2008 BUICK ENCLAVE mirror controls

Seats and Restraint System............................. 1-1
Head Restraints
......................................... 1-2
Front Seats
............................................... 1-4
Rear Seats
..............................................1-12
Safety Belts
.............................................1-12
Child Restraints
.......................................1-35
Airbag System
.........................................1-58
Restraint System Check
............................1-74
Features and Controls..................................... 2-1
Keys
........................................................ 2-3
Doors and Locks
......................................2-10
Windows
.................................................2-15
Theft-Deterrent Systems
............................2-17
Starting and Operating Your Vehicle
...........2-20
Mirrors
....................................................2-34
Object Detection Systems
..........................2-38
OnStar
®System
......................................2-46
Universal Home Remote System
................2-50
Storage Areas
.........................................2-57
Instrument Panel............................................. 3-1
Instrument Panel Overview
.......................... 3-4
Climate Controls
......................................3-21
Warning Lights, Gages, and Indicators
........3-32
Driver Information Center (DIC)
..................3-49
Audio System(s)
.......................................3-75Driving Your Vehicle....................................... 4-1
Your Driving, the Road, and the Vehicle
....... 4-2
Towing
...................................................4-23
Service and Appearance Care.......................... 5-1
Service
..................................................... 5-3
Fuel
......................................................... 5-5
Checking Things Under the Hood
...............5-12
Headlamp Aiming
.....................................5-51
Bulb Replacement
....................................5-54
Windshield Wiper Blade Replacement
.........5-57
Tires
......................................................5-59
Appearance Care
.....................................5-92
Vehicle Identication
...............................5-100
Electrical System
....................................5-100
Capacities and Specications
...................5-109
Maintenance Schedule..................................... 6-1
Maintenance Schedule
................................ 6-2
Customer Assistance Information.................... 7-1
Customer Assistance and Information
........... 7-2
Reporting Safety Defects
...........................7-15
Vehicle Data Recording and Privacy
...........7-17
Index................................................................ 1
2009 Buick Lucerne Owner ManualM

Memory Seat and Mirrors
On vehicles with the memory feature the buttons are
located on the driver’s door.
1:Saves the seating position for driver 1.
2:Saves the seating position for driver 2.
B:Recalls the easy exit position.
For more programming information, seeDIC Vehicle
Customization on page 3-66.
To save your positions in memory:
1. Adjust the driver’s seat, including the seatback
recliner and lumbar, and both outside mirrors to
your preferred position.
2. Press and hold button 1 until two beeps sound to
let you know that the position has been stored.
3. Repeat the procedure for a second driver using
button 2.
The vehicle must be in PARK (P) to recall your memory
positions.
Press and release either button to recall the stored
setting. Each time a memory button is pressed, a single
beep sounds.If you use the remote keyless entry transmitter to enter
your vehicle and the remote recall memory feature
is on, automatic seat and mirror movement occurs.
To stop recall movement of the memory feature, press
one of the power seat controls, memory buttons, or
power mirror buttons.
If something has blocked the driver’s seat while recalling
a memory position, the driver’s seat recall may stop
working. If this happens, press the control for the area
that is not recalling for two seconds, after the obstruction
is removed. Try recalling the memory position again
by pressing the appropriate memory button. If the
memory position is still not recalling, see your
dealer/retailer for service.
Easy Exit Seat
B
:With the vehicle in PARK (P), press to recall the
exit position.
You will hear a single beep and the driver’s seat
moves back.
1-8

Keys...............................................................2-3
Remote Keyless Entry (RKE) System................2-4
Remote Keyless Entry (RKE) System
Operation...................................................2-5
Remote Vehicle Start......................................2-8
Doors and Locks............................................2-10
Door Locks..................................................2-10
Power Door Locks........................................2-10
Delayed Locking...........................................2-11
Programmable Automatic Door Locks..............2-11
Rear Door Security Locks..............................2-12
Lockout Protection........................................2-12
Trunk..........................................................2-13
Windows........................................................2-15
Power Windows............................................2-16
Sun Visors...................................................2-17
Theft-Deterrent Systems..................................2-17
Content Theft-Deterrent.................................2-17
PASS-Key
®III+ Electronic Immobilizer.............2-18
PASS-Key®III+ Electronic Immobilizer
Operation.................................................2-19Starting and Operating Your Vehicle................2-20
New Vehicle Break-In....................................2-20
Ignition Positions..........................................2-21
Retained Accessory Power (RAP)...................2-22
Starting the Engine.......................................2-22
Engine Coolant Heater..................................2-24
Automatic Transmission Operation...................2-25
Parking Brake..............................................2-27
Shifting Into Park..........................................2-28
Shifting Out of Park......................................2-31
Parking Over Things That Burn.......................2-31
Engine Exhaust............................................2-32
Running the Vehicle While Parked..................2-33
Mirrors...........................................................2-34
Automatic Dimming Rearview Mirror................2-34
Compass.....................................................2-34
Outside Power Mirrors...................................2-36
Outside Automatic Dimming Mirror..................2-36
Park Tilt Mirrors............................................2-37
Outside Convex Mirror...................................2-37
Outside Heated Mirrors..................................2-37
Section 2 Features and Controls
2-1

Express-Down Window
This feature is on the front windows. Press the switch to
the second position to activate the express-down feature.
To stop the window as it is lowering, press down briey
on the switch again.
Window Lockout
o
(Window Lockout):The rear window lockout
button is located on the driver’s door armrest near the
window switches.
Press the right side of this button to disable the rear
window controls. The light on the button will come on,
indicating the feature is in use. The rear windows
still can be raised or lowered using the driver’s window
switches when the lockout feature is active.
To restore power to the rear windows, press the button
again. The light on the button will go out.
Sun Visors
Pull the visor toward you, or move to the side to help
reduce glare.
On vehicles with a lighted vanity mirror, lift the attached
cover to use.
Theft-Deterrent Systems
Vehicle theft is big business, especially in some cities.
This vehicle has theft-deterrent features, however,
they do not make it impossible to steal.
Content Theft-Deterrent
Your vehicle may have the optional content
theft-deterrent alarm system.
To activate the theft-deterrent system:
1. Open the door.
2. Lock the door with the power door lock switch
or the Remote Keyless Entry (RKE) transmitter.
If you are using the RKE transmitter, the door does
not need to be open.
3. Close all doors.
Once armed, the alarm will go off if someone tries to
enter the vehicle without using the RKE transmitter or
a key or turns the ignition on with an incorrect key.
The horn will sound and the turn signal lamps will ash
for about two minutes.
When the alarm is armed, the trunk may be opened
with the RKE transmitter. The power door lock switches
are disabled and the doors remain locked. You must
use your RKE transmitter or your key to unlock the doors
when the system is armed.
2-17

Outside Power Mirrors
Controls for the outside
power mirrors are located
on the driver’s door
armrest.
To adjust the mirror:
1. Press the left or right side of the selector switch
located beneath the control pad to choose the
driver’s or passenger side mirror.
2. Press one of the four arrows located on the control
pad to move the mirror in the desired direction.
3. Adjust each outside mirror to see a little of your
vehicle, and the area behind your vehicle.Manually fold the mirrors inward to prevent damage
when going through an automatic car wash. To fold, push
the mirror toward the vehicle. Push the mirror outward, to
return to its original position.
Outside Automatic Dimming Mirror
If the vehicle has this feature, the driver’s side mirror
adjusts for the glare of headlamps behind you.
This feature is controlled by the on and off settings on
the automatic dimming rearview mirror. SeeAutomatic
Dimming Rearview Mirror on page 2-34for more
information.
Turn Signal Indicator
The vehicle may also have a turn signal indicator on the
mirror. An arrow on the outside rearview mirror ashes
in the direction of the turn or lane change. SeeTurn and
Lane-Change Signals on page 3-8for more information.
Side Blind Zone Alert (SBZA)
If the vehicle has the Side Blind Zone Alert (SBZA)
system, seeSide Blind Zone Alert (SBZA) on page 2-40.
2-36

Lights (cont.)
High/Low Beam Changer................................ 3-9
On Reminder..............................................3-16
Loading Your Vehicle.......................................4-18
Lockout Protection..........................................2-12
Locks
Delayed Locking..........................................2-11
Door ..........................................................2-10
Lockout Protection.......................................2-12
Power Door ................................................2-10
Programmable Automatic Door Locks.............2-11
Rear Door Security Locks.............................2-12
Loss of Control...............................................4-10
Lower Anchors and Tethers for Children.............1-45
Lumbar
Power Controls............................................. 1-5
M
Maintenance Schedule
Additional Required Services........................... 6-6
At Each Fuel Fill........................................... 6-9
At Least Once a Month.................................. 6-9
At Least Once a Year..................................6-10
Introduction.................................................. 6-2
Maintenance Footnotes.................................. 6-7Maintenance Schedule (cont.)
Maintenance Record....................................6-15
Maintenance Replacement Parts....................6-13
Maintenance Requirements............................. 6-2
Owner Checks and Services........................... 6-8
Recommended Fluids and Lubricants.............6-12
Scheduled Maintenance................................. 6-4
Using.......................................................... 6-3
Your Vehicle and the Environment................... 6-2
Malfunction Indicator Lamp...............................3-43
Manual Seats................................................... 1-4
Memory Seat and Mirrors.................................. 1-8
Message
DIC Warnings and Messages........................3-56
Mirrors
Automatic Dimming Rearview........................2-34
Manual Rearview Mirror with Compass and
Temperature............................................1-12
Outside Automatic Dimming Mirror.................2-36
Outside Convex Mirror.................................2-37
Outside Heated Mirrors................................2-37
Outside Power Mirrors..................................2-36
Park Tilt.....................................................2-37
MP3 .............................................................3-88
MyGMLink.com................................................ 7-5
8

Power
Door Locks.................................................2-10
Electrical System.......................................5-101
Inadvertent Battery Saver.............................3-19
Lumbar Controls........................................... 1-5
Retained Accessory.....................................2-22
Seat ............................................................ 1-5
Steering Fluid.............................................5-38
Tilt Wheel and Telescopic Steering Column....... 3-7
Windows....................................................2-16
Privacy..........................................................7-17
Event Data Recorders..................................7-17
Navigation System.......................................7-18
OnStar .......................................................7-18
Radio Frequency Identication.......................7-18
Programmable Automatic Door Locks.................2-11
R
Radiator Pressure Cap....................................5-35
Radio Frequency Identication (RFID), Privacy....7-18
Radio(s)........................................................3-78
Radios
Navigation/Radio System, see Navigation
Manual...................................................3-93
Reception.................................................3-105
Setting the Clock.........................................3-76
Theft-Deterrent..........................................3-104
Rainsense™ II Wipers.....................................3-10Rear Door Security Locks................................2-12
Rear Seat Armrest..........................................2-57
Rearview Mirror, Automatic Dimming..................2-34
Rearview Mirror with Compass and
Temperature...............................................1-12
Reclining Seatbacks.......................................... 1-9
Recommended Fluids and Lubricants.................6-12
Recreational Vehicle Towing.............................4-24
Remote Keyless Entry (RKE) System.................. 2-4
Remote Keyless Entry (RKE) System, Operation . . . 2-5
Remote Vehicle Start........................................ 2-8
Removing the Flat Tire and Installing the
Spare Tire..................................................5-84
Removing the Spare Tire and Tools...................5-83
Replacement Bulbs.........................................5-57
Replacement Parts, Maintenance......................6-13
Reporting Safety Defects
Canadian Government..................................7-15
General Motors...........................................7-15
United States Government............................7-15
Restraint System Check
Checking the Restraint Systems....................1-74
Replacing Restraint System Parts
After a Crash..........................................1-75
Retained Accessory Power...............................2-22
Roadside
Assistance Program....................................... 7-7
Rocking Your Vehicle to Get it Out....................4-18
Routing, Engine Drive Belt...............................6-14
Running the Vehicle While Parked.....................2-33
10

S
Safety Belt Reminders.....................................3-35
Safety Belts
Care of ......................................................5-95
How to Wear Safety Belts Properly................1-18
Lap Belt.....................................................1-33
Lap-Shoulder Belt........................................1-27
Safety Belt Extender....................................1-34
Safety Belt Use During Pregnancy.................1-33
Safety Belts Are for Everyone.......................1-12
Safety Warnings and Symbols.............................. iii
Scheduled Maintenance..................................... 6-4
Seats
Center Seat................................................1-12
Heated and Cooled Seats.............................. 1-7
Heated Seats............................................... 1-6
Memory, Mirrors............................................ 1-8
Power Lumbar .............................................. 1-5
Power Seats................................................. 1-5
Reclining Seatbacks...................................... 1-9
Securing a Child Restraint
Center Front Seat Position............................1-54
Rear Seat Position......................................1-51
Right Front Seat Position..............................1-54
Security Light.................................................3-46
Service........................................................... 5-3
Accessories and Modications......................... 5-3
Adding Equipment to the Outside of the
Vehicle..................................................... 5-5Service (cont.)
California Perchlorate Materials Requirements . . . 5-4
California Proposition 65 Warning.................... 5-4
Doing Your Own Work................................... 5-4
Engine Soon Lamp......................................3-43
Publications Ordering Information...................7-16
Service, Scheduling Appointments.....................7-10
Servicing Your Airbag-Equipped Vehicle..............1-72
Setting the Clock............................................3-76
Sheet Metal Damage.......................................5-99
Shifting Into Park............................................2-28
Shifting Out of Park........................................2-31
Side Blind Zone Alert......................................2-40
Signals, Turn and Lane-Change.......................... 3-8
Spare Tire
Compact....................................................5-91
Installing
....................................................5-84
Removing...................................................5-83
Storing.......................................................5-89
Specications, Capacities...............................5-109
Speedometer..................................................3-34
StabiliTrak
®Indicator Light...............................3-41
Stabilitrak®System........................................... 4-6
Start Vehicle, Remote....................................... 2-8
Starting the Engine.........................................2-22
Steering.......................................................... 4-8
Steering Wheel Controls, Audio.......................3-104
Steering Wheel, Heated..................................... 3-7
Steering Wheel, Power Tilt Wheel and
Telescopic Steering Column............................ 3-7
11
