2008 Citroen C3 PLURIEL DAG Owner's Manual

D
23
A
C
B
E
EDCB
AE
1
II
35
M U L T I F U N C T I O N D I S P L A Y
D I S P L A Y A
The driver is recommended not to concern himself with the display controls while driving.1. Time.2. Date - Display zone.3. Outside temperature.
When the outside temperature is between +3 °C and –3 °C, the temperature display fl ashes (risk of ice).Note: The outside temperature displayed may be higher than the actual temperature if the vehicle is stationary in bright sunlight.
Remark: The display of certain types of information is sometimes scrolled and sometimes alter-nated.
ControlsA. Access to the “Main menu” of the display.B. Scroll through display menus.C. Validation and Selection in the menus, of the function chosen or value modifi ed.D. Cancellation of the operation or return to the previous display.E. Selection of the type of infor-mation displayed in zone 2(date, radio/CD and trip com-puter).E. In the Menus, choice of acti-vation/deactivation of your functions and choice of your adjustments.
Main Menu
By pressing control A then B, you have access to the following func-tions:
Radio-CD (See radio-CD hand-book).
Vehicle confi guration, to acti-vate/deactivate:The automatic guide-me-home lighting.Automatic lighting of head-lamps.Options, to display the alerts.
Display adjustments, to adjust the date and time on the dis-play.
Languages, to select the dis-play language.Units, to access the choices of units of Temperature and Fuel Consumption.

D
A
C
B
E
EDCB
AE
II
36
M U L T I F U N C T I O N D I S P L A Y
D I S P L A Y A
Personalisation/Confi guration
To activate/deactivate the auto-matic guide-me-home lighting:Press button A.
Select, using B, the sub-menu to personalise-confi gure your vehicle, then confi rm your choice with a press on C.Select guide-me-home lighting, using B.
The system tells you the status (active or inactive) of the func-tion. Modify this status with a press on E.
Then please wait for the display to disappear.

D
A
C
B
E
EDCB
AE
II
37
M U L T I F U N C T I O N D I S P L A Y
D I S P L A Y A
To choose the language:Press button A.
Using B, select the sub-menu for Languages. Confi rm your choice with a press on C.By presses on E, select the lan-guage of your choice.
Then please wait for the display to disappear.
To choose units:Press button A.Using B, select the sub-menu for Units. Confi rm your choice with a press on C.
Using B, select the unit you wish to modify (Temperature or Consumption).
Via presses on E, select the unit of your choice.Then please wait for the display to disappear.Note: This choice concerns all the types of information (fuel con-sumption, speed, etc.) that appear on the displays.

EDCB
AE
231
II
38
M U L T I F U N C T I O N D I S P L A Y
D I S P L A Y C
The driver is recommended not to concern himself with the display controls while driving.1. Time.2. Outside temperature.3. Date - Display zone.
When the outside temperature is between +3 °C and –3 °C, the temperature display fl ashes (risk of ice).
ControlsA. Access to the “Main menu” of the display.B. Scroll through display menus.C. Validation and Selection in the menus, of the function chosen or value modifi ed.D. Cancellation of the operation or return to the previous display.E. Selection of the type of infor-mation you wish to see perma-nently displayed (date, radio-CD, trip computer) on the right of the screen.
Main Menu
Press on button A to bring up the “Main menu” of the multifunc-tion display. This menu gives you access to the following functions:
Radio-CD
(See radio-CD handbook).
Trip computer, giving you:Entering the distance to the destination
Access to the log of alerts (recall of the alerts signalled previously.
Access to status of functions, for example activation/deacti-vation of automatic lighting of headlamps, ESP, windscreen wipers.

EDCB
AE
II
39
M U L T I F U N C T I O N D I S P L A Y
D I S P L A Y C
Trip computer
To enter the distance to be trav-elled on the trip computer:Press button A.Use B to select the icon “Trip computer”, then confi rm with a press on C.
Select entry of distance using B. Confi rm your choice with a press on C.
To choose the distance, select the fi gure you wish to modify by using B, then confi rm with a press on C.Use B to adjust the value, then validate by pressing C.
Validate “OK” on the screen.
To access the trip computer's log of alerts:Press button A.Use B to select the icon “Trip computer”, then confi rm with a press on C.
Select the log of alerts.
When the list displays, use B to scroll through it.Press D to return to the perma-nent display.
To access the status of functions: proceed in a similar manner.

EDCB
AE
II
40
To adjust the display brightness:Press button A.
Use B to select the icon “Per-s o n a l i s a t i o n - C o n f i g u r a t i o n ” then confi rm your choice by pressing C.Select the display confi guration with a press on B. Confi rm your choice with a press on C.
Select the brightness adjust-ment. Confi rm your choice with a press on C.
Select with a press on B, then validate by pressing C, the nor-mal or alternative display mode. To adjust the brightness, select the symbols “+” or “–” and con-fi rm your adjustment by press-ing C.
Validate “OK” on the screen.

II
41
T R I P C O M P U T E R
For selection and display of the various types of information, give short presses on the end of the windcsreen wiper stalk.
Instrument panel (For a ver-sion with digital clock)
The trip computer provides 4 types of information on the instrument panel, following the display of trip mileage:Range.
Instantaneous consumption.
Average consumption.Average speed.
Remark: If the cruise control / speed limiter is in operation, the display of trip computer information disappears after a few seconds.

II
42
The trip computer gives access to 3 types of instantaneous information:Range.
Instantaneous consumption.Distance remaining to be travelled.
The trip computer also gives access to 3 types of information for 2 Journeys 1 and 2:The distance travelled.
Average consumption.Average speed.
The Journeys
Journeys 1 and 2 are independent of each other but identical in use. For example you can allocate Journey 1 to daily calculations and Journey 2 to monthly calculations.
Resetting a Journey to zero
When the desired Journey is displayed, give a long press on the end of the wiper control stalk.
Remark:
After a re-initialisation of the trip computer, the indication of range only becomes signifi cant after a certain period of use.
