2008 AUDI A8 SPEED

Contents3
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Entering the PIN/PUK code . . . . . .
Emergency calls . . . . . . . . . . . . . . .
Dialling a telephone number . . . .
Answering and ignoring telephone
calls . . . . . . . . . . . . . . . . . . . . . . . . . .
Ending calls . . . . . . . . . . . . . . . . . . .
Storing a telephone number in the
directory . . . . . . . . . . . . . . . . . . . . . .
Dialling a stored telephone number
Other settings for the Bluetooth car
telephone kit . . . . . . . . . . . . . . . . . .
Other settings for the phone pre-
installation . . . . . . . . . . . . . . . . . . . .
Navigation. . . . . . . . . . . . . . . . . . . . .
Introduction . . . . . . . . . . . . . . . . . . .
Activating navigation mode . . . . .
Entering a destination . . . . . . . . . .
Stopping the route guidance . . . .
Display . . . . . . . . . . . . . . . . . . . . . . . .
Storing a destination . . . . . . . . . . .
Loading a destination . . . . . . . . . .
Other settings . . . . . . . . . . . . . . . . .
Calling up traffic information. .
Introduction . . . . . . . . . . . . . . . . . . .
Calling up traffic reports (TP memo)
Setting a traffic station . . . . . . . . .
Calling up a traffic message . . . . .
Other settings . . . . . . . . . . . . . . . . .
Multi-function steering
wheel
. . . . . . . . . . . . . . . . . . . . . . . .
Basic operation . . . . . . . . . . . . . . . .
Introduction . . . . . . . . . . . . . . . . . . .
Adjusting the volume . . . . . . . . . . .
Listening to the radio . . . . . . . . . . .
Playing media . . . . . . . . . . . . . . . . . .
Television . . . . . . . . . . . . . . . . . . . . . .
Using the telephone . . . . . . . . . . . .
Navigation . . . . . . . . . . . . . . . . . . . . .
Voice control . . . . . . . . . . . . . . . . . . .
Telephone handset. . . . . .
Basic operation . . . . . . . . . . . . . . . .
Switching the handset on and off
Overview of the keypad . . . . . . . . .
Display . . . . . . . . . . . . . . . . . . . . . . . .
Using the telephone . . . . . . . . . . .
Placing calls . . . . . . . . . . . . . . . . . . .
Speed and one-touch dialling . . . .
Answering and ignoring telephone
calls . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency calls . . . . . . . . . . . . . . . . Ending calls . . . . . . . . . . . . . . . . . . . .
Options during a call . . . . . . . . . . . .
Answering and replacing further
calls . . . . . . . . . . . . . . . . . . . . . . . . . . .
Menus. . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction . . . . . . . . . . . . . . . . . . . .
“Last calls” menu . . . . . . . . . . . . . . .
“Phone book” menu . . . . . . . . . . . . .
“ Text messages” menu . . . . . . . . . .
“Settings” menu (handset) . . . . . . .
Vo i c e c o n t r o l . . . . . . . . . . . . . .
Telephone speech control
system . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction . . . . . . . . . . . . . . . . . . . .
Basic operation . . . . . . . . . . . . . . . . .
Name tags . . . . . . . . . . . . . . . . . . . . .
Speech recognition for some
export markets . . . . . . . . . . . . . . . . .
Storing names in the phone book*
Selecting a name from the phone
book* . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting a name from the phone
book* . . . . . . . . . . . . . . . . . . . . . . . . . .
Speech dialogue system . . . . . . .
Introduction . . . . . . . . . . . . . . . . . . . .
Basic operation . . . . . . . . . . . . . . . . .
Name tags . . . . . . . . . . . . . . . . . . . . .
Listening to the radio . . . . . . . . . . . .
Playing an audio CD . . . . . . . . . . . . .
Using the directory . . . . . . . . . . . . . . 88
89
90
92
92
93
94
94
101
104
104
105
105
110
110
112
114
116
121
121
121
122
122
123127
128
128
129
129
130
131
132
136
137
139
140
140
140
142
145
145
146
147
147148
149
150
151
151
152
153
154
155
159
160
160
161
164
167
167
168
168
169
169
170
172
174
175
175










Basic operation47
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
– Starting from any of the audio, TV*, or SETUP menus,
press the control button for Sound
page 41.
– Turn the rotary pushbutton to select an item in the menu
(e.g. Balance
page 46, fig. 37).
– Press the rotary pushbutton. The selected item will
appear larger on the MMI display
fig. 38.
– Turn the rotary pushbutton clockwise or anti-clockwise to
adjust the sound settings.
– Press the rotary pushbutton to confirm your adjustment.
The following sound settings are available:
•Balance: Varies left and right volume levels
•Fader: Varies front and rear volume levels
•Tr e b l e
•Bass
•GALA (speed-dependent volume control)
•Subwoofer* (for extra bass depth)6)
•DSP *
page 47
•DSP Bang & Olufsen*
page 48
•Volume settings for other audio sources
page 46
The settings for treble and bass are effective for the currently
selected function. The settings for balance and fader apply regard-
less of the selected function.
Applies to vehicles: with DSP
Digital Signal Processing (DSP)
With the sound focus function you can achieve three-
dimensional sound effects. GALA adjusts the volume level
and sound settings to the vehicle's speed.
Displaying the DSP menu
– Starting from any of the audio, TV*, or SETUP menus,
press the control button for Sound
page 41.
– Turn the rotary pushbutton to DSP and press to confirm.
The DSP menu will appear on the MMI display
fig. 39.
Sound focus
– Turn the rotary pushbutton to Sound focus and press to
confirm.
6)The subwoofer cannot be adjusted if your vehicle is equipped with the Bang
& Olufsen* sound system.
Fig. 38 Adjusting
balance
Fig. 39 Adjusting
three-dimensional
sound effects (sound
focus)










Basic operation51
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
– Press the button , the rotary pushbutton
and the top right control button simultaneously.
– Then release the buttons. The MMI system will switch off
and then restart.
Other settings
MMI menu language
– Select: Function selector button > control button
Settings > Menu language.
The language of texts shown on the MMI display and the driver
information system as well as the language of the voice guidance*
can be altered.
You can select the languages German, English, French, Italian,
Spanish, Portuguese, Dutch or Russian.
Measurement units
– Select: Function selector button > control button
Settings > Measurement units.
You can alter the measurement units shown on the MMI display, the
driver information system and the air conditioner display.
The units for distance (km or miles), speed (km/h or mph), tempera-
ture (°C or °F) and pressure (bar or psi) can be set.
Applies to vehicles: with speech dialogue system
Speech dialogue system
– Select: Function selector button > control button
Settings > Speech dialogue system.
Repeat command
If Repeat command is activated, the speech dialogue system* will
repeat your commands when switching to another function.
Deleting all name tags
All the name tags (spoken names or telephone numbers) you have
stored will be deleted.
Default settings
– Select: Function selector button > control button
Settings > Default settings.
This function resets the general settings, the sound settings as well
as several of the radio, CD, TV/AV*, telephone* and navigation*
settings to the default settings.
Brightness of the MMI display
– Select: Function selector button > control button
Display > Brightness.
You can alter the brightness of the display by turning the rotary
pushbutton clockwise or anti-clockwise.
SETUPA1A2
A3
SETUP
SETUP
SETUP
SETUP
SETUP










Television71
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Television
Applies to vehicles: with analog TV and DVB-T
Introduction
For safety reasons, the TV picture is not available while
the vehicle is moving.
Via the MMI system you can receive either analog TV channels or
digital TV channels as well as digital radio stations 9) in the DVB-T
standard.
Your MMI system automatically displays a list of the available TV
channels. You do not even have to set up the channels. Use the
rotary pushbutton in the usual way to select the TV channels.
However, which and how many channels you can receive depends
on your location and the quality of the reception.
DVB-T channels/stations can primarily be received in big metropol-
itan areas. Reception is dependent on a number of factors, e.g. the
distance to the transmitter and the speed at which the vehicle is
travelling.
Would you like to connect additional AV devices to your MMI
system? No problem! You can connect up to two AV devices
(audio/video out port). You only have to set the appropriate AV
standard
page 79. Suitable connector cables are available from
Audi dealers or specialist retailers.
The picture is at first only shown within the inner section of the
display; however, after a few seconds it will expand to the full
screen. The volume will automatically be muted if the TV reception
becomes poor. The volume will be switched on again automatically
if the TV reception quality improves. While you are driving, the
screen will be darkened for your safety. However, you can still listen
to the audio.
Note
•The analog/digital TV reception only supports the DVB-T
standard. Other standards such as DVB via satellite (DVB-S) or
encoded programmes / Pay TV are not supported.
•Playback of multi-channel programmes in Dolby Digital 5.1
sound is not supported. These programmes are then reproduced in
stereo.
•The DVB-T network is still in the process of expanding and is
therefore not available in all areas. Please obtain information
regarding DVB-T reception in the region you live in.
•You can operate the DVB functions via the MMI if the DVB-T
receiver was fitted at the factory.
Applies to vehicles: with analog TV and DVB-T
Activating TV mode
Important: The MMI system must be switched on

page 40, and the vehicle must be stationary.
– Press the function selector button marked .
9)Digital radio stations can only be received via DVB-T in some countries and
regions.
Fig. 62 List of possible
audio/video sources
MEDIA










Using the telephone 146
Applies to vehicles: with handset for the car telephone kit
Speed and one-touch dialling
The position number of a SIM card entry is used for speed
dialling and one-touch dialling.
Dialling a SIM card entry (speed dialling)
– Enter the position (e.g. 2)
fig. 130 of the SIM card entry
you want to dial.
– Press the button. The selected SIM card entry is
displayed.
– Press the “Call” button
page 140, fig. 124 to start
dialling.
Dialling a SIM card entry (one-touch dialling)
– Press and hold one of the buttons 2 to 9. The selected
SIM card entry will be displayed.
–Confirm the Really connect? prompt by pressing the
control button for Ye s. The number will be dialled.Dialling the mailbox (one-touch dialling)
– Press and hold button . The phone number you have
stored for your mailbox will be dialled
page 157.
Changing the position of a SIM card entry
– Press the control button for Ph.book. The phone book
entries will be listed
page 153, fig. 140.
– To jump to a particular entry in the phone book, enter the
initial letter using the normal text entry method.
– To select a SIM card entry, use the navigation button to
scroll up or down.
– Press the control button for Ok.
– Select Edit and then press the control button for Ok. You
can now change the information stored in the selected
SIM card entry.
–Scroll to the Position function
fig. 130 using the navi-
gation button.
– Press the control button for Ok.
– To delete the position shown on the display, press the
control button for Delete.
– Enter the desired position on the keypad.
– Press the control button for Ok.
–Scroll to the Store function using the navigation button.
– Press the control button for Ok to save the changes you
have made.
The telephone numbers stored at positions two to nine in the SIM
card phone book can also be used as one-touch dial numbers.
Fig. 130 Position of a
phone book entry
#
A5
1





!




Menus153
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
•If you switch the call information on the MMI off and on again

page 97, the complete contents of the call lists will be deleted.
Applies to vehicles: with handset for the car telephone kit
“Phone book” menu
– Press the control button for Menu
page 142,
fig. 126.
– Select Phone book using the navigation button.
New entry
•Name - to enter a first name and surname.
•Number - to enter the telephone number for the entry.
•Pos it ion - used for speed dialling and one-touch dialling

page 146. A free position is automatically suggested.
•Store - to store the phone book entry on the SIM card.
Finding an entry
When you enter the initial letter of an entry you want to find, the
cursor jumps through the list to the entries starting with that letter.
When an entry is selected, you can call up the following functions
by pressing the control button for Options:
•Details - to display the name, telephone number and position of
the entry.
•Edit - to edit the name, telephone number and position of the
entry.
•Delete - to delete the selected entry.
•Call - to call the selected entry.
Memory in use
•SIM - SIM card entries are loaded and displayed.
•Telephone - Phone book entries on the mobile phone are loaded
and displayed. To use this function, a mobile phone with SIM Access
Profile must be connected to the car telephone kit and the SIM card
must be in the phone
page 24.
•SIM+Tel. - SIM card entries and phone book entries on the mobile
phone are loaded and displayed. To use this function, a mobile
phone with SIM Access Profile must be connected to the car tele-
phone kit and the SIM card must be in the phone
page 24. If the
SIM card is in the handset, only the SIM card entries will be
displayed.
The memory in use can be set separately on the MMI
page 100.
Displaying the phone book entries
The phone book entries are displayed in alphabetical order together
with a category symbol
fig. 140, e.g. SIM card, private, business,
mobile phone or telephone symbol.
Fig. 139 Phone book
menu
Fig. 140 Phone book
entries
A8










Index 186
Entry in directory
Calling (MMI control console) . . . . . . . 82
Calling (speech dialogue system) . . . 176
Changing / copying . . . . . . . . . . . . . . . . 85
Deleting . . . . . . . . . . . . . . . . . . . . . . . . . 86
Editing . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Finding . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Importing . . . . . . . . . . . . . . . . . . . . . . . . 81
Navigation (MMI control console) . . . . 83
Navigation (speech dialogue system) 176
New entry . . . . . . . . . . . . . . . . . . . . . . . . 80
EPG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
External
AV source . . . . . . . . . . . . . . . . . . . . . 76, 79
Bluetooth devices . . . . . . . . . . . . . . . . . 96
Players . . . . . . . . . . . . . . . . . . . . . . . . . . 18
F
Fader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Fast forward in track (media drive) . . . . . . 65
Favourite stations
Deleting . . . . . . . . . . . . . . . . . . . . . . . . . 61
Switching on/off . . . . . . . . . . . . . . . . . . 60
Filter display . . . . . . . . . . . . . . . . . . . . . . . 124
Forwarding data calls . . . . . . . . . . . . . . . . 99
Forwarding fax calls . . . . . . . . . . . . . . . . . . 99
Forwarding phone calls . . . . . . . . . . . . . . . 99
Frequency . . . . . . . . . . . . . . . . . . . . . . . 54, 56
Function selector button . . . . . . . . . . . . . . 41
G
GALA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
H
Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Bonding handset . . . . . . . . . . . . . . . . . . 27
Entering text . . . . . . . . . . . . . . . . . . . . 143
Menus . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Phoning . . . . . . . . . . . . . . . . . . . . . . . . 145
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Speed dialling . . . . . . . . . . . . . . . . . . . 146
Switching on/off . . . . . . . . . . . . . . . . . 140
Handset display . . . . . . . . . . . . . . . . . . . . 142
Handsfree mode . . . . . . . . . . . . . . . . . . . . 149
Help function
Speech control system . . . . . . . . . . . . 162
Speech dialogue system . . . . . . . . . . 171
I
Importing a telephone number . . . . . . 81, 83
In immediate vicinity . . . . . . . . . . . . . . . . 116
In vicinity of destination . . . . . . . . . . . . . 116
INFO
Audi music interface . . . . . . . . . . . . . . . 69
DAB data services . . . . . . . . . . . . . . . . . 61
MP3 CD . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Traffic reports . . . . . . . . . . . . . . . . . . . 121
Input level . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Intersection zoom (navigation) . . . . . . . . 119iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MMI control console . . . . . . . . . . . . . . . 63
Multi-function steering wheel . . . . . . 130
J
Jack plug . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
K
Keypad lock (handset) . . . . . . . . . . . . . . . 155
L
L band (DAB) . . . . . . . . . . . . . . . . . . . . . . . . 62
Language setting
Handset . . . . . . . . . . . . . . . . . . . . . . . . 155
MMI control console . . . . . . . . . . . . . . . 51
Laser equipment . . . . . . . . . . . . . . . . . . . . . 11
Last calls
Handset . . . . . . . . . . . . . . . . . . . . . . . . 152
MMI control console . . . . . . . . . . . . . . . 91
Multi-function steering wheel . . . . . . 134
Last destinations
Deleting . . . . . . . . . . . . . . . . . . . . . . . . 120
Loading . . . . . . . . . . . . . . . . . . . . . . . . . 114
Last stations (radio)
Deleting . . . . . . . . . . . . . . . . . . . . . . . . . 61
Switching on/off . . . . . . . . . . . . . . . . . . 60
Loading from directory (navigation) . . . . 115
Local stations . . . . . . . . . . . . . . . . . . . . . . . 59





!




Index 190
SOS
Handset . . . . . . . . . . . . . . . . . . . . . . . . 147
MMI control console . . . . . . . . . . . . . . . 89
Sound
Basic settings . . . . . . . . . . . . . . . . . . . . 46
DSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
DSP Bang & Olufsen . . . . . . . . . . . . . . . 48
Volume . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Sound channel (dual channel sound - DVB-T)
77
Sound focus . . . . . . . . . . . . . . . . . . . . . 47, 48
Sound focus (telephone) . . . . . . . . . . 96, 101
Special destinations . . . . . . . . . . . . . . . . . 116
Speech control system . . . . . . . . . . . . . . 160
Speech dialogue system . . . . . . . . . . . . . 169
Deleting name tag . . . . . . . . . . . . . . . . 86
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Name tags . . . . . . . . . . . . . . . . . . . . . . 172
Playing name tag . . . . . . . . . . . . . . . . . 86
Repeat command . . . . . . . . . . . . . . . . . 51
Switching on/off . . . . . . . . . . . . . 137, 170
Volume . . . . . . . . . . . . . . . . . . . . . . 46, 170
Speech recognition . . . . . . . . . . . . . . . . . 167
Speed dialling . . . . . . . . . . . . . . . . . . . . . . 146
Speller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Station list (radio)
Selecting station (MMI control console) .
55
Selecting station (multi-function steering
wheel) . . . . . . . . . . . . . . . . . . . . . . . . 130
Updating . . . . . . . . . . . . . . . . . . . . . . . . 55
Station name (radio) . . . . . . . . . . . . . . . . . 59
Station reception . . . . . . . . . . . . . . . . . . . . 59Stopovers, entering . . . . . . . . . . . . . . . . . 108
STORE
Radio stations . . . . . . . . . . . . . . . . . . . . 57
TV channels . . . . . . . . . . . . . . . . . . . . . . 74
Stored telephone number, dialling . . . . . 94
Storing destination
In directory . . . . . . . . . . . . . . . . . . . . . . 112
Structure of folders . . . . . . . . . . . . . . . . . . 64
Subwoofer . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Surround level . . . . . . . . . . . . . . . . . . . . . . . 48
Switching between calls
Handset . . . . . . . . . . . . . . . . . . . . . . . . 149
MMI control console . . . . . . . . . . . . . . . 95
Multi-function steering wheel . . . . . . 135
Switching off telephone
Car telephone kit . . . . . . . . . . . . . . . . . . 26
Handset . . . . . . . . . . . . . . . . . . . . . . . . 155
Switching on/off
Car telephone kit . . . . . . . . . . . . . . . . . . 26
Handset . . . . . . . . . . . . . . . . . . . . . . . . 140
MMI control console . . . . . . . . . . . . . . . 40
Speech control system . . . . . . . . . . . . 161
Speech dialogue system . . . . . . . . . . 170
T
T9 - automatic word recognition . . 143, 155
Talk button
Mobile phone adapter . . . . . . . . . . . . 161
Multi-function steering wheel . . 137, 161,
170Telephone - speech control system . . . . 160
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Switching on/off . . . . . . . . . . . . . 137, 161
Telephone mode, activating
MMI control console . . . . . . . . . . . . . . . 88
Speech dialogue system . . . . . . . . . . 176
Telephone number
Importing into directory . . . . . . . . . . . . 83
Storing in directory . . . . . . . . . . . . . . . . 93
Telephone settings . . . . . . . . . . . . . . . 96, 101
Telephone volume . . . . . . . . . . . . . . . . . . . 46
Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Television
SeeTV . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
TEXT (radio) . . . . . . . . . . . . . . . . . . . . . . . . . 61
Text messages
Handset . . . . . . . . . . . . . . . . . . . . . . . . 154
MMI control console . . . . . . . . . . . . . . 100
See alsoText messages . . . . . . . 100, 154
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
TMC . . . . . . . . . . . . . . . . . . . . . . . . . . 122, 124
Top categories . . . . . . . . . . . . . . . . . . . . . 114
Top destination . . . . . . . . . . . . . . . . . . 84, 116
TP . . . . . . . . . . . . . . . . . . . . . . . . . 58, 121, 123
Track (media drive)
Next/previous . . . . . . . . . . . . . . . . . . . . . 65
Scanning . . . . . . . . . . . . . . . . . . . . . . . . 66
Selecting . . . . . . . . . . . . . . . . . . . . . . . . 65
Track display (MP3 CD) . . . . . . . . . . . . . . . . 68
