2008 CADILLAC CTS display

Adding Coolant
If more coolant is needed, add the proper DEX-COOL®
coolant mixture at the surge tank, but only when the
engine is cool.
{CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains eythylene glycol,
and it will burn if the engine parts are hot
enough. Do not spill coolant on a hot engine.
When replacing the pressure cap, make sure it is
hand-tight and fully seated.
Coolant Surge Tank Pressure Cap
Notice:If the pressure cap is not tightly installed,
coolant loss and possible engine damage may
occur. Be sure the cap is properly and tightly
secured.
The coolant surge tank pressure cap must be fully
installed on the coolant surge tank. SeeEngine
Compartment Overview on page 5-14for more
information on location.
Engine Overheating
There are two engine hot messages that may be
displayed in the Driver Information Center (DIC).
SeeDIC Warnings and Messages on page 3-56for
more information.
5-31

Brakes
Brake Fluid
The brake master cylinder
reservoir is lled with
DOT-3 brake uid. See
Engine Compartment
Overview on page 5-14for
the location of the reservoir.
There are only two reasons why the brake uid level in
the reservoir might go down. The rst is that the brake
uid goes down to an acceptable level during normal
brake lining wear. When new linings are put in, the uid
level goes back up. The other reason is that uid is
leaking out of the brake hydraulic system. If it is, have
the brake hydraulic system xed, since a leak means
that sooner or later the brakes will not work well.Do not top off the brake uid. Adding brake uid will not
correct a leak. If uid is added when the linings are
worn, there will be too much uid when new brake
linings are installed. Add or remove brake uid, as
necessary, only when work is done on the brake
hydraulic system.
{CAUTION:
If your vehicle has too much brake uid, it can
spill on the engine. The uid will burn if the
engine is hot enough. You or others could be
burned, and your vehicle could be damaged.
Add brake uid only when work is done on
the brake hydraulic system.
If the ignition is in ON/RUN and the brake uid is low,
the Service Brake System message will be displayed in
the DIC. SeeDIC Warnings and Messages on page 3-56.
When the brake uid falls to a low level, the brake
warning light will come on. SeeBrake System Warning
Light on page 3-38.
5-41

Federal Communications
Commission (FCC) and Industry
and Science Canada
The Tire Pressure Monitor System (TPMS) operates
on a radio frequency and complies with Part 15 of
the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
The TPMS operates on a radio frequency and complies
with RSS-210 of Industry and Science Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modications to this system by other than
an authorized service facility could void authorization to
use this equipment.
Tire Pressure Monitor Operation
The Tire Pressure Monitor System (TPMS) is designed
to warn the driver when a low tire pressure condition
exists. TPMS sensors are mounted onto each tire
and wheel assembly, excluding the spare tire and wheel
assembly. The TPMS sensors monitor the air pressure
in the vehicle’s tires and transmits the tire pressure
readings to a receiver located in the vehicle.
Using the Driver Information Center (DIC), the driver
can also check tire pressure levels using the DIC.
For additional information and details about the DIC
operation and displays seeDIC Operation and Displays
on page 3-48andDIC Warnings and Messages on
page 3-56.
When a low tire pressure
condition is detected, the
TPMS illuminates the
low tire pressure warning
light located on the
instrument panel cluster.
5-70

A DIC warning message to check the pressure in a
specic tire is also shown on the DIC display screen.
The low tire pressure warning light and the DIC warning
message come at each ignition cycle until the tires
are inated to the correct ination pressure.
The low tire pressure warning light may come on in
cool weather when the vehicle is rst started, and then
turn off as you start to drive. This could be an early
indicator that the air pressure in the tire(s) are getting
low and need to be inated to the proper pressure.
The Tire and Loading Information label, attached to
your vehicle, shows the size of your vehicle’s original
equipment tires and the correct ination pressure for the
tires when they are cold. SeeLoading the Vehicle on
page 4-22, for an example of the Tire and Loading
Information label and its location on your vehicle.
Also seeInflation - Tire Pressure on page 5-66.Your vehicle’s TPMS can warn you about a low tire
pressure condition but it does not replace normal
tire maintenance. SeeTire Inspection and Rotation
on page 5-74andTires on page 5-58.
Notice:Using non-approved tire sealants could
damage the Tire Pressure Monitor System (TPMS)
sensors. TPMS sensor damage caused by using
an incorrect tire sealant is not covered by the
vehicle warranty. Always use the GM approved
tire sealant available through your dealer/retailer.
Your vehicle, when new, may have included a
factory-installed Tire Sealant and Compressor Kit.
This kit uses a GM approved liquid tire sealant. See
Tire Sealant and Compressor Kit (With Sealant Selector
Switch) on page 5-84orTire Sealant and Compressor
Kit (Without Sealant Selector Switch) on page 5-93.
5-71

TPMS Malfunction Light and Message
The TPMS will not function properly if one or more of
the TPMS sensors are missing or inoperable. When the
system detects a malfunction, the low tire warning light
ashes for about one minute and then stays on for the
remainder of the ignition cycle. A DIC warning message
is also displayed. The low tire warning light and DIC
warning message come on at each ignition cycle until the
problem is corrected. Some of the conditions that can
cause the malfunction light and DIC message to come
on are:
One of the road tires has been replaced with the
spare tire. The spare tire does not have a TPMS
sensor. The DIC message should go off once you
re-install the road tire containing the TPMS sensor.
The TPMS sensor matching process was not
done or not completed successfully after rotating
the vehicle’s tires. The DIC message should go off
after successfully completing the sensor matching
process. See “TPMS Sensor Matching Process”
later in this section.
One or more TPMS sensors are missing or
damaged. The DIC message and the TPMS
malfunction light should go off when the TPMS
sensors are installed and the sensor matching
process is performed successfully. See your
dealer/retailer for service.
Replacement tires or wheels do not match your
vehicle’s original equipment tires or wheels. Tires
and wheels other than those recommended for your
vehicle could prevent the TPMS from functioning
properly. SeeBuying New Tires on page 5-76.
Operating electronic devices or being near facilities
using radio wave frequencies similar to the TPMS
could cause the TPMS sensors to malfunction.
If the TPMS is not functioning it cannot detect or
signal a low tire condition. See your dealer/retailer for
service if the TPMS malfunction light and DIC message
comes on and stays on.
5-72

TPMS Sensor Matching Process
Each TPMS sensor has a unique identication code.
Any time you replace one or more of the TPMS sensors
or rotate your vehicle’s tires, the identication codes
need to be matched to the new tire/wheel position.
The sensors are matched to the tire/wheel positions
in the following order: driver side front tire, passenger
side front tire, passenger side rear tire, and driver
side rear tire using a TPMS diagnostic tool. See your
dealer/retailer for service.
The TPMS sensors can also be matched to each
tire/wheel position by increasing or decreasing the tire’s
air pressure. If increasing the tire’s air pressure, do not
exceed the maximum ination pressure indicated on the
tire’s sidewall. To decrease the tire’s air-pressure use the
pointed end of the valve cap, a pencil-style air pressure
gage, or a key.
You have two minutes to match the rst tire/wheel
position, and ve minutes overall, to match all four
tire/wheel positions. If it takes longer than two minutes,
to match the rst tire and wheel, or more than
ve minutes to match all four tire and wheel positions,
the matching process stops and you need to start over.The TPMS matching process is outlined below:
1. Set the parking brake.
2. Turn the ignition switch to ON/RUN with the
engine off.
3. Press the Remote Keyless Entry (RKE) transmitter’s
lock and unlock buttons at the same time for
approximately ve seconds. The horn sounds twice
to signal the receiver is in relearn mode and Tire
Learning Active message displays on the DIC
screen.
4. Start with the driver side front tire.
5. Remove the valve cap from the valve stem.
Activate the TPMS sensor by increasing or
decreasing the tire’s air pressure for 10 seconds,
or until a horn chirp sounds. The horn chirp, which
can take up to 30 seconds to sound, conrms
that the TPMS sensor identication code has
been matched to this tire position.
6. Proceed to the passenger side front tire, and repeat
the procedure in Step 5.
7. Proceed to the passenger side rear tire, and repeat
the procedure in Step 5.
8. Proceed to the driver side rear tire, and repeat the
procedure in Step 5.
5-73

Fuses Usage
BCM 4 Body Control Module 4
BCM 5 Body Control Module 5
BCM 6 Body Control Module 6
BCM 7 Body Control Module 7
DISPLY Display
DRL RT Right Daytime Running Lamp (DRL)
DRL/ENG
PUMPDaytime Running Lamps
ECM Engine Control Module (ECM)
ECM/TCM IGNECM, Transmission Control
Module (TCM), Instrument Panel
Cluster (IPC), PASS-Key III+ Module
EMIS 1 Emission 1
EMIS 2 Emission 2
EVEN COILS Even Coils
FRT FOG Front Fog Lamps
HDM WASH Headlamp Driver Module Washer
HORN Horn
LO BEAM DRL Low-Beam DRL
LT HI BEAM Left High-Beam Headlamp
LT LO BEAM Left Low-Beam HeadlampFuses Usage
LT LO BEAM Left Low-Beam Headlamp
LTR Cigarette Lighter
MISC IGN Ignition
NAV MTR Navigation Motor
ODD COILS Odd Coils
PED PROT Not Used
PWR MODINGPassKey Module, Body Control
Module
RT HI BEAM Right High-Beam Headlamp
RT LO BEAM Right Low-Beam Headlamp
RT LO BEAM Right Low-Beam Headlamp
SPARE Spare
SPARE Spare
STR/WHL/
ILLUMSteering Wheel Illumination
TCM BATTTransmission Control Module
Battery
TRANS
OIL RLYTransmission Oil Relay
WPR Windshield Wiper
WSW PUMP Windshield Washer Pump
5-125

Customer Assistance Information (cont.)
Customer Satisfaction Procedure..................... 7-2
GM Mobility Reimbursement Program............... 7-7
Reporting Safety Defects to General Motors.....7-17
Reporting Safety Defects to the
Canadian Government..............................7-17
Reporting Safety Defects to the
United States Government.........................7-16
Roadside Service.......................................... 7-7
Service Publications Ordering Information........7-17
D
Daytime Running Lamps..................................3-18
Defensive Driving............................................. 4-2
Delayed Locking.............................................2-19
DIC Compass.................................................3-53
Diesel
Running Out of Fuel....................................2-49
Disc, MP3....................................................3-106
Doing Your Own Service Work........................... 5-5
Door
Central Door Unlocking System.....................2-19
Delayed Locking..........................................2-19
Locks........................................................2-18
Power Door Locks.......................................2-19
Programmable Automatic Door Locks.............2-20
Rear Door Security Locks.............................2-20Driver Information Center (DIC).........................3-48
DIC Operation and Displays..........................3-48
DIC Vehicle Customization............................3-69
DIC Warnings and Messages........................3-56
Driving
At Night.....................................................4-14
Before a Long Trip......................................4-16
Defensive..................................................... 4-2
Drunken....................................................... 4-2
Highway Hypnosis.......................................4-16
Hill and Mountain Roads..............................4-16
In Rain and on Wet Roads...........................4-15
Rocking Your Vehicle to Get it Out.................4-22
Winter........................................................4-17
Dual Climate Control System............................3-24
E
EDR .............................................................7-18
Electrical System
Add-On Equipment.....................................5-122
Fuses and Circuit Breakers.........................5-123
Power Windows and Other Power Options....5-122
Rear Compartment Fuse Block....................5-126
Underhood Fuse Block...............................5-123
Windshield Wiper Fuses.............................5-122
4
