Downloaded from www.Manualslib.com manuals search engine Overview
Buttons for:
Audi magnetic ride
Electronic stabilisationprogram
Hazard warning lights
Rear spoiler
parking system for activation/deactivation
of parking aid
Warning lamp for front
passenger’s airbag
Handbrake
ESP OFF
19
P
20
21
Door handle and central
locking switch
Lock
Unlock
Bonnet lock release
Light switch
Cruise control system
Turn signal and main beam
lever
Controls on multi-function
steering wheel
Instruments and warning/
indicator lamps
10
9
8
4
5
7
6
Steering wheel position
adjuster Ignition lock
Windscreen wipers/washer
and buttons for on-board
computer
Navigation system Air conditioner
Front passenger’s seat
heating
Driver’s seat heating
Gear lever or selector lever
for Rtronic
18
17
16
15
12
14
13
11
14
15
1617
18
19
20
21
Downloaded from www.Manualslib.com manuals search engine 3
Infotainment
Display
Function selector buttons
Press one of the buttons
(e.g. RADIO) to activate
the desired mode.
ON/OFF button
To switch on:Press briefly.
To adjust volume: Turn.
To mute: Press briefly.
To switch off: Press and hold.
Control buttons
To activate one of the functions shown
in the four corners of the display, press
the control button for that corner of the display.
Rotary pushbutton
To select a menu item on display :
Turn the rotary pushbutton.
To confirm selection:
Press the rotary pushbutton.3
7
6
5
4
3
Operating logic
The operating logic for accessing
the functions is always the same.
To call up the menu in a
corner of the display: Press
the corresponding button.
To select: Turn the rotary
pushbutton.
To confirm: Press the rotary
pushbutton.
C
B
A
CA
B
7566
4
