2008 AUDI R8 steering

Downloaded from www.Manualslib.com manuals search engine Overview
Buttons for:
Audi magnetic ride
Electronic stabilisationprogram
Hazard warning lights
Rear spoiler
parking system for activation/deactivation
of parking aid
Warning lamp for front
passenger’s airbag
Handbrake
ESP OFF
19
P
20
21
Door handle and central
locking switch
Lock
Unlock
Bonnet lock release
Light switch
Cruise control system
Turn signal and main beam
lever
Controls on multi-function
steering wheel
Instruments and warning/
indicator lamps
10
9
8
4
5
7
6
Steering wheel position
adjuster Ignition lock
Windscreen wipers/washer
and buttons for on-board
computer
Navigation system Air conditioner
Front passenger’s seat
heating
Driver’s seat heating
Gear lever or selector lever
for Rtronic
18
17
16
15
12
14
13
11
14
15
1617
18
19
20
21

Downloaded from www.Manualslib.com manuals search engine 8
76
4
123
5
Manual seat adjustment
To move seat backwards or forwards:
Lift the lever and move the seat.
Then relea
se the lever and move the
seat further until the catch engages.
To adjust lumbar support:
Press the appropriate part of the
switch.
T

o adjust seat height:
Pull up or press down the lever
repeatedly .
T

o adjust backrest:
Take your weight off the backrest
and turn the knob. To release backrest:
Pull the lever upwards and fold the
backr est f

orwards.
5
8
7
6
4
Adjusting head restraints
Take hold of the sides of the head
restraint with both hands and move it up
or down as required. The top of the head
restraint should be at eye level or higher.
Seat adjustment
Electric seat adjustment
To adjust lumbar support:
Press the appropriate part
of the switch.
To adjust se

at height and move seat
backwards or
forwards:
Front of seat cushion up/down
Rear of seat cushion up/down Seat up/down
Seat forwards/
bac

kwards
To adjust backrest: Backrest further
upright/further
r

eclined
1
3
2
Sitting position
Sit in a normal upright position anddo not sit too close to the steering
wheel. If necessary, also adjust the position of the steering wheel.min.
25 cm

Downloaded from www.Manualslib.com manuals search engine 1
22
Audi Navigation System plus
ComponentsDriver information systemMulti-function steering wheel
Scroll the left thumbwheel to select a menu item in
the driver information system. Press the thumbwheel to
confirm the selection.
Press the MODE button to switch between the active
audio source and the navigation and telephone functions.
Briefly press the button to switch on the speech
dialogue system.
Speak after the e.g. say to call up the
possible operating commands.
Press and hold the talk button to switch off the speech
dialogue system.
Scroll the right thumbwheel to adjust the volume.
If you press the right thumbwheel, the last navigation
cue will be repeated.
2
1
