inner side
bulkheads of the box in front of and behind both wheel
housings. Place wooden boards across the box from side
to side to create separate load compartments in the
pickup box.
There are four tie-down cleats bolted to the lower sides of
the pickup box that can sustain loads up to 1000 lbs (450
kg) total.
SLIDE-IN CAMPERS
DO NOTuse slide-in campers on your vehicle.
EASY-OFF TAILGATE
The tailgate can be removed quickly. Tailgate removal is
sometimes required for pickup box loading. To remove
the tailgate unlatch the tailgate and remove the support
cables by releasing the lock tang from the pivot, then
rotate and pull away from the box. Once the cables are
free, move to the right side of the tailgate hinge bracket.
Raise the right side of the tailgate until the right side
pivot clears the hanger bracket. Slide the entire tailgate to
the right to free the left side pivot. Remove the tailgate
from the vehicle entirely. Do not carry the tailgate loose in
the truck pickup box.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171
3

NOTE:Dual rear wheel pickup models require properly
spaced rear clearance lights. If such a vehicle is operated
without a tailgate, suitable lights must be installed.
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
After using the jack and tools, always reinstall them
in the original carrier and location. While driving
you may experience, abrupt stopping, rapid accelera-
tion, or sharp turns. A loose jack, tools, bracket or
other objects in the vehicle may move around with
force, resulting in serious injury.
JACKING INSTRUCTIONS
Removing The Spare Tire
Remove the spare tire before attempting to jack the truck.
Attach the wheel wrench to the jack extension tube. Insert
the tube through the access hole between the lower
tailgate and the top of the bumper and into the winch
mechanism tube. Rotate the wheel wrench handle coun-
terclockwise until the spare tire is on the ground with
enough cable slack to allow you to pull it out from underthe vehicle. When the spare is clear, tilt the retainer at the
end of the cable and pull it through the center of the
wheel.
It is recommended that you stow the flat or spare to
avoid tangling the loose cable.
392 WHAT TO DO IN EMERGENCIES

Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, doors, tailgate and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to insure proper function. When performing other
underhood services, the hood latch, release mechanism
and safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality lubricant such as MopartLock
Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner. This will remove accu-
mulations of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
Windshield Washers
The fluid reservoir is located under the hood and should
be checked for fluid level at regular intervals. Fill the
reservoir with windshield washer solvent only (not ra-
diator antifreeze).
424 MAINTAINING YOUR VEHICLE

Supplemental Tire Pressure Information........ 344
Synthetic Engine Oil...................... 415
System, Navigation...................... 227
System, Remote Starting.................... 25
Tachometer............................ 179
Tailgate............................... 171
Tether Anchor, Child Restraint.............65,69
Tilt Steering Column..................... 137
Tip Start.............................. 259
Tire and Loading Information Placard......331,344
Tire Identification Number (TIN)............. 330
Tire Markings.......................... 326
Tire Pressure Monitor System (TPMS) Placard
ªHIº (MAX) Load Switch.................. 177
Tire Safety Information.................... 326
Tires ..........................78,86,335,482
Aging (Life of Tires).................... 341
Air Pressure.......................... 335Alignment........................... 343
Chains.............................. 344
Changing............................ 392
Compact Spare........................ 339
General Information.................... 335
High Speed.......................... 338
Inflation Pressures..................... 336
Jacking............................. 393
Life of Tires.......................... 341
Load Capacity.....................331,332
Off-Road............................. 86
Pressure Monitor System (TPMS)........... 347
Pressure Warning Light.................. 187
Quality Grading....................... 482
Radial.............................. 338
Replacement......................... 342
Rotation............................. 346
Safety...........................326,335
Sizes............................... 328
500 INDEX
