READY TO SET OFF
Gearbox and steering wheel
Stopping – Starting on a gradient
This is an electronic gearbox system without
a clutch pedal.
To immobilise the vehicle on a gradient,
you must use the parking brake and not
the accelerator.
When starting on a gradient, accelerate
gradually while releasing the parking brake.
Changing to sequential mode
Once you have started the engine, you
can go into sequential mode by selecting
position M.
“AUTO” disappears and
the gears selected appear
successively on the instrument
panel display.
Gear change requests are only possible if
the engine speed allows them.
Gently lift your foot from the accelerator
pedal to select the gear.
When driving at low speed (e.g. approaching
a stop sign or at traffic lights), the gearbox
automatically changes down to first gear.
Changing to automatic mode
When in sequential mode, you can return to
automatic mode by selecting position A.
Stopping the vehicle
Before switching off the engine, you can :
- select position N to engage neutral.
- leave a gear engaged, such as first or
reverse gear.
In either case, you must engage the parking
brake to immobilise the vehicle.
Reinitialising
Following a battery disconnection, you must
reinitialise the gearbox :
- switch on the ignition, “AUTO” appears
on the instrument panel display,
- press on the brake pedal,
- wait for about 30 seconds until “N” or
a gear appears on the instrument panel
display,
- release the brake pedal.
The gearbox is now operational again.
Operating anomaly
With the ignition switched on, the fl ashing of “AUTO” and the lighting of this warning lamp, accompanied by a sound signal and a message on the instrument panel display, indicate a
gearbox malfunction.
Have the system checked by your CITROËN dealer.
You must always press the brake pedal
down when starting the engine.
When the vehicle is moving, never
select neutral N.
Only select reverse gear R with the vehicle
stationary and your foot on the brake pedal.
In all cases, you must engage the parking
brake to immobilise the vehicle.
When on a steep gradient, you are advised
to use sequential mode.
“AUTO” is displayed and the
gear selected appears on the
instrument panel display.
The gearbox operates in
automatic mode, without the need for driver
intervention.
It always selects the gear best suited to the
following parameters :
- driving style,
- road profile,
- vehicle load.
To maximise driving comfort and obtain the
most suitable gear, avoid making rough
movements on the accelerator pedal.
If you press the accelerator beyond the point
of resistance, the gearbox selects the next
gear down to allow for faster acceleration.

53
3
IN-CAR TECHNOLOGY
Trip computer
TRIP COMPUTER
The TRIP button, located at the end of
the wipers stalk, provides access to the
following information: - Range,
- Route A,
- Average consumption A,
- Current consumption A,
- Average speed A,
- Trip duration A. If TRIP B is activated on
MENU :
- Route B,
- Average consumption B,
- Average speed B,
- Trip duration B.
Level 1 display:
- Speed (Speed bleep).
- Hour (Setting of the time).
- Buzz (Volume of the announcements).
- Unit (Unit of measurement).
- Bag p (Passenger air bag).

Refer to the corresponding line in the configuration – personalisation table on the following pages.

54
Menu
MENU

This button enables you to:
- access the menus and sub-menus,
- confirm your selections within a menu,
- exit from the menus.
A long press enables you to return to the welcome screen.

This button enables you to:
- scroll up through a menu,
- increase a value.

This button enables you to:
- scroll down through a menu,
- decrease a value.

Menu... Press...
Sub-
menu...
Press... Select...
Confirm
and exit
Enables you to...

1 Speed Bleep ON Increase
Activate/deactivate the audible
signal indicating exceeding of the
programmed speed and select the
speed value.
Decrease
OFF

2 Activate
Trip B ON Activate
Display a second route “Trip B”.
OFF
Confi guration - Personalisation

Level 2 display:
The control pad located to the left of the
steering wheel provides access to display 2
menus which permit the personalisation of
some of your equipment.
Eight languages are offered: Italian, English,
German, French, Spanish, Portuguese,
Dutch and Turkish.
As a safety precaution, the menus can only
be accessed when the ignition is off (engine
off).
Refer to the corresponding line in the configurati on – personalisation table on the following
pages.

55
3
IN-CAR TECHNOLOGY
Menu
Menu...
Press... Sub-menu... Press... Select...
Confirm
and exit
Enables you to...

3 Set the time Hours
Increase
Set the clock.
Decrease
Format 24 hour
Select the clock display mode.
12 hour

4 Set the date Year/Month/Day Increase
Set the date.
Decrease

5 See radio ON
Display the name of the station.
OFF

6 Autoclose While moving ON
Activate/Deactivate the
automatic locking of the doors
above 12 mph (20 km/h)
OFF

7 Measurement
unit Distances
Km
Select the distance display unit.
Mi(les)
Temperature °C
Select the temperature display
unit.
°F
Consumption km/l
Select the consumption display
unit.
l/100 km

8 Language List of languages
available
Select the display language.

9 Volume of an-
nouncements Increase
Increase/decrease the
volume (the volume changes
immediately when the button is
pressed).
Decrease

56
Menu
Menu...
Press... Sub-menu... Press... Select...
Confirm
and exit
Enables you to...

10 Volume of
the buttons Increase
Increase/decrease the volume
of the buttons.
Decrease

11 Service (Km/Miles
before oil
change) Display the kilometres/miles
remaining before the next oil
change.
Display the oil level.

12 Bag
(passenger
air bag) ON
Yes
Activate the passenger air bag.
No
OFF Yes
Disarm the passenger air bag.
No

13 Exit from
menu Exit from the menu. Press the
arrow at the bottom to go to
the first menu.

57
3
IN-CAR TECHNOLOGY
Parking assistance
AUDIBLE REAR PARKING ASSISTANCE
The audible system consists of four
proximity sensors, installed in the rear
bumper.
It detects any obstacle which enters the
field: person, vehicle, tree, fence, behind the
vehicle during the manoeuvre.
However, it will not be able to detect
obstacles located immediately below the
bumper.
An object, such as a stake, a roadworks
cone or any other similar object may be
detected at the beginning of the manoeuvre
but may no longer be detected when the
vehicle moves close to it. Stop the assistance
Change to neutral.
Operating fault
If this warning lamp or the service
warning lamp lights up on the
instrument panel, accompanied
by a message on the display,
contact your CITROËN dealer.
Good practice
In bad weather or in winter, ensure that the
sensors are not covered with mud, ice or
snow.
Engage reverse gear
The proximity information is indicated by an
audible signal which becomes more rapid as
the vehicle approaches the obstacle.
When the distance between the rear of
the vehicle and the obstacle is less than
approximately thirty centimetres, the audible
signal becomes continuous.
This function will be deactivated
automatically if a trailer is being towed.
You are advised to obtain a towbar
recommended by CITROËN and have it
installed by a professional.
If anomalies are detected on engaging
reverse gear, the warning light comes on,
possibly accompanied by a message on the
display.

59
3
IN-CAR TECHNOLOGY
Audio equipment
“AUDIO FUNCTIONS MENU”
Press the MENU button of the
radio system to access the
“Audio Functions” menu.
Press the “  ” or “  ” button
to select one of the audio
functions to be configured as
below.
RDS System “AF Switching”
The RDS system (Radio Data System)
allows you to keep listening to the same
station, whatever the frequency it uses in
different areas where you may be driving.
The radio permanently searches for the
transmitter offering the best reception.
Press on the “  ” or “  ” button to activate
(ON) or deactivate (OFF) the RDS function.
When on the FM band, “AF” appears on the
display, if the RDS function is activated and
if the station broadcasts on RDS.
Traffi c Information “Traffi c Info”
Any traffic news will be broadcast whatever
audio source you are currently listening to.
The EON system (Enhanced Other
Networks) links stations belonging to the
same network.
Regional tracking mode “Regional Mode”
Some stations, organised by network,
broadcast regional programmes in the
various regions that they serve. The regional
tracking mode allows you to prioritise
listening to the same programme.
Press on the “  ” or “  ” button to activate (ON)
or deactivate (OFF) the REG function.
When on the FM band, “LOC” is displayed,
if the REG function is activated and if the
station finds a local frequency.
MP3 Display “MP3 Display”
Press on the “  ” or “  ” button to display
the track number or the MP3 CD information
(Play / Album / Folder / File / Title / Time
elapsed).
Automatic volume adjustment “Speed Volume”
Press on the “  ” or “  ” button to minimise
(LOW), maximise (HIGH) or deactivate
(OFF) the automatic volume adjustment
according to the speed of the vehicle.
It allows traffic information to be broadcast
from a station belonging to the same
network as the station being listened to.
The volume of traffic information is
independant of the volume of other audio
sources. You can adjust it using the volume
button whilst it is being broadcast; this will
be memorised for the next broadcast.
Press on the “  ” or “  ” button to activate (ON)
or deactivate (OFF) the TA function.
When on the FM band, “TA” appears on
the display if the TA function is activated
and “TPM” if the station broadcasts traffi c
information.
External sound volume “External Audio Vol”
Press on the “  ” or “  ” button to reduce
(down to 0), increase (up to 40) or
deactivate (OFF) the volume of the external
source (e.g. hands-free kit).
Programmed switch off “Radio Off”
Press on the “  ” or “  ” button to set
the time for switching off to “00 MIN” or
“20 MIN”.
This countdown is recorded with the doors
closed, and the key in position STOP.
Default values “Restore Default”
Press on the “  ” or “  ” button to retain the
modified values (NO) or reset to the default
values (YES).
“Restoring” is displayed during the resetting
of the configuration values.
“MP3” is displayed if the function is activated
and if the CD contains tracks in MP3 format.

22
11
60
Audio equipment
CD
PLAYING A CD OR AN MP3 COMPILATION
Insert circular compact discs only.
Some anti-pirating systems, on original
discs or CDs copied using a personal
recorder, may cause faults which are no reflection on the
quality of the original player.
Insert a CD or an MP3 compilation in
the player, play begins automatically.
If the player already contains a disc,
press the CD button.
Press one of the buttons to select a
track on the CD. The MP3 format, an abbreviation of MPEG 1.2 & 2.5
Audio
Layer 3, is an audio compression standard which per mits the
recording of several tens of music files on a singl e disc.
MP3
In order to be able to play a recorded CDR or CDRW , when
recording it is preferable to select standards ISO 9660
level 1.2 or Joliet.
If the disc is recorded in another format, it may not be played
correctly.
It is recommended that the same recording standard is
always used for an individual disc, with as low a s peed as
possible (4x maximum) for optimum sound quality.
In the particular case of a multi-session CD, the Joliet
standard is recommended.
The audio equipment will only play files with the extension
“.mp3” with a sampling rate of 22.05 KHz or 44.1 KH z.No
other type of file (.wma, .mp4, m3u...) can be play ed.
It is advisable to restrict file names to 20 chara cters without
using special characters (e.g.: “
” ? ; ) to avoid any playing or
displaying problems.
