2008 Acura TSX buttons

Î
Î
Î
Î Only on vehicles equipped with navigation system. Ref er to the navigation system manual.
To use the horn, press the pad around the ‘‘Acura’’ logo.
1:
2:
Your Vehicle at a Glance
4
WINDSHIELD
WIPERS/WASHERS
MOONROOF
SWITCH
REMOTE AUDIO
CONTROL BUTTONS
MULTI-INFORMATION
BUTTONSCRUISE CONTROL
BUTTONS
REAR WINDOW
DEFOGGER BUTTON
HAZARD WARNING
BUTTON
HORN
INSTRUMENT PANEL BRIGHTNESS
STEERING WHEEL ADJUSTMENT PASSENGER AIRBAG
OFF INDICATOR
HEADLIGHTS/TURN SIGNALS/FOG LIGHTS
VEHICLE STABILITY
ASSIST (VSA) SYSTEM
OFF SWITCH
Vehicle without navigation system is shown. SEAT HEATER SWITCHES
(P.269)
(P.121-122)
(P.202)
(P.150)
(P.125) (P.123)
(P.120)
(P.33)(P.124)
(P.124)
(P.206)
(P.137)
(P.71,72)
BLUETOOTH
HANDSFREELINKBUTTONS/
VOICE CONTROL BUTTONS
(P.214)1
2
\f—\f—
y
y
(\fy\f\f\fy
2008 TSX

After all occupants have adjusted
their seats and head restraints, and
put on their seat belts, it is very
important that they continue to sit
upright, well back in their seats, with
their feet on the floor, until the
vehicle is parked and the engine is
off.
This could cause
very serious injuries in a crash.
See page f or additional
inf ormation about your seat belts
and how to take care of them.
If a seat belt does not seem to work
properly, it may not protect the
occupant in a crash.
Using a seat
belt that is not working properly can
result in serious injury or death.
Have your dealer check the belt as
soon as possible.
The front seats have adjustable seat
belt anchors. To adjust the height of
an anchor, press and hold the release
buttons, and slide the anchor up or
down as needed (it has f our
positions). Sitting improperly can increase the
chance of injury during a crash. For
example, if an occupant slouches,
lies down, turns sideways, sits
forward, leans forward or sideways,
or puts one or both f eet up, the
chance of injury during a crash is
greatly increased.
19 Maintain a Proper Sitting
Position
6.
Never place t he shoulder port ion of a
lap/shoulder belt under your arm orbehind your back.
No one should sit in a seat wit h aninoperat ive seat belt .
Protecting A dults and Teens
16
RELEASE BUTTONS
\f—\f—
y
y
(\fy\f\f
y
2008 TSX

The multi-inf ormation display in the
instrument panel displays various
inf ormation and messages when the
ignition switch is in the ON (II)
position. Some of the messages help
you operate your vehicle more
comf ortably.
Others help to keep you aware of the
periodic maintenance your vehicle
needs f or continued trouble-f ree
driving.When you turn the ignition switch to
the ACCESSORY (I) position, the
display shows ‘‘Goodbye.’’
There are three types of messages;
normal display messages, engine oil
lif e and maintenance messages, and
system messages.
You can also customize some vehicle
control settings to your liking with
the multi-inf ormation display and the
two buttons on the steering wheel
(see page ).
When you unlock and open the
driver’s door with the remote
transmitter, the display shows
‘‘Welcome Driver 1’’ or ‘‘Welcome
Driver 2’’ depending on which
remote transmitter you use. The
driver’s ‘‘ID’’ is detected by the
transmitter. For more information
about driver’s ‘‘ID’’, see page .If you use the key to unlock the
driver’s door, the display only shows
‘‘Welcome.’’ This means the system
cannot recognize either ‘‘Driver 1’’ or
‘‘Driver 2.’’ In this case, you cannot
use the customized settings on the
multi-inf ormation display (see page
).
86
13286
CONT INUED
Normal Display Messages
Multi-Inf ormation Display
Inst rument s and Cont rols
69
\f—\f—
y
y
(\fy\f\fy
2008 TSX

Î
Î
Î
Î
Only on vehicles equipped with navigation system. Ref er to the navigation system manual.
To use the horn, press the pad around the ‘‘Acura’’ logo.
1:
2:
Controls Near the Steering Wheel
Inst rument s and Cont rols
119
HEADLIGHTS/TURN SIGNAL/
FOG LIGHTS
REMOTE AUDIO
CONTROL BUTTONS
REAR WINDOW
DEFOGGER BUTTON
CRUISE CONTROL
BUTTONS
WINDSHIELD WIPERS/
WASHERS
HAZARD WARNING
BUTTON
MULTI-INFORMATION
BUTTONS
MOONROOF
SWITCH
(P.150) PASSENGER AIRBAG
OFF INDICATOR
(P.33)
(P.121-122)
(P.120)
(P.124)
(P.124)
(P.71,72) (P.123)
INSTRUMENT PANEL BRIGHTNESS
(P.206)
VEHICLE STABILITY
ASSIST (VSA) SYSTEM
OFF SWITCH
(P.202)
Vehicle without navigation system is shown. SEAT HEATER SWITCHES
(P.137)
HORN
(P.269) (P.125)
STEERING WHEEL
ADJUSTMENT
BLUETOOTH
HANDSFREELINKBUTTONS/
VOICE CONTROL BUTTONS
(P.214)
1
2
\f—\f—
y
\fy
(\fy\f
y
2008 TSX

µµ
To change the ‘‘INTERIOR LIGHT
DIMMING TIME,’’ see page .
If you unlock the doors with the
remote transmitter, but do not open
anydoorswithin30seconds,the
doors automatically relock and the
security system sets. To change this
setting, refer to ‘‘SECURITY
RELOCK TIMER’’ on page .
Each remote transmitter also
activates the Driving Position
Memory System and changes the
‘‘MEMORY POSITION LINK’’
setting according to that remote (see
page ).
Pressthisbuttonfor
about 1 second to attract attention;
thehornwillsoundandtheexterior
lights will f lash f or about 30 seconds.
To cancel panic mode, press any
other button on the remote
transmitter, or turn the ignition
switch to the ON (II) position.
Pressthisbuttonfor
about 1 second to open the trunk.
You cannot open the trunk if the key
is in the ignition switch. Standing outside the vehicle with
all the doors shut, push the lock
and unlock buttons at the same
time until the LED on the remote
transmitter blinks 2 times.
Open and shut the driver’s door.
Use the remote transmitter to lock
and unlock the driver’s door.
Verify that the remote transmitter
is in the linked mode. Turn the
ignition switch to the ON (II)
position. The MID display should
read ‘‘Welcome Driver 1’’ or
‘‘Welcome Driver 2’’, depending on
which remote you just linked (the
remote number is on the back of
the remote transmitter).
If theMIDdisplayonlyreads
‘‘Welcome Driver’’ once the ignition
switch is turned to the ON (II)
position, the link f rom the remote
transmitter to the vehicle has failed.
Repeat the procedure. If the link still
f ails, see your dealer.
106
115 1.
2.
3.
4.
143
Recalling a Memorized Driving
Position
PA NIC
TRUNK L inking Your Remote
Transmitter
Remote Transmitter
132
DRIVER 1 REMOTE DRIVER 2 REMOTE
——
y
y
(y
y
2008 TSX

Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.
To turn it back on, repeat this
procedure. The LED will come on
for 1 second to indicate the feature
has been turned on.
The driving position memory
activated (Driver 1, Driver 2) is
shownonthebackof each
transmitter. Make sure you store
your desired driving position in the
memory that is activated by the
transmitter you normally carry.
You can turn off this system
activation. Press and hold the LOCK
and UNLOCK buttons at the same
time. The LED in the remote
transmitter will blink twice. Then
release the buttons. Doing this also
cancels the ‘‘MEMORY POSITION
LINK’’ setting f or that remote and
restores the default settings.
Any of these actions will stop the
system’s automatic seat adjustment:
Pressing either memory button or
the MEMO button on the driver’s
door.
Pressing any of the seat
adjustment switches.
Shif ting out of Park (A/T), or into
reverse (M/T).
When you open the driver’s door
after unlocking it with the remote
transmitter, you will hear a beep
(depending on the ‘‘KEYLESS
LOCK ACKNOWLEDGEMENT’’
setting see page ). The driver’s
seat will move to the positions stored
inthememorylocation
corresponding to the remote in use.
You will hear two beeps when the
seat stops moving.
If it takes several pushes on the
button to lock or unlock the doors,
replace the battery as soon as
possible.
Battery type: CR2025
113
CONT INUED
Remote Transmitter Care
Replacing the Transmitter Battery
Remote Transmitter
Inst rument s and Cont rols
133
\f—\f—
y
\f\fy
(\fy\f
y
2008 TSX

CONT INUED
Press and release the MEMO
button on the driver’s door. You
will hear a beep. Then, both
indicators in the memory buttons
will start to blink. Press and hold
one of the memory buttons (1 or
2) within 5 seconds af ter you press
the MEMO button. When the
system completes storing a new
driving position, you hear two
beeps. The indicator in the stored
memory button will come on.
Store a driving position only when
the vehicle is parked.
Turn the ignition switch to the ON
(II) position. You cannot add a
new driving position to the
memory unless the ignition switch
is in the ON (II) position. You can
recall a memorized position with
the ignition switch in any position.
Adjust the seat to a comfortable
position (see page ).
Your vehicle has a memory feature
f or the driver’s seat position.
Two seat positions can be stored in
separate memories. You select a
memorized position by pushing the
appropriate button or appropriate
remote transmitter (Driver 1 or
Driver 2).
This setting can be linked or
unlinked with the remote transmitter.
To customize the setting ‘‘MEMORY
POSITION LINK’’, see page .
3.
104 138
1.
2.
Driving Position Memory System
Driving Position Memory System Storing a Driving Position in
Memory
Inst rument s and Cont rols
143
MEMORY BUTTONSMEMO BUTTON
INDICATORS
\f—\f—
y
\fy
(\fy\f
y
2008 TSX

The system will move the driver’s
seat to the memorized position. The
indicator in the selected memory
button will flash during movement.
When the adjustment is complete,
you will hear two beeps, and the
indicator will stay on.You cannot select a memorized
position if the transmission is in
reverse. Shif t to another gear,
then select a position.
If the parking brake is not set, you
must press and hold the memory
button until the adjustment is
complete.
Doing any of the f ollowing af ter
pressing the MEMO button will
cancel the storing procedure.
Not pressing a memory button
within 5 seconds.
Pressing the MEMO button again
within 5 seconds.
Readjusting the seat position.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button’s memory. If
you want to add a new position while
retaining the current one, use the
other memory button.
All stored driving positions will be
lost if your vehicle’s battery goes
dead or is disconnected. Press the desired memory button
(1 or 2) until you hear a beep.
Make sure the parking brake is set
(M/T) or the shif t lever is in Park
(A/T).
To select a memorized position, do
this:
1.
2.
Notes f or vehicles with M/T
Driving Position Memory System
Selecting a Memorized Position
144
MEMORY BUTTONS
\f—\f—
y
\f
y
(\fy\f
y
2008 TSX
