2008 AUDI A8 CD player

Playing media69
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Other settings for Audi music
interface
Applies to vehicles: with Audi music interface
Repeating (repeat/shuffle)
Important: A portable player must be connected via an iPod
adapter cable
page 16 or via a USB/mini USB adapter
cable
page 17.
– Select: Function selector button > source Audi
music interface > function selector button >
Repeat/shuffle.
Repeat/shuffle Tr a c k
The track currently playing will be repeated. Interface Repeat will
appear in the heading. The shuffle function cannot be activated.
Repeat/shuffle List
The tracks on the list currently playing will be repeated. If the shuffle
function is active, the tracks on the current track list will be played
in random order.
If you have connected a portable player via a USB/mini USB adapter
cable, you can select List and additionally set the function Include
subfolders. All tracks in the subfolders of the current list will then
also be repeated.
Repeat/shuffle off
The repeat function is switched off. All tracks or lists on the
connected device will not be repeated. If the shuffle function is
active, all tracks or lists will be played in random order.
Note
•The shuffle function also depends on these settings
page 66.
•If the shuffle function is activated and you change the repeat
option from List to off, the current track will stop playing and a new
track will be selected at random.
Applies to vehicles: with Audi music interface
Track information (INFO)
Important: A portable player must be connected via an iPod
adapter cable
page 16 or via a USB/mini USB adapter
cable
page 17.
– Select: Function selector button > source Audi
music interface > control button CD control > INFO (track
information).
Information on the current track (e.g. artist) stored to the ID3/ WMA
tag will be displayed.
Applies to vehicles: with Audi music interface
Track information
Important: A portable player must be connected via an iPod
adapter cable
page 16 or via a USB/mini USB adapter
cable
page 17.
– Select: Function selector button > function
selector button > Track information.
If ID3/ WMA tag information on the current track (e.g. artist) is avail-
able and this function is active, it will be displayed as a pop-up for
the track currently playing.
MEDIA
SETUPMEDIA
MEDIA
SETUP





!




Playing media 70
Applies to vehicles: with Audi music interface
Input level
Important: A portable player must be connected via an
adapter cable with 3.5 mm jack plug
page 18.
– Select: Function selector button > source Audi
music interface > function selector button >
Input level.
The volume of the portable player will be adapted to the MMI
system. We recommend setting the volume of the portable player to
about 70 percent of the maximum volume.
MEDIA
SETUP










Calling up traffic information121
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Calling up traffic information
Introduction
If desired, your MMI system will inform you about the current traffic
situation both on the screen and audibly.
You are probably familiar with the traffic reports that most radio
stations transmit at regular intervals. Your MMI system automati-
cally records these reports
page 121 for up to an hour after the
MMI has been switched off. The Traffic Programme reception is indi-
cated by the TP symbol when the radio, the CD player or the Audi
music interface*
21) is switched on
page 58.
In addition, more and more radio stations transmit traffic messages
that are received automatically and inaudibly by your MMI system.
You can set the system to display these messages on your MMI
display. Another even more convenient function is that the MMI
system uses these reports when the dynamic navigation function is
activated to guide you around traffic obstructions such as conges-
tions whenever possible
page 117.
The reception of traffic messages is indicated by the TMC symbol at
the top of the display when the navigation mode is activated:
Calling up traffic reports (TP memo)
Traffic reports are stored along with the station name and
the time of transmission.
Important: The Traffic Programme function must be
switched on
page 58.
– Press the function selector button marked .
21)Still under development at the time of printing.
TMC symbolsExplanation
TMC symbol litTMC stations are available and the dynamic
navigation is switched on
page 117.
TMC symbol not
litTMC stations are available; the dynamic navi-
gation is switched off.
TMC symbol
crossed outTMC stations are not available; the dynamic
navigation is switched on.
TMC symbol
is not displayedTMC stations are not available; the dynamic
navigation is switched off.
Fig. 106 List of traffic
reports
INFO











Basic operation 128
Basic operation
Applies to vehicles: with multi-function steering wheel
Introduction
You can use the multi-function steering wheel to call up
the following functions in the driver information system
one after the other: Navigation*, Telephone*, Radio, CD
player, Audi music interface* and TV*.
Using the multi-function steering wheel
fig. 110, you can operate
certain functions on the radio, the CD player, the Audi music inter-
face*
22), the TV*, the telephone* and the navigation system* very conveniently and without having to take your hands off the steering
wheel.
The available functions are displayed in the driver information
system
fig. 111. In addition, you can use the multi-function
steering wheel to switch the speech dialogue system* or the tele-
phone speech control system* on and off and to adjust the volume
on these systems.
These functions can be operated by pressing and scrolling buttons
to
fig. 110.
•Press the button repeatedly to switch between the
navigation* mode, the telephone* mode and the current audio
source. The selected function will appear in the display of the driver
information system
fig. 111. If a sub-menu is displayed in the
driver information system, you can exit this menu again by pressing
the button.
•Scroll the left thumbwheel to select an option within one of
the following functions: radio, CD, Audi music interface*22), TV*,
telephone* and navigation*.
•The speech dialogue system* and the telephone speech control
system* are activated by pressing the talk button . Press and hold
the talk button again to deactivate the speech dialogue / speech
control system.
•Scroll the right thumbwheel up/down to raise/lower the
volume as desired.
Note
•The on-board computer is also displayed in the driver informa-
tion system. Please refer to your Owner's Manual for a detailed
description.
Fig. 110 Controls on
the multi-function
steering wheel
Fig. 111 Display in the
driver information
system
22)Still under development at the time of printing.
A1A4
MODEA2
MODE
A1
A3
A4











Basic operation131
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control Would you like to find out more about the media function in your
vehicle? You can find a detailed description on
page 63, “Playing
media”.
Applies to vehicles: with multi-function steering wheel
Selecting a track
Important: A list of tracks must be displayed
page 130,
fig. 114 /
fig. 115.
– Scroll the left thumbwheel
page 128, fig. 110 to mark a
track.
– Press the left thumbwheel to select the track.
Note
You can select a CD in the CD changer or a folder on a portable
player via the MMI control console
page 12.
Applies to vehicles: with multi-function steering wheel
Pausing and resuming (media drive)
Important: A track must be playing
page 63.– Scroll the right thumbwheel all the way down to pause
the track that is currently playing.
– To continue playback, scroll the right thumbwheel
upwards.
Television
Applies to vehicles: with multi-function steering wheel and TV (analog and analog/digital)
Calling up the TV menu
Important: The TV function on the MMI system must be
switched on
page 71.
– Press the button
page 128, fig. 110 repeatedly
until a list of TV channels appears in the display of the
driver information system.
Would you like to find out more about the TV function in your
vehicle? You can find a detailed description on
page 71,
“ Television”.
Fig. 115 Track list of a
folder
Fig. 116 List of TV
channels
MODE










Index 186
Entry in directory
Calling (MMI control console) . . . . . . . 82
Calling (speech dialogue system) . . . 176
Changing / copying . . . . . . . . . . . . . . . . 85
Deleting . . . . . . . . . . . . . . . . . . . . . . . . . 86
Editing . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Finding . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Importing . . . . . . . . . . . . . . . . . . . . . . . . 81
Navigation (MMI control console) . . . . 83
Navigation (speech dialogue system) 176
New entry . . . . . . . . . . . . . . . . . . . . . . . . 80
EPG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
External
AV source . . . . . . . . . . . . . . . . . . . . . 76, 79
Bluetooth devices . . . . . . . . . . . . . . . . . 96
Players . . . . . . . . . . . . . . . . . . . . . . . . . . 18
F
Fader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Fast forward in track (media drive) . . . . . . 65
Favourite stations
Deleting . . . . . . . . . . . . . . . . . . . . . . . . . 61
Switching on/off . . . . . . . . . . . . . . . . . . 60
Filter display . . . . . . . . . . . . . . . . . . . . . . . 124
Forwarding data calls . . . . . . . . . . . . . . . . 99
Forwarding fax calls . . . . . . . . . . . . . . . . . . 99
Forwarding phone calls . . . . . . . . . . . . . . . 99
Frequency . . . . . . . . . . . . . . . . . . . . . . . 54, 56
Function selector button . . . . . . . . . . . . . . 41
G
GALA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
H
Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Bonding handset . . . . . . . . . . . . . . . . . . 27
Entering text . . . . . . . . . . . . . . . . . . . . 143
Menus . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Phoning . . . . . . . . . . . . . . . . . . . . . . . . 145
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Speed dialling . . . . . . . . . . . . . . . . . . . 146
Switching on/off . . . . . . . . . . . . . . . . . 140
Handset display . . . . . . . . . . . . . . . . . . . . 142
Handsfree mode . . . . . . . . . . . . . . . . . . . . 149
Help function
Speech control system . . . . . . . . . . . . 162
Speech dialogue system . . . . . . . . . . 171
I
Importing a telephone number . . . . . . 81, 83
In immediate vicinity . . . . . . . . . . . . . . . . 116
In vicinity of destination . . . . . . . . . . . . . 116
INFO
Audi music interface . . . . . . . . . . . . . . . 69
DAB data services . . . . . . . . . . . . . . . . . 61
MP3 CD . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Traffic reports . . . . . . . . . . . . . . . . . . . 121
Input level . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Intersection zoom (navigation) . . . . . . . . 119iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MMI control console . . . . . . . . . . . . . . . 63
Multi-function steering wheel . . . . . . 130
J
Jack plug . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
K
Keypad lock (handset) . . . . . . . . . . . . . . . 155
L
L band (DAB) . . . . . . . . . . . . . . . . . . . . . . . . 62
Language setting
Handset . . . . . . . . . . . . . . . . . . . . . . . . 155
MMI control console . . . . . . . . . . . . . . . 51
Laser equipment . . . . . . . . . . . . . . . . . . . . . 11
Last calls
Handset . . . . . . . . . . . . . . . . . . . . . . . . 152
MMI control console . . . . . . . . . . . . . . . 91
Multi-function steering wheel . . . . . . 134
Last destinations
Deleting . . . . . . . . . . . . . . . . . . . . . . . . 120
Loading . . . . . . . . . . . . . . . . . . . . . . . . . 114
Last stations (radio)
Deleting . . . . . . . . . . . . . . . . . . . . . . . . . 61
Switching on/off . . . . . . . . . . . . . . . . . . 60
Loading from directory (navigation) . . . . 115
Local stations . . . . . . . . . . . . . . . . . . . . . . . 59





!




Index187
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
M
Mailbox
Handset . . . . . . . . . . . . . . . . . . . . . 146, 155
MMI control console . . . . . . . . 98, 99, 102
Map colours . . . . . . . . . . . . . . . . . . . . . . . . 118
Map content . . . . . . . . . . . . . . . . . . . . . . . 119
Map display . . . . . . . . . . . . . . . . . . . . . . . . 110
Map orientation . . . . . . . . . . . . . . . . . . . . . 118
Map type . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Measurement units . . . . . . . . . . . . . . . . . . . 51
Memory (radio)
Deleting stations . . . . . . . . . . . . . . . . . . 61
Moving stations . . . . . . . . . . . . . . . . . . . 58
Selecting station (MMI control console) .
58
Selecting station (multi-function steering
wheel) . . . . . . . . . . . . . . . . . . . . . . . . . 130
Storing stations . . . . . . . . . . . . . . . . . . . 57
Memory (TV)
Deleting channels . . . . . . . . . . . . . . . . . 76
Moving channels . . . . . . . . . . . . . . . . . . 75
Selecting channel (MMI control console)
75
Selecting channel (multi-function steering
wheel) . . . . . . . . . . . . . . . . . . . . . . . . . 132
Storing channels . . . . . . . . . . . . . . . . . . 74
Memory capacity (directory) . . . . . . . . . . . 86
Memory settings . . . . . . . . . . . . . . . . 100, 102
Menu language
Handset . . . . . . . . . . . . . . . . . . . . . . . . . 155
MMI control console . . . . . . . . . . . . . . . 51
Menus (handset) . . . . . . . . . . . . . . . . 149, 151Messages
SeeText messages . . . . . . . . . . . 100, 154
Microphone on/off
Handset . . . . . . . . . . . . . . . . . . . . . . . . . 149
MMI control console . . . . . . . . . . . 95, 101
Missed calls
Handset . . . . . . . . . . . . . . . . . . . . . . . . . 152
MMI control console . . . . . . . . . . . . . . . 91
Multi-function steering wheel . . . . . . 133
MMI control console . . . . . . . . . . . . . . . . . . 41
MMI display
Brightness . . . . . . . . . . . . . . . . . . . . . . . 51
Navigation display . . . . . . . . . . . . . . . . 110
Speller . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Standard menus . . . . . . . . . . . . . . . . . . 42
Switching on/off . . . . . . . . . . . . . . . . . . 45
Thermometer . . . . . . . . . . . . . . . . . . . . . 72
TV display . . . . . . . . . . . . . . . . . . . . . . . . 72
MMI system . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Controls and displays . . . . . . . . . . . . . . . 9
Display overview . . . . . . . . . . . . . . . . . . 40
Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Switching on/off . . . . . . . . . . . . . . . . . . 40
Mobile phone
Bluetooth (car telephone kit) . . . . . 26, 28
Bluetooth (phone pre-installation) . . . . 22
Inserting in phone pre-installation . . . 21
Searching . . . . . . . . . . . . . . . . . . . . . . . . 96
With Hands-Free Profile . . . . . . . . . . . . 24
With SIM Access Profile . . . . . . . . . . . . 24Mobile phone adapter
Inserting mobile phone . . . . . . . . . . . . . 21
Removing / installing . . . . . . . . . . . . . . . 20
Removing mobile phone . . . . . . . . . . . . 21
Moving stored station . . . . . . . . . . . . . . . . . 58
MP3
MMI control console . . . . . . . . . . . . . . . 63
Multi-function steering wheel . . . . . . 130
MP3 files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
MP3 player . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Multi-function steering wheel . . . . . . . . . 128
Mute
MMI control console . . . . . . . . . . . . . . . 45
Multi-function steering wheel . . . . . . 129
N
Name tags (speech control system) . . . . 164
Deleting . . . . . . . . . . . . . . . . . . . . . 165, 166
Dialling a number . . . . . . . . . . . . . . . . 163
Playing the phone book . . . . . . . . . . . 163
Storing . . . . . . . . . . . . . . . . . . . . . 164, 165
Name tags (speech dialogue system) . . . 172
Calling directory entry . . . . . . . . . . . . . 176
Deleting . . . . . . . . . . . . . . . . . . . . . . 51, 173
Deleting station . . . . . . . . . . . . . . . . . . 174
Navigating to directory entry . . . . . . . 176
Playing . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Selecting CD . . . . . . . . . . . . . . . . . . . . . 175
Selecting station . . . . . . . . . . . . . . . . . 174
Selecting track (CD) . . . . . . . . . . . . . . . 175
Storing . . . . . . . . . . . . . . . . . . . . . . . . . 172
Traffic Programme . . . . . . . . . . . . . . . . 174
