2008 AUDI R8 steering wheel

Handset for the Bluetooth car telephone kit35
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control










Basic operation41
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
How to use the controls
You can operate the functions of the MMI system by
pressing and turning the buttons on the MMI control
console.
Fig. 29 Buttons on MMI control console
Function selector buttons
Press one of the function selector buttons to activate the function
shown on the button. For example, simply press the button
to switch the system to the radio mode.
Use the button to call up additional settings for the current
function. Rotary pushbutton
To select a menu option in the MMI display, turn the rotary push-
button in the required direction and then press it.
Control buttons
To activate a function indicated in one of the four corners of the
display, press the corresponding control button for that corner of
the display. For instance, the top right control button corresponds
with the top right corner of the display
fig. 29.
RETURN button
Press the button to cancel an entry that has not yet been
confirmed or to return to the previous menu level.
Arrow buttons
Press the or button to go to the next or go back to the previous
radio station or TV* channel in the list.
Press the button to select the next track of a CD or iPod
5) (if an
iPod is being used). Press the button within the first ten seconds
of a track to go back to the previous track. After the first ten seconds,
you can press this button to go back to the start of the track that is
currently playing.
When in the CD, MP3 or interface mode, press and hold the
button to activate the fast reverse function, or press the button to
activate the fast forward function.
A1
RADIO
SETUP
5)Still under development at the time of printing.
A2
A3
A4
RETURN
A5
<>
><
<>










Basic operation43
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Speller
Use the speller to enter addresses, a navigation destina-
tion or a telephone number.
Some functions in the directory, telephone* or navigation* mode
require you to enter letters or numbers. In the MMI display the
speller for numbers
fig. 32 or letters
fig. 33 will appear.
While entering the numbers/letters, you can switch from numbers
to letters and vice versa as desired by turning the rotary pushbutton
to 0..9
fig. 33 or A..Z
fig. 32 and then pressing the rotary
pushbutton.
All symbols for entering letters and numbers are explained in the
following table:
TP symbolReception of traffic reports
page 58.
Corners of
display
Indicates the functions that can be
selected.
Use control buttons to select func-
tions. The top right corner of the dis-
play corresponds to the top right
control button.
SubtitlesInforms you of a selected option (e.g.
current radio station).
Function
wheelIs operated by turning and pressing
the rotary pushbutton.
Crossed-out
loudspeaker
symbolCurrent audio source is muted.
Time
Telephone
symbol*Missed calls*
page 91, fig. 85.
LegendSymbol /
MarkingExplanation
A11
A12
A13
A14
A15
A16
A17
Fig. 32 Speller for
numbers: Entering
phone numbers
Fig. 33 Speller for
letters: Finding a direc-
tory entry
A11A5










Basic operation45
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Switching the MMI display on and off
Switching off the display
– Starting from any one of the Setup menus, press the
control button for Display.
– Turn the rotary pushbutton to Switch off display

fig. 34 and press the rotary pushbutton. The display
will be switched off.
Switching on the display
– Press or turn the rotary pushbutton, or
– Press a function selector button, or
– Press a control button, or
– Press the button.
Note
After switching off the display, you can still change the station on a
selected audio/video source using the arrow buttons on the MMI
control console.
Adjusting the volume
Current audio/video* source
Adjust the volume or mute the audio sources using the
ON/OFF button.
Increasing and reducing the volume
– Turn the ON/OFF button clockwise or anti-clockwise. The
volume level you select is stored in the memory.
Mute
– Briefly press the ON/OFF button. A crossed-out loud-
speaker will appear in the MMI display.
Unmute
– Briefly press the ON/OFF button, or
– Turn the ON/OFF button.
When you switch on the MMI system, very high/very low volume
levels are automatically reduced/increased to a preset level.
If you activate the mute/pause function by pressing the ON/OFF
button briefly before switching off the MMI, the mute/pause func-
tion will remain active when the MMI is switched on again.
Fig. 34 Switching off
the MMI display
RETURN
Fig. 35 Increasing,
reducing and muting
volume of MMI system










Basic operation 46
If you are in CD mode, the CD playback will be paused while the
mute function is activated.
Note
You can also adjust the volume by scrolling the right thumbwheel
on the multi-function steering wheel up and down without having
to remove your hands from the steering wheel
page 129.
Other audio sources
The volume of the voice guidance*, traffic reports*, the
speech dialogue system* and the telephone* can be
adjusted separately.
The system automatically sends a test message while the
settings are being adjusted.
– Starting from any of the audio, TV*, or SETUP menus,
press the control button for Sound
page 41.
– Turn the rotary pushbutton and select Volume settings.
– Press the rotary pushbutton. The Volume settings menu
will appear on the MMI display
fig. 36.
– Turn the rotary pushbutton to select an item in the menu.– Press the rotary pushbutton. Now you can adjust the
volume for the selected item.
– Turn the rotary pushbutton to select the desired volume.
– Press the rotary pushbutton to confirm your adjustment.
Note
Select Audio during route guid. to adjust the volume of the current
audio source during route guidance (spoken navigation
directions).
Adjusting the sound
Basic settings
Fig. 36 Volume
settings
Fig. 37 Selecting
balance





!




Basic operation47
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
– Starting from any of the audio, TV*, or SETUP menus,
press the control button for Sound
page 41.
– Turn the rotary pushbutton to select an item in the menu
(e.g. Balance
page 46, fig. 37).
– Press the rotary pushbutton. The selected item will
appear larger on the MMI display
fig. 38.
– Turn the rotary pushbutton clockwise or anti-clockwise to
adjust the sound settings.
– Press the rotary pushbutton to confirm your adjustment.
The following sound settings are available:
•Balance: Varies left and right volume levels
•Fader: Varies front and rear volume levels
•Tr e b l e
•Bass
•GALA (speed-dependent volume control)
•Subwoofer* (for extra bass depth)6)
•DSP *
page 47
•DSP Bang & Olufsen*
page 48
•Volume settings for other audio sources
page 46
The settings for treble and bass are effective for the currently
selected function. The settings for balance and fader apply regard-
less of the selected function.
Applies to vehicles: with DSP
Digital Signal Processing (DSP)
With the sound focus function you can achieve three-
dimensional sound effects. GALA adjusts the volume level
and sound settings to the vehicle's speed.
Displaying the DSP menu
– Starting from any of the audio, TV*, or SETUP menus,
press the control button for Sound
page 41.
– Turn the rotary pushbutton to DSP and press to confirm.
The DSP menu will appear on the MMI display
fig. 39.
Sound focus
– Turn the rotary pushbutton to Sound focus and press to
confirm.
6)The subwoofer cannot be adjusted if your vehicle is equipped with the Bang
& Olufsen* sound system.
Fig. 38 Adjusting
balance
Fig. 39 Adjusting
three-dimensional
sound effects (sound
focus)










Basic operation49
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
– Press the rotary pushbutton to confirm your
adjustment.
Setting the time
You can choose between a quartz clock and a radio-
controlled clock*. If you have chosen the quartz clock,
you must set the time and date yourself. The radio-
controlled clock* receives the time and date automati-
cally.
Calling up the Time setting menu
– Press the function selector button marked .
– Press the Time control button. The Time setting menu
will appear on the MMI display.
Selecting the time source*
7)
– Turn the rotary pushbutton to Time source and press to
confirm.– Turn the rotary pushbutton to quartz or radio clock* and
press to confirm. When the time source is selected as
radio clock*, the “signal reception symbol” appears on
the rev counter display.
Setting the time (only possible for time source:
quar t z)
– Turn the rotary pushbutton to Time and press to confirm.
The hour display will be highlighted in white on the MMI
display.
– To set the hour, turn the rotary pushbutton clockwise or
anti-clockwise and press it. The minute display will then
be highlighted in white on the MMI display.
– To set the minutes, turn the rotary pushbutton clockwise
or anti-clockwise.
– Confirm the time setting by pressing the rotary push-
button.
Setting the date (only possible for time source:
quar t z)
– Turn the rotary pushbutton to Date and press the rotary
pushbutton. The date display will then be highlighted in
white on the MMI display.
– To set the day, turn the rotary pushbutton clockwise or
anti-clockwise and press it. The month display will then
be highlighted in white on the MMI display.
– To set the month, turn the rotary pushbutton clockwise
or anti-clockwise and press it. The year display will then
be highlighted in white on the MMI display.
– To set the year, turn the rotary pushbutton clockwise or
anti-clockwise.
7)Applies to vehicles with radio-controlled clock
Fig. 41 Time setting
SETUP










Basic operation51
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
– Press the button , the rotary pushbutton
and the top right control button simultaneously.
– Then release the buttons. The MMI system will switch off
and then restart.
Other settings
MMI menu language
– Select: Function selector button > control button
Settings > Menu language.
The language of texts shown on the MMI display and the driver
information system as well as the language of the voice guidance*
can be altered.
You can select the languages German, English, French, Italian,
Spanish, Portuguese, Dutch or Russian.
Measurement units
– Select: Function selector button > control button
Settings > Measurement units.
You can alter the measurement units shown on the MMI display, the
driver information system and the air conditioner display.
The units for distance (km or miles), speed (km/h or mph), tempera-
ture (°C or °F) and pressure (bar or psi) can be set.
Applies to vehicles: with speech dialogue system
Speech dialogue system
– Select: Function selector button > control button
Settings > Speech dialogue system.
Repeat command
If Repeat command is activated, the speech dialogue system* will
repeat your commands when switching to another function.
Deleting all name tags
All the name tags (spoken names or telephone numbers) you have
stored will be deleted.
Default settings
– Select: Function selector button > control button
Settings > Default settings.
This function resets the general settings, the sound settings as well
as several of the radio, CD, TV/AV*, telephone* and navigation*
settings to the default settings.
Brightness of the MMI display
– Select: Function selector button > control button
Display > Brightness.
You can alter the brightness of the display by turning the rotary
pushbutton clockwise or anti-clockwise.
SETUPA1A2
A3
SETUP
SETUP
SETUP
SETUP
SETUP
