Gross Trailer Weight (GTW)
The gross trailer weight (GTW) is the weight of the trailer
plus the weight of all cargo, consumables and equipment
(permanent or temporary) loaded in or on the trailer in its
9loaded and ready for operation9condition. The recom-
mended way to measure GTW is to put your fully loaded
trailer on a vehicle scale. The entire weight of the trailer
must be supported by the scale.
Gross Combination Weight Rating (GCWR)
The gross combination weight rating (GCWR) is the total
permissible weight of your vehicle and trailer when
weighed in combination. (Note that GCWR ratings in-
clude a 68 kg (150 lbs) allowance for the presence of a
driver).
Gross Axle Weight Rating (GAWR)
The GAWR is the maximum capacity of the front and rear
axles. Distribute the load over the front and rear axles
evenly. Make sure that you do not exceed either front or
rear GAWR.
WARNING!
It is important that you do not exceed the maximum
front or rear GAWR. A dangerous driving condition
can result if either rating is exceeded. You could lose
control of the vehicle and have an accident.
Tongue Weight (TW)
The downward force exerted on the hitch ball by the
trailer. In most cases it should not be less than 10% or
more than 15% of the trailer load. You must consider this
as part of the load on your vehicle.
368 STARTING AND OPERATING
Page 376 of 504
þCheck for signs of tire wear or visible tire damage
before towing a trailer. Refer to the Tires±General
Information section of this manual on Tread Wear
Indicators for the proper inspection procedure.
þWhen replacing tires refer to the Tires±General Infor-
mation section of this manual on Replacement Tires for
proper tire replacement procedures. Replacing tires
with a higher load carrying capacity will not increase
the vehicle's GVWR and GAWR limits.
Towing Requirements Ð Trailer Brakes
þ
Donotinterconnect the hydraulic brake system or
vacuum system of your vehicle with that of the trailer.
This could cause inadequate braking and possible
personal injury.
þAn electronically actuated trailer brake controller is
required when towing a trailer with electronically
actuated brakes. When towing a trailer equipped with
a hydraulic surge actuated brake system, an electronic
brake controller is not required.
þTrailer brakes are recommended for trailers over 1,000
lbs (454 kg) and required for trailers in excess of 2,000
lbs (907 kg).
CAUTION!
If the trailer weighs more than 1,000 lbs (454 kg)
loaded, it should have its own brakes and they
should be of adequate capacity. Failure to do this
could lead to accelerated brake lining wear, higher
brake pedal effort, and longer stopping distances.
376 STARTING AND OPERATING
Page 491 of 504
Fluids, Lubricants and Genuine Parts.......... 465
Fog Lights.......................132,184,463
Fold Flat Load Floor..................... 166
Four Wheel Drive....................... 271
Four-Way Hazard Flasher.................. 390
Freeing A Stuck Vehicle................... 402
Front Axle (Differential)................... 434
Front Wheel Bearings..................... 439
Fuel................................. 357
Adding............................. 362
Filler Cap (Gas Cap).................... 363
Filter............................... 417
Gauge.............................. 189
Octane Rating......................357,465
Requirements......................357,464
Tank Capacity........................ 464
Fuses................................ 447
Garage Door Opener (HomeLinkt) ........... 150Gas Cap (Fuel Filler Cap)...............363,409
Gasoline (Fuel)......................... 357
Gasoline, Reformulated................... 358
Gauges............................... 179
Coolant Temperature.................... 181
Fuel................................ 189
Oil Pressure.......................... 180
Speedometer......................... 180
Tachometer.......................... 179
Voltmeter............................ 179
Gear Ranges........................263,269
Gear Ratios............................. 84
General Information.................18,120,357
Glass Cleaning.......................... 446
Gross Axle Weight Rating.................. 368
Gross Vehicle Weight Rating................ 367
Guide, Body Builders...................... 6
GVWR............................... 364
INDEX 491
10
Page 500 of 504
Supplemental Tire Pressure Information........ 344
Synthetic Engine Oil...................... 415
System, Navigation...................... 227
System, Remote Starting.................... 25
Tachometer............................ 179
Tailgate............................... 171
Tether Anchor, Child Restraint.............65,69
Tilt Steering Column..................... 137
Tip Start.............................. 259
Tire and Loading Information Placard......331,344
Tire Identification Number (TIN)............. 330
Tire Markings.......................... 326
Tire Pressure Monitor System (TPMS) Placard
ªHIº (MAX) Load Switch.................. 177
Tire Safety Information.................... 326
Tires ..........................78,86,335,482
Aging (Life of Tires).................... 341
Air Pressure.......................... 335Alignment........................... 343
Chains.............................. 344
Changing............................ 392
Compact Spare........................ 339
General Information.................... 335
High Speed.......................... 338
Inflation Pressures..................... 336
Jacking............................. 393
Life of Tires.......................... 341
Load Capacity.....................331,332
Off-Road............................. 86
Pressure Monitor System (TPMS)........... 347
Pressure Warning Light.................. 187
Quality Grading....................... 482
Radial.............................. 338
Replacement......................... 342
Rotation............................. 346
Safety...........................326,335
Sizes............................... 328
500 INDEX
