2008 DODGE CHARGER turn signal

vehicle may need to be driven for up to 10 minutes above
15 mph (25 km/h) in order for the TPMS to receive this
information.
Check TPMS Warning
If a system fault is detected, the Tire Pressure Monitoring
Telltale Light will flash on and off for 75 seconds and then
remain on solid. The system fault will also sound a
chime. If the ignition key is cycled, this sequence will
repeat, providing the system fault still exists. The Tire
Pressure Monitoring Telltale Light will turn off when the
fault condition no longer exists. A system fault can occur
due to any of the following:
1. Signal interference due to electronic devices or driving
next to facilities emitting the same Radio Frequencies as
the TPM sensors.
2. Installing aftermarket window tinting that contains
materials, which may block radio wave signals.3. Accumulation of snow or ice around the wheels or
wheel housings.
4. Using tire chains on the vehicle.
5. Using wheels/tires not equipped with TPM sensors.
NOTE:
Vehicles with Full Size Spare
1. The matching full size spare wheel and tire assembly
has a tire pressure monitoring sensor that can be moni-
tored by the TPMS.
2. If you install the full size spare in place of a road tire
that has a pressure below the low-pressure warning limit,
upon the next ignition key cycle, a chime will sound and
the TPM Telltale Light will turn ON.
3. Driving the vehicle for up to 10 minutes above 15 mph
(25 km/h) will turn off the TPM Telltale Light, as long as
no tire pressure is below the low-pressure warning limit
in any of the four active road tires.
STARTING AND OPERATING 313
5

1. Signal interference due to electronic devices or driving
next to facilities emitting the same Radio Frequencies as
the TPM sensors.
2. Installing aftermarket window tinting that contains
materials, which may block radio wave signals.
3. Accumulation of snow or ice around the wheels or
wheel housings.
4. Using tire chains on the vehicle.
5. Using wheels/tires not equipped with TPM sensors.
NOTE:
Vehicles with Full Size Spare
1. The matching full size spare wheel and tire assembly
has a tire pressure monitoring sensor that can be moni-
tored by the TPMS.2. If you install the full size spare in place of a road tire
that has a pressure below the low-pressure warning limit,
upon the next ignition key cycle, a chime will sound and
the TPM Telltale Light will turn ON. In addition, the
EVIC will display a Low Pressure message and a graphic
showing the low tire pressure value flashing.
3. After driving the vehicle for up to 10 minutes above 15
mph (25 km/h) the TPM Telltale Light will turn OFF, as
long as no tire pressure is below the low-pressure warn-
ing limit in any of the four active road tires.
NOTE:
Vehicles with Compact Spare
1. The compact spare tire does not have a tire pressure
monitoring sensor. Therefore, the TPMS will not monitor
the pressure in the compact spare tire.
2. If you install the compact spare tire in place of a road
tire that has a pressure below the low-pressure warning
limit, upon the next ignition key cycle, the TPM Telltale
STARTING AND OPERATING 317
5

WARNING!
Do not connect trailer brakes to your vehicle's hy-
draulic brake lines. It can overload your brake sys-
tem and cause it to fail. You might not have brakes
when you need them and could have an accident.
Towing any trailer will increase your stopping dis-
tance. When towing, you should allow for additional
space between your vehicle and the vehicle in front
of you. Failure to do so could result in an accident.
Towing Requirements Ð Trailer Lights & Wiring
Whenever you pull a trailer, regardless of the trailer size,
stoplights and turn signals on the trailer are required for
motoring safety.
The Trailer Tow Package may includea4and7pin
wiring harness. Use a factory approved trailer harness
and connector.
NOTE:Do not cut or splice wiring into the vehicles
wiring harness.
STARTING AND OPERATING 339
5

HAZARD WARNING FLASHER
The hazard flasher switch is located in the center of the
instrument panel below the center air outlets.To engage the Hazard Warning Flashers, depress the
switch on the instrument panel. When the Hazard Warn-
ing Switch is activated, all directional turn signals will
flash on and off to warn oncoming traffic of an emer-
gency. Push the switch a second time to turn off the
flashers.
This is an emergency warning system and it should not
be used when the vehicle is in motion. Use it when your
vehicle is disabled and it is creating a safety hazard for
other motorists.
When you must leave the vehicle to seek assistance, the
Hazard Warning Flashers will continue to operate even
though the ignition switch is OFF.
NOTE:With extended use, the Hazard Warning Flash-
ers may wear down your battery.
Hazard Flasher Switch
344 WHAT TO DO IN EMERGENCIES

Oil Filter Disposal...................... 378
Oil Selection.......................376,419
Oil Synthetic......................... 377
Operation............................ 74
Overheating.......................... 345
Starting............................. 255
Temperature Gauge..................... 165
Engine Oil Viscosity...................376,377
Enhanced Accident Response Feature.......... 61
Entry System, Illuminated.................. 20
Ethanol............................... 320
Event Data Recorder...................... 63
Exhaust Gas Caution..............75,76,322,387
Exhaust System.......................75,387
Exterior Folding Mirrors................... 85
Exterior Lighting........................ 123
Exterior Lights.......................... 78
Filler Location Fuel...................... 323Filters
Air Cleaner.......................... 379
Air Conditioning....................248,384
Engine Fuel.......................... 379
Engine Oil........................378,421
Engine Oil Disposal.................... 378
Flashers
Hazard Warning....................... 344
Turn Signal......................78,127,166
Flash-To-Pass........................... 128
Flat Tire Changing....................... 346
Flooded Engine Starting................... 257
Floor Console.......................... 153
Fluid, Brake........................... 423
Fluid Capacities......................... 419
Fluid Leaks............................. 78
Fluid Level Checks
Automatic Transmission................. 396
Brake............................... 395
450 INDEX

Key, Sentry (Immobilizer)................... 15
Key-In Reminder......................... 15
Keyless Entry System...................... 20
Keys................................. 12
Knee Bolster............................ 50
Lane Change and Turn Signals.............. 127
Lap/Shoulder Belts....................... 41
LATCH (Lower Anchors and Tether for
CHildren)............................68,70
Latch Plate............................. 42
Latches................................ 78
Hood............................... 121
Lead Free Gasoline...................... 319
Leaks, Fluid............................ 78
Life of Tires............................ 304
Light Bulbs..........................78,412
Lights..............................78,123
Airbag........................57,62,77,167Anti-Lock.........................173,282
Automatic Headlights................... 124
Brake Assist Warning................... 289
Brake Warning.....................170,280
Bulb Replacement...................412,413
Courtesy/Reading...................128,139
Cruise.............................. 164
Daytime Running...................... 126
Dimmer Switch, Headlight.............126,127
Electronic Stability Program (ESP)
Indicator...........................286,289
Electronic Throttle Control Warning......... 165
Engine Temperature Warning.............. 167
Exterior.............................. 78
Fog .............................126,168
Hazard Warning Flasher................. 344
Headlight Switch...................... 123
Headlights........................... 123
Headlights On Reminder................. 126
454 INDEX

Headlights On With Wipers............125,131
High Beam........................127,168
High Beam Indicator.................... 168
High Beam/Low Beam Select............. 127
Illuminated Entry....................... 20
Instrument Cluster..................123,164
Intensity Control....................... 129
Interior..........................128,139
License............................. 418
Lights On Reminder.................... 126
Low Fuel............................ 174
LowTire ............................ 172
Malfunction Indicator (Check Engine)........ 174
Map Reading......................128,139
Oil Pressure.......................... 168
Parade Mode (Daytime Brightness).......... 129
Passing............................. 128
Reading..........................128,139
Seat Belt Reminder..................... 168Service...........................412,413
Service Engine Soon (Malfunction Indicator) . . . 174
Tire Pressure Monitoring (TPMS)........172,309
Traction Control....................... 289
Turn Signal...................78,126,127,166
Vanity Mirror.......................... 87
Voltage............................. 165
Warning (Instrument Cluster Description)..... 164
Load Leveling System.................... 156
Loading Vehicle......................326,327
Capacities........................... 327
Tires ............................... 294
Locks................................. 28
Auto Unlock.......................... 31
Automatic Door........................ 30
Child Protection........................ 32
Door................................ 28
Power Door........................... 29
Low Tire Pressure System.................. 309
INDEX 455
10

Setting the Clock................192,196,211,215
Settings, Personal........................ 186
Shifting............................... 258
Automatic Transmission............258,262,267
Shoulder Belt Upper Anchorage.............. 46
Shoulder Belts........................... 41
Side Airbag...........................52,58
Side Curtain (Window Airbag)............... 52
Signals, Turn......................78,127,166
Slippery Surfaces, Driving On............... 275
Snow Chains (Tire Chains)................. 307
Snow Tires............................ 308
Sound Systems (Radio).................191,209
Spare Tire..........................302,348
Spark Plugs.........................379,421
Specifications
Fuel (Gasoline)........................ 421
Oil ................................ 421
Speed Control (Cruise Control).............. 135Speedometer........................... 164
Starting.............................26,255
Automatic Transmission................. 256
Cold Weather......................... 256
Emergency (Jump Starting)............... 356
Engine Fails to Start.................... 257
Remote.............................. 26
Starting and Operating.................... 255
Starting Procedures...................... 255
Steering
Column Controls...................... 126
Column Lock......................... 133
Linkage............................. 385
Power...........................282,384
Tilt Column.......................... 133
Wheel, Tilt........................... 133
Steering Wheel Mounted Sound System
Controls.............................. 237
Storage............................153,411
INDEX 461
10
