2008 DODGE DURANGO spark plugs replace

MAINTAINING YOUR VEHICLE
CONTENTS
mEngine Compartment 3.7L V6..............384
mEngine Compartment 4.7L V-8..............385
mEngine Compartment 5.7L HEMI V-8.........386
mOnboard Diagnostic System Ð OBD II........387
NLoose Fuel Filler Cap Message............388
mEmissions Inspection And Maintenance
Programs............................388
mReplacement Parts......................390
mDealer Service.........................390mMaintenance Procedures..................391
NEngine Oil..........................391
NEngine Oil Filter......................394
NDrive Belts Ð Check Condition And Tension . . 394
NSpark Plugs.........................395
NEngine Air Cleaner Filter................395
NEngine Fuel Filter.....................396
NCatalytic Converter....................396
NMaintenance Free Battery................397
7

belt tension can cause belt slippage and failure. Belts
should be inspected for evidence of cuts, cracks, glazing,
or frayed cords and replaced if there is indication of
damage which could result in belt failure. Low generator
belt tension can cause battery failure. Also check belt
routing to make sure there is no interference between the
belts and other engine components.
Spark Plugs
Spark plugs must fire properly to assure proper engine
performance and emission control. The plugs installed in
your vehicle should operate satisfactorily in normal
service for the mileage indicated in the Maintenance
Chart. New plugs should be installed at this mileage. The
entire set should be replaced if there is any malfunction
due to a faulty spark plug. Refer to Fluids, Lubricants
and Genuine Parts for the proper type of spark plug for
your vehicle.
CAUTION!
When replacing plugs, do not overtighten. You could
damage them and cause them to leak.
Engine Air Cleaner Filter
Follow the Maintenance Schedule for recommended en-
gine air cleaner filter change intervals.
WARNING!
The air cleaner can provide a measure of protection
in the case of engine backfire. Do not remove the air
cleaner unless such removal is necessary for repair or
maintenance. Make sure that no one is near the
engine compartment before starting the vehicle with
the air cleaner removed. Failure to do so can result in
serious personal injury.
MAINTAINING YOUR VEHICLE 395
7

Perform Maintenance Every(Where time and mileage
are listed, follow the interval that occurs first.)
Maintenance Items Miles Kilometers or Months
Replace the engine air cleaner filter. 30,000 50 000 30
Inspect the transfer case fluid. 30,000 50 000 30
Replace the top row of spark plugs on 4.7L engines.
**30,000 50 000 30
Replace the spark plugs on 3.7L and 5.7L engines.30,000 50 000 30
Drain and refill automatic transmission fluid and
change main sump filter (4.7L/5.7L engines only). This
applies only if your vehicle is used for police, taxi,
fleet, or frequent trailer towing.60,000 100 000 60
Drain and refill automatic transmission fluid, change
filter (3.7L engines). This applies only if your vehicle
is used for police, taxi, fleet, or frequent trailer towing.60,000 100 000 60
Change the transfer case fluid if using your vehicle for
any of the following: police, taxi, fleet, off-road or fre-
quent trailer towing.60,000 100 000 60
448 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Perform Maintenance Every(Where time and mileage
are listed, follow the interval that occurs first.)
Maintenance Items Miles Kilometers or Months
Change the manual transmission fluid if using your
vehicle for any of the following: trailer towing, snow-
plowing, heavy loading, taxi, police, delivery service
(commercial service), off-road, desert operation or
more then 50% of your driving is at sustained high
speeds during hot weather, above 90FÉ (32CÉ).60,000 100 000 60
Inspect and replace PCV valve if necessary. 90,000 150 000 90
Flush and replace the engine coolant. 102,000 170 000 60
Replace the ignition cables on 4.7L engines.102,000 170 000 102
Replace the side row of spark plugs on 4.7L engines.
**102,000 170 000 102
Drain and refill automatic transmission fluid, change
filter (3.7L engines).120,000 200 000 120
MAINTENANCE SCHEDULES 449
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
