Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
FUSE BLOCK
CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it suggests a
problem in the circuit that must be corrected.NOTE:If you are leaving your vehicle dormant for
longer than 21 days you may want to take steps to protect
your battery. You may do this by disconnecting the
battery or by disconnecting the two ignition-off draw
(I.O.D.) fuses located in the Auxiliary Power Distribution
Center (PDC) located in the engine compartment. The
I.O.D. cavities include a snap-in retainer that allows the
fuse to be disconnected, without removing it from the
fuse block. Pressing the I.O.D. fuse back into the cavity
reconnects it.
420 MAINTAINING YOUR VEHICLE

Fuses (Interior)
The fuse block contains blade-type mini-fuses, relays,
and circuit breakers for high-current circuits. It is located
in the left kick panel. It is accessible through a snap-in
cover.
MAINTAINING YOUR VEHICLE 421
7

Cavity Mini Fuse/Color Description
F1 15 Amp BlueInstrument Clus-
ter Battery Feed
F 2 10 Amp Red Spare
F3 10 Amp RedIgnition Run/
Start for Next
Generation Con-
troller (NGC),
Integrated
Power Module
(IPM), AC Relay
and Fuel Pump
Relay
F4 10 Amp RedDoor Node and
Non-Memory
Power Mirror
Switch Battery
FeedCavity Mini Fuse/Color Description
F5 (2) 10 Amp RedAirbags
(2 Fuses in Yel-
low Holder)
F6 2 Amp ClearIgnition Run/
Start Unlock
F7 25 Amp NaturalRadio Battery
Feed
F8 10 Amp RedIgnition Run/
Start for
Cluster/Transfer
Case/Seat Sw.
Back lighting
F9 10 Amp RedSatellite Digital
Audio Receiver
(SDAR)/Digital
Video Disc
(DVD) Battery
Feed
422 MAINTAINING YOUR VEHICLE

Cavity Mini Fuse/Color Description
F10 10 Amp Red Spare
F11 10 Amp Red Heated Mirrors
F12 20 Amp YellowCluster Battery
Feed
F13 10 Amp RedIgnition Run
HVAC Module/
Heated Rear
Glass (EBL) Re-
lay
F14 10 Amp RedABS Module Ig-
nition Run
F15 15 Amp BlueBattery Feed
Blue Tooth,
Compass/Trip
Computer
(CMTC), Sentry
Key DiagnosticsCavity Mini Fuse/Color Description
F16 20 Amp YellowReconfigurable
Power Outlets
F17 20 Amp YellowIgnition Run /
Rear Park Assist
/ Second Row
Heated Seats
F18 20 Amp YellowCigar Lighter
Ignition
F19 10 Amp Red Spare Fuse
F20 15 Amp BlueHeating & Air
Conditioning
w/ATC Only
Battery Feed
F21 25 Amp NaturalAmplifier Bat-
tery Feed
MAINTAINING YOUR VEHICLE 423
7

Fuses (Power Distribution Center)
Your vehicle is equipped with an electrical power distri-
bution center located in the left side of the engine
compartment.
This center contains cartridge fuses, mini fuses and
relays. A description of each fuse and component may bestamped on the inside cover otherwise the cavity number
of each fuse is stamped on the inside cover that corre-
sponds to the following chart. These fuses and relays can
be obtained from your dealer.
CavityCartridge
Fuse /
RelayMini
FuseDescription
1 30 Amp
PinkStarter
2 30 Amp
PinkFront Wiper
3 40 Amp
GreenBrake Batt
4 30 Amp
PinkJB Feed Acc # 2
5 40 Amp
GreenPower Seats
6 30 Amp
PinkRun Remote Relay
Feed
Power Distribution Center
424 MAINTAINING YOUR VEHICLE

CavityCartridge
Fuse /
RelayMini
FuseDescription
7 40 Amp
GreenBlower Motor Relay
Feed
8 40 Amp
GreenJB Feed Acc Delay
9 Spare
10 30 Amp
PinkASD
11 40 Amp
GreenPower Liftgate ( If
Equipped)
12 40 Amp
GreenJB Feed / Heated
Rear Glass (EBL)/ T
Case Brake
13 30 Amp
PinkJB Feed RR
14 40 Amp
GreenESP PumpCavityCartridge
Fuse /
RelayMini
FuseDescription
15 50 Amp
RedJB Feed
16 10 Amp
RedSpare
17 Spare
18 20 Amp
YellowFuel Pump
19 20 Amp
YellowNext Generation
Controller (NGC)
20 25 Amp
Clear115v Power Inverter
21 20 Amp
YellowABS Batt
22 20 Amp
YellowNext Generation
Controller (NGC)
Batt
MAINTAINING YOUR VEHICLE 425
7

CavityCartridge
Fuse /
RelayMini
FuseDescription
23 20 Amp
YellowTrailer Tow
24 15 Amp
BlueA/C Clutch
25 15 Amp
BlueStop Lamp Switch
26 Spare
27 20 Amp
YellowRun/Start Relay
Feed
28 Spare
29 Relay Run Start
30 Relay Run Remote
31 SpareCavityCartridge
Fuse /
RelayMini
FuseDescription
32 Relay Starter
33 Relay Electronic Auto-
matic Transaxle
(EATX)
34 Relay AC Clutch
35 Relay Fuel Pump Rly
36 Spare
37 Relay Stop Lamp Switch
38 Spare
39 Relay Blower Motor
40 Relay Auto Shut Down
(ASD) Rly
426 MAINTAINING YOUR VEHICLE

Fuses (Integrated Power Module)
An integrated Power Module is located in the left side of
the engine compartment. This center contains cartridge
fuses, mini fuses and relays. A description of each fuse
and component may be stamped on the inside coverotherwise the cavity number of each fuse is stamped on
the inside cover that corresponds to the following chart.
CavityCartridge
Fuse /
RelayMini
FuseDescription
1 Relay Wiper On/Off Rly
2 Relay Wiper Hi/Lo Rly
3 Relay Horn Rly
4 Relay Rear Wiper Rly
5 Relay Lt Trailer-Tow Stop/
Turn Rly
6 Relay Rt Trailer-Tow
Stop/Turn Rly
7 Relay Park Lamps Rly
8 10 Amp
RedLt Park Lamps
9 10 Amp
RedTrailer-Tow Park
Lamps
Integrated Power Module
MAINTAINING YOUR VEHICLE 427
