2008 DODGE AVENGER fuse

Cavity Car-
tridge
Fuse Mini
Fuse Description
24 Ð 25 Amp
Clear Battery Feed Ð PWR
Sunroof Feed
25 Ð 10 Amp
Red Ignition Run Ð
Heated Mirrors - If
Equipped
26 Ð 15 Amp
Lt. Blue Auto Shutdown
(ASD) Relay Feed 2
27 Ð 10 Amp
Red Ignition Run Ð Occu-
pant Classification
Module (OCM)/
Occupant Restraint
Controller (ORC) Cavity Car-
tridge
Fuse Mini
Fuse Description
28 Ð 10 Amp
Red Ignition Run Ð Occu-
pant Classification
Module (OCM)/
Occupant Restraint
Controller (ORC)
29 Ð Ð Hot Car (No Fuse Re-
quired)
30 Ð 20 Amp
Yellow Ignition Run Ð
Heated Seats - If
Equipped
31 Ð 10 Amp
Red Ð
32 30 Amp
Pink Ð Auto Shutdown
(ASD) Relay Feed 1 MAINTAINING YOUR VEHICLE 409
7

Cavity Car-
tridge
Fuse Mini
Fuse Description
33 Ð 10 Amp
Red Battery Feed Ð
Switch Bank/
Diagnostic Link
Connector/
Powertrain Control
Module (PCM)
34 30 Amp
Pink Ð Battery Feed Ð Anti-
Lock Brakes (ABS)
Module - if
equipped/Electronic
Stability Program
(ESP) Module - If
Equipped Cavity Car-
tridge
Fuse Mini
Fuse Description
35 40 Amp
Green Ð Battery Feed Ð Anti-
Lock Brakes (ABS)
Module - If
Equipped/Electronic
Stability Program
(ESP) Module - If
Equipped
36 30 Amp
Pink Ð Battery Feed Ð Pas-
senger Door Module
(PDM)/Driver Door
Module (DDM)
37 Ð 25 Amp
Clear Ð410 MAINTAINING YOUR VEHICLE

CAUTION!² When installing the Totally Integrated Power
Module cover, it is important to ensure the cover is
properly positioned and fully latched. Failure to
do so may allow water to get into the Totally
Integrated Power Module, and possibly result in
an electrical system failure.
² When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected. VEHICLE STORAGE
If you will not be using your vehicle for more than 21 days,
you may want to take steps to preserve your battery.
² Disengage the mini-fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
² Disconnect the negative cable from the battery.
REPLACEMENT BULBS
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.
LIGHT BULBS Ð Interior Bulb Number
Front Courtesy/Reading Lights .......... 578/W5W
Center Courtesy/Reading Lights ......... 578/W5W
Visor Vanity Lights ..................... A6220
Glove Box Light ......................... 194
Shift Indicator Light ................. JKLE14140
Rear Compartment (Trunk) Light ............. 579 MAINTAINING YOUR VEHICLE 411
7

Fuel System Caution ..................... 329
Fueling ............................... 328
Fuses ................................ 406
Garage Door Opener (HomeLink t ) ........... 143
Gas Cap (Fuel Filler Cap) ............ 328,330,371
Gasoline, Clean Air ...................... 320
Gasoline (Fuel) ......................... 319
Gasoline, Reformulated ................. 320,321
Gauges
Coolant Temperature .................... 170
Fuel ................................ 170
Odometer ........................... 172
Tachometer .......................... 172
Gearshift .............................. 270
General Information ................. 17,115,319
General Maintenance ..................... 374
Glass Cleaning .......................... 404
Glove Compartment ...................... 161 Gross Axle Weight Rating ............... 332,335
Gross Vehicle Weight Rating ............. 332,334
GVWR ............................... 332
Hands-Free Phone (UConnectŸ) ........ 89,223,224
Hard Drive (HDD) .................... 220,223
Hazard
Driving Through Flowing, Rising, or Shallow
Standing Water ........................ 289
Hazard Warning Flasher ................... 348
Head Restraints ......................... 125
Headlights ............................ 412
Bulb Replacement ...................... 412
Cleaning ............................ 402
High Beam ........................ 134,179
High Beam/Low Beam Select Switch ........ 134
On With Wipers ....................... 137
Passing ............................. 131
Switch .............................. 130 INDEX 451
10

Heated Seats ........................... 123
Heater ............................... 242
Heater, Engine Block ..................... 266
Hitches
Trailer Towing ........................ 336
HomeLink t (Garage Door Opener) Transmitter . . . 143
Hood Prop ............................ 128
Hood Release .......................... 127
Hoses ................................ 394
Ignition ............................... 12
Key ................................. 12
Ignition Key Removal ..................... 12
Illuminated Entry ........................ 20
Immobilizer (Sentry Key) ................... 14
Infant Restraint ...................... 67,68,69
Information Center, Vehicle ................. 181
Inside Rearview Mirror .................... 85
Instrument Cluster .................... 168,170 Instrument Panel and Controls .............. 167
Instrument Panel Cover ................... 403
Instrument Panel Lens Cleaning ............. 405
Integrated Power Module (Fuses) ............ 406
Interior Appearance Care .................. 403
Interior Lights .......................... 129
Intermittent Wipers (Delay Wipers) ........... 136
Introduction ............................. 4
Jack Location ........................... 351
Jack Operation ....................... 350,352
Jacking Instructions ...................... 352
Jump Starting .......................... 358
Key, Programming ........................ 16
Key, Replacement ........................ 16
Key, Sentry (Immobilizer) ................... 14
Key-In Reminder ......................... 14
Keyless Entry System ...................... 21452 INDEX

Paint Care ............................. 400
Panic Alarm ............................ 25
Parking Brake .......................... 276
Passing Light ........................... 131
Personal Settings ........................ 188
Pets .................................. 77
Phone, Cellular .................... 89,223,224
Phone, Hands-Free (UConnectŸ) ........ 89,223,224
Placard, Tire and Loading Information ......... 295
Port
Universal Serial Bus (USB) ............. 220,223
USB ............................. 220,223
Power
Distribution Center (Fuses) ............... 406
Door Locks ........................... 32
Mirrors .............................. 86
Outlet (Auxiliary Electrical Outlet) .......... 153
Seats ............................... 123
Steering ............................. 287 Steering, Checking ..................... 385
Sunroof ............................. 150
Windows ............................. 35
Power Steering Fluid ..................... 385
Pregnant Women and Seat Belts .............. 50
Preparation for Jacking .................... 352
Pretensioners
Seat Belts ............................. 48
Programmable Electronic Features ............ 188
Programming Transmitters
(Remote Keyless Entry) .................... 26
Radial Ply Tires ......................... 302
Radiator Cap (Coolant Pressure Cap) .......... 391
Radio Broadcast Signals ................... 191
Radio, Navigation ....................... 223
Radio Operation ................... 221,224,241
Radio Remote Controls .................... 236
Radio, Satellite .............. 220,221,223,224,231456 INDEX

INSTALLATION OF RADIO TRANSMITTING
EQUIPMENT
Special design considerations are incorporated into this
vehicle's electronic system to provide immunity to radio
frequency signals. Mobile two-way radios and telephone
equipment must be installed properly by trained person-
nel. The following must be observed during installation.
The positive power connection should be made directly
to the battery and fused as close to the battery as possible.
The negative power connection should be made to body
sheet metal adjacent to the negative battery connection.
This connection should not be fused.
Antennas for two-way radios should be mounted on the
roof or the rear area of the vehicle. Care should be used
in mounting antennas with magnet bases. Magnets may
affect the accuracy or operation of the compass on
vehicles so equipped. The antenna cable should be as short as practical and
routed away from the vehicle wiring when possible. Use
only fully shielded coaxial cable.
Carefully match the antenna and cable to the radio to
ensure a low Standing Wave Ratio (SWR).
Mobile radio equipment with output power greater than
normal may require special precautions.
All installations should be checked for possible interfer-
ence between the communications equipment and the
vehicle's electronic systems.
