8
Interior
INSTRUMENTS AND CONTROLS
1. Lights and direction indicators
stalk.
2. I n s t r u m e n t p a n e l w i t h d i s p l a y .
3. Wipers, wash-wipe, trip
computer controls.
4. I g n i t i o n .
5. Audio equipment, hands-free kit
control.
6. Driver’s air bag, horn.
7. Steering wheel height and depth
adjustment.
8. Cruise control, speed limiter
switch.
9. Control pad, parking assistance,
headlamp beam adjustment,
ESP.
10. Bonnet release.
11. Electric exterior mirror
adjustment.
Page 6 of 153
3
53
2
3
10
Interior
Storage compartments
These are placed under the front
seats. For greater ease, reach behind
the seat to access them.
The tool kit and the jack are stored
under the right-hand seat and can be
accessed from the rear.
Steering wheel
Adjust the height and depth
of the steering wheel.
Mirrors
Manual adjustments.
Electric adjustments.
Seat belts
Height adjustment.
Fastening.
1.
Forwards-backwards
adjustment.
2. Angle.
3. Height. 4. Head restraint
height and
angle.
Driver’s seat
57 63
37
73
97
SIT COMFORTABLY
Page 18 of 153
22
Accesses
REAR ROOF FLAP
T h i s r e a r r o o f fl a p i s o n l y c o m p a t i b l e
with the hinged doors.
T o o p e n t h e r e a r r o o f fl a p :
- raise the black paddle of the toggle,
- relieve the toggle by pressing the r e a r r o o f fl a p ( d o w n w a r d s ) t h e n
release the hook,
- l i f t t h e r e a r r o o f fl a p ,
- pass the point of resistance to s e c u r e t h e r e a r r o o f fl a p u s i n g t h e
support struts. Support bar
A support bar is provided for
transporting long loads, after opening
t h e r e a r r o o f fl a p .
Fold back the support bar by lifting the
lever.
Support it to the door pillar.
Support the long loads to be
transported, lift them and reposition the
support bar with one hand.
Ensure that it is secured correctly by
pressing the handle downwards past
the point of resistance and secure the
l o a d s fi r m l y . The rear bumper has been
strengthened to serve as a
footrest on entering the vehicle.
Never drive without the support
bar in place.
The rear doors only lock when the
support bar is installed.
W h e n t h e r e a r r o o f fl a p i s o p e n , t a k e
care when driving where height is
restricted.
Never rest loads directly on the rear
doors.
Comply with the usual indications, to
attract the attention of other drivers.
The side supports can be used as
hooking points.
- lower the black paddle to secure
t h e r e a r r o o f fl a p .
S e c u r i n g t h e r e a r r o o f fl a p p l a c e s i t
on the seal correctly and guarantees
sealing without noise.
T o c l o s e t h e r e a r r o o f fl a p :
- check that the support bar is secured correctly,
- l o w e r t h e r e a r r o o f fl a p ,
- w h i l e p r e s s i n g t h e r e a r r o o f fl a p (downwards), take hold of the two
loops of the spring then place the
hook in its housing,
Page 33 of 153
37
READY TO SET OFF
37
22
Gearboxes and steering wheel
GEARBOX
5-speed - reverse gear gearbox
To change gear easily, always press
the clutch pedal fully.
To prevent the mat from becoming
caught under the pedal:
- e n s u r e t h a t t h e m a t a n d i t s fi x i n g s o n t h e fl o o r a r e p o s i t i o n e d c o r r e c t l y ,
- n e v e r fi t o n e m a t o n t o p o f a n o t h e r .
When driving, avoid leaving your hand
o n t h e g e a r k n o b a s t h e f o r c e e x e r t e d ,
even if slight, may wear the internal
c o m p o n e n t s o f t h e g e a r b o x o v e r t i m e . To engage reverse gear, wait until the
vehicle is stationary then push the gear
lever to the right then down.
The lever should be moved slowly
to reduce the noise on engaging
reverse gear.
When the vehicle is stationary, unlock
the steering wheel by pulling the lever.
Adjust the height and depth of the
steering wheel, then lock by pushing
the lever fully.
Page 55 of 153
5 7
ERGONOMICS and COMFORT
33
Seats
FRONT SEATS
D e p e n d i n g o n t h e v e r s i o n a n d
c o n fi g u r a t i o n o f y o u r v e h i c l e , d i f f e r e n t
f r o n t s e a t s a r e fi t t e d , e i t h e r :
- a d r i v e r ’ s s e a t a n d a p a s s e n g e r s e a t ,
- a n i n d i v i d u a l d r i v e r ’ s s e a t a n d a m o d u l a r b e n c h .
Depending on the models, the following
a d j u s t m e n t s a r e a v a i l a b l e : 1 - Forwards/backwards adjustment
L i f t t h e b a r a n d s l i d e t h e s e a t f o r w a r d s
o r b a c k w a r d s .
3 - Driver’s seat height adjustment
T o r a i s e t h e s e a t , p u l l t h e h a n d l e u p w a r d s
t h e n t a k e y o u r w e i g h t o f f t h e s e a t c u s h i o n .
T o l o w e r t h e s e a t , p u l l t h e h a n d l e
u p w a r d s t h e n p u s h o n t h e s e a t
cushion.
2 - Seat back angle adjustment
W i t h y o u r b a c k p r e s s e d a g a i n s t t h e s e a t
b a c k , m o v e t h e l e v e r f o r w a r d a n d s e t
t h e r e q u i r e d a n g l e .
Page 56 of 153
5 8
Seats
N e v e r d r i v e w i t h t h e h e a d
r e s t r a i n t s r e m o v e d ; t h e y m u s t b e
i n p l a c e a n d c o r r e c t l y a d j u s t e d . Armrest
T o a c c e s s t h e v e r t i c a l p o s i t i o n , r a i s e
t h e a r m r e s t u n t i l i t l o c k s .
L o w e r t h e a r m r e s t t o p u t i t b a c k i n t h e
position for use.
T o r e m o v e t h e a r m r e s t , p r e s s t h e r e l e a s e
b u t t o n f r o m t h e v e r t i c a l p o s i t i o n a n d m o v e
a s i d e t h e a r m r e s t .
T o p u t t h e a r m r e s t b a c k i n p l a c e , c l i p i t
i n t h e v e r t i c a l p o s i t i o n .
I f t h e v e h i c l e i s fi t t e d w i t h t h e a d d i t i o n a l
c o n s o l e a n d a n a r m r e s t , t o f o l d t h e
p a s s e n g e r s e a t t o t h e t a b l e p o s i t i o n
r e m o v e t h e c o n s o l e o r t h e a r m r e s t .
PASSENGER SEAT
T h e b a c k o f t h e i n d i v i d u a l p a s s e n g e r
s e a t c a n b e f o l d e d t o f o r m a w r i t i n g
t a b l e .
T h i s p o s i t i o n a l s o p e r m i t s t h e
t r a n s p o r t a t i o n o f l o n g l o a d s .
Head restraint height adjustment
T o r a i s e t h e h e a d r e s t r a i n t , s l i d e i t
v e r t i c a l l y u p w a r d s .
T o l o w e r t h e h e a d r e s t r a i n t , p r e s s t h e
b u t t o n a n d s l i d e t h e h e a d r e s t r a i n t
v e r t i c a l l y d o w n w a r d s .
T h e a d j u s t m e n t i s c o r r e c t w h e n t h e u p p e r
e d g e o f t h e h e a d r e s t r a i n t i s l e v e l w i t h t h e
t o p o f t h e h e a d .
T o r e m o v e t h e h e a d r e s t r a i n t , p r e s s
t h e b u t t o n a n d p u l l t h e h e a d r e s t r a i n t
u p w a r d s .
T o r e - i n s t a l l , e n g a g e t h e h e a d r e s t r a i n t
r o d s i n t h e h o l e s , m a k i n g s u r e t h e y a r e
a l i g n e d w i t h t h e s e a t b a c k .
Folding the seat back
P u l l t h e l e v e r f o r w a r d s t h e n t i l t t h e s e a t
b a c k .
Returning the seat back to its
original position
P u l l t h e l e v e r f o r w a r d s t h e n r a i s e t h e
s e a t b a c k u n t i l i t l o c k s .
Page 57 of 153
5 8
Seats
N e v e r d r i v e w i t h t h e h e a d
r e s t r a i n t s r e m o v e d ; t h e y m u s t b e
i n p l a c e a n d c o r r e c t l y a d j u s t e d . Armrest
T o a c c e s s t h e v e r t i c a l p o s i t i o n , r a i s e
t h e a r m r e s t u n t i l i t l o c k s .
L o w e r t h e a r m r e s t t o p u t i t b a c k i n t h e
position for use.
T o r e m o v e t h e a r m r e s t , p r e s s t h e r e l e a s e
b u t t o n f r o m t h e v e r t i c a l p o s i t i o n a n d m o v e
a s i d e t h e a r m r e s t .
T o p u t t h e a r m r e s t b a c k i n p l a c e , c l i p i t
i n t h e v e r t i c a l p o s i t i o n .
I f t h e v e h i c l e i s fi t t e d w i t h t h e a d d i t i o n a l
c o n s o l e a n d a n a r m r e s t , t o f o l d t h e
p a s s e n g e r s e a t t o t h e t a b l e p o s i t i o n
r e m o v e t h e c o n s o l e o r t h e a r m r e s t .
PASSENGER SEAT
T h e b a c k o f t h e i n d i v i d u a l p a s s e n g e r
s e a t c a n b e f o l d e d t o f o r m a w r i t i n g
t a b l e .
T h i s p o s i t i o n a l s o p e r m i t s t h e
t r a n s p o r t a t i o n o f l o n g l o a d s .
Head restraint height adjustment
T o r a i s e t h e h e a d r e s t r a i n t , s l i d e i t
v e r t i c a l l y u p w a r d s .
T o l o w e r t h e h e a d r e s t r a i n t , p r e s s t h e
b u t t o n a n d s l i d e t h e h e a d r e s t r a i n t
v e r t i c a l l y d o w n w a r d s .
T h e a d j u s t m e n t i s c o r r e c t w h e n t h e u p p e r
e d g e o f t h e h e a d r e s t r a i n t i s l e v e l w i t h t h e
t o p o f t h e h e a d .
T o r e m o v e t h e h e a d r e s t r a i n t , p r e s s
t h e b u t t o n a n d p u l l t h e h e a d r e s t r a i n t
u p w a r d s .
T o r e - i n s t a l l , e n g a g e t h e h e a d r e s t r a i n t
r o d s i n t h e h o l e s , m a k i n g s u r e t h e y a r e
a l i g n e d w i t h t h e s e a t b a c k .
Folding the seat back
P u l l t h e l e v e r f o r w a r d s t h e n t i l t t h e s e a t
b a c k .
Returning the seat back to its
original position
P u l l t h e l e v e r f o r w a r d s t h e n r a i s e t h e
s e a t b a c k u n t i l i t l o c k s .
Page 68 of 153
69
ERGONOMICS and COMFORT
33
Practical information
Ladder P a r t i t i o n w i t h fl a p
Mid-height partition
Load retainers
Y o u r v e h i c l e c a n b e e q u i p p e d w i t h
a w i d e r a n g e o f l o a d r e t a i n e r s t o
e f f e c t i v e l y p r o t e c t t h e d r i v e r a n d f r o n t
p a s s e n g e r ( s ) , w h i l e m a i n t a i n i n g t h e
l o a d i n g a d a p t a b i l i t y . Removable flap
T h e fl a p l o c a t e d o n t h e p a n e l s e c t i o n
o f t h e m i d - h e i g h t p a r t i t i o n , b e h i n d
t h e p a s s e n g e r s e a t ( s ) , c a n b e r e m o v e d
t o p e r m i t t h e l o a d i n g o f l o n g o b j e c t s .
- T u r n t h e c o n t r o l l o c a t e d a t t h e t o p
o f t h e fl a p t o r e l e a s e i t .
- L i f t t h e fl a p t o r e m o v e i t f r o m i t s l o c a t i o n .
- P i v o t t h e fl a p b y 9 0 ° t o t h e r i g h t .
- S t o r e i t b e h i n d t h e d r i v e r ’ s s e a t , clipping it into the securing lugs.
C o n t a c t a C I T R O Ë N d e a l e r f o r
i n f o r m a t i o n a b o u t t h e d i f f e r e n t
a c c e s s o r y l o a d r e t a i n e r m o d e l s .
