2008 Acura RL steering wheel

2008 RL Online Reference Owner's Manual

Contents

Owner's Identification Form

Introduction .............................................................................................................................\
............................. i

A Few Words About Safety ......................................................................\
........................................................ iii
Your Vehicle at a Glance (main controls) ....................................................\
................................................ 4
Driver and Passenger Safety (seat belts, SRS, and child protection) ......................\
.............................. 7
Instruments and Controls
(indicators, gauges, multi-information display, dashboard and steering column)
.......... 59
Features (
climate control,audio,steering wheel,security,cruise control,HomeLink,an\
d other convenience items
) ............ 197
Before Driving (fuel, vehicle break-in, and cargo loading) ...........................................\
........................... 327
Driving (engine and transmission operation) .........................................\
....................................................... 345
Maintenance (minders, fluid checking, minor services, and vehicle storage)......................................... 385
Taking Care of the Unexpected (flat tire, dead battery, overheating, fuses) ..................................... 431
Technical Information (vehicle specifications, tires, and emissions controls) ....................................... 461
Warranty and Customer Relations (U. S. and Canada only) (warranty and contact information) ... 477
Authorized Manuals (U. S. only) (how to order) ..............................................\
........................................... 481
Index ......................................................................\
......................................................... ........................................ I

Service Information Summary ( fluid capacities and tire pressures)
\
\
1 31SJA630

Î
Î
Î
Î
ÎÎ Î
Î
Î
ÎÎ
Î
To use the horn, press the center pad of the steering wheel.
If equipped.
1:
2:
3:
4: Canadian models only
Ref er to the navigation system manual.
Your Vehicle at a Glance
Your Vehicle at a Glance
5
VEHICLE STABILITY ASSIST (VSA)
SYSTEM OFF SWITCH
STEERING WHEEL AUDIO
CONTROLS
COLLISION MITIGATION
BRAKE SYSTEM (CMBS)
OFF SWITCH
ADAPTIVE FRONT LIGHTING
SYSTEM (AFS) OFF SWITCH HORN
VOICE CONTROL
BUTTONS
STEERING WHEEL
ADJUSTMENTS
HEADLIGHT WASHER
SWITCH
MIRROR CONTROLS
HEADLIGHTS/
TURN SIGNAL/
FOG LIGHTS
(P.140,142)
(P.138) (P.147) DISTANCE
BUTTONPASSENGER AIRBAG
OFF INDICATOR
(P.35)
REAR WINDOW
DEFOGGER BUTTON
(P.146)/
HEATED MIRROR
BUTTON
CRUISE CONTROL
BUTTONS
ADAPTIVE CRUISE
CONTROL (ACC)
BUTTONS
MULTI-INFORMATION
BUTTONS
SEAT HEATER
SWITCHES
SEAT HEATER AND
SEAT VENTILATION
BUTTONS
(P.159)
(P.71)(P.178)/
(P.179)
(P.144) INSTRUMENT
PANEL BRIGHTNESS
HAZARD WARNING
BUTTON
PADDLE SHIFTERS
(P.145)(P.137) (P.145) WINDSHIELD
WIPER/WASHER
(P.351)
(P.364)
(P.378)
(P.159) (P.239)(P.289,294)
(P.265) (P.281,285)
(P.277)/
(P.309)
BLUETOOTH
HANDSFREELINKBUTTONS
2
2 1
4
3
22
2
——
yy
(y
y
2008 RL

The most important things you need
to know about your airbags are:Always wear
your seat belt properly, and sit
upright and as f ar back f rom the
steering wheel as possible while
allowing f ull control of the vehicle. A
f ront passenger should move their
seat as far back from the dashboard
as possible. The rest of this section gives more
detailed inf ormation about how you
can maximize your saf ety.
Remember, however, that no saf ety
system can prevent all injuries or
deaths that can occur in a severe
crash, even when seat belts are
properly worn and the airbags deploy.
They are designed to supplement
the seat belts.
To do their job, airbags must
inf late with tremendous f orce. So
while airbags help save lives, they
can cause minor injuries or more
serious or even fatal injuries if
occupants are not properly
restrained or sitting properly.
Your Vehicle’s Saf ety Features
What you should do:
Airbags do not replace seat belts.
A irbags of f er no prot ect ion in rearimpact s, or minor f ront al or sidecollisions.
Airbags can pose serious hazards.
12
\f—\f—
y\f
\f
y
(\fy\f\f
y
2008 RL

If you sit too close to the steering
wheel or dashboard, you can be
seriously injured by an inf lating f ront
airbag, or by striking the steering
wheel or dashboard.Adjust the driver’s seat-back to a
comf ortable, upright position,
leaving ample space between your
chest and the airbag cover in the
center of the steering wheel.
Passengers with adjustable seat-
backs should also adjust their seat-
back to a comf ortable, upright
position.
If you cannot get f ar enough away
f rom the steering wheel and still
reach the controls, we recommend
that you investigate whether some
type of adaptive equipment may help.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that drivers
allow at least 10 inches (25 cm)
between the center of the steering
wheel and the chest. In addition to
adjusting the seat, you can adjust the
steering wheel up and down, and in
and out (see page ).
See page f or how to adjust the
f ront seats.
147 155
CONT INUED
Adjust the Seat-Backs
3.
Protecting A dults and Teens
Driver and Passenger Saf ety
15
Sitting too close to a front
airbag can result in serious
injury or death if the front
airbags inflate.
Always sit as far back from the
front airbags as possible.
\f—\f—
y\f
y
(\fy\f\f\fy
2008 RL

Î
Your airbag system includes:Two side airbags, one f or the
driver and one f or a f ront
passenger. The airbags are stored
in the outer edges of the seat-
backs. Both are marked ‘‘SIDE
AIRBAG’’ (see page ).
Two side curtain airbags, one f or
each side of the vehicle. The
airbags are stored in the ceiling,
above the side windows. The front
and rear pillars are marked ‘‘SIDE
CURTAIN AIRBAG’’ (see page ).
Two SRS (supplemental restraint
system) f ront airbags. The driver’s
airbag is stored in the center of
the steering wheel; the f ront
passenger’sairbagisstoredinthe
dashboard. Both are marked ‘‘SRS
AIRBAG’’ (see page ).
32
34 29
CONT INUED
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
27
(12)
(15)
(14)
(13)
(11) (13)
(13) Side Impact Sensors (Second)
(14) Rear Safing Sensor
(15) Side Curtain Airbags
(11) E-pretensioner Control Unit
(12) Front Impact Sensors
\f—\f—
y\fy
(\fy\f\fy
2008 RL

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .60
............................
Instrument Panel .61
..........
Instrument Panel Indicators .62
.............................................
Gauges .70
...................
Temperature Gauge .70
..................................
Fuel Gauge .70
.............
Multi-Inf ormation Display .71
Controls Near the Steering
.........................................
Wheel .136
Windshield Wipers and .....................................
Washers .137
.......
Turn Signals and Headlights .140
.................................
Fog Lights .142
.........
Daytime Running Lights .142
Automatic Lighting Off
...................................
Feature .142
Adaptive Front Lighting System
..........................................
(AFS) .143
...............
Hazard Warning Button .145
......
Instrument Panel Brightness .145
...............
Rear Window Def ogger .146
......
Steering Wheel Adjustments .147
.............................
Keys and Locks .149
......................
Immobilizer System .150
..............................
Ignition Switch .151
....................................
Door Locks .152 ..............................................
Trunk .153
......
Emergency Trunk Opener .154
................
Childproof Door Locks .154
...............................................
Seats .155
...........................................
Mirrors .159
Driving Position Memory
........................................
System .160
................
Keyless Access System .163
..................................
Seat Heaters .178
Seat Heaters and Seat
.................................
Ventilation .179
............................
Power Windows .181
.......................................
Moonroof .184
...............................
Parking Brake .187
.........
Interior Convenience Items .188
..................................
Glove Box .189
.....................
Beverage Holders .190
.............
Console Compartment .191
..................................
Sun Visors .192
........
Accessory Power Sockets .192
...........................
Rear Ashtrays .193
..................
Front Door Pockets .193
..............
Power Rear Sunshade .194
..............
Integrated Sunshades .195
...............................
Interior Lights .196
Instruments and Controls
Inst rument s and Cont rols
59
\f—\f—
y\f
y
(\fy\f\fy
2008 RL

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.This indicator has three f unctions:
Itcomesonasareminderthatyou
have turned off the vehicle
stability assist (VSA) system.
It flashes when VSA is active (see
page ).
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. For more inf ormation, see
page . It comes on along with the VSA
system indicator if there is a
problem with the VSA system.
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page ).
If itcomesonandstaysonatany
other time, or it does not come on
when you turn the ignition switch to
the ON (II) position, there is a
problem with the VSA system. You
will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display (see page ).
Take your vehicle to a dealer to have
it checked. Without VSA, your
vehicle still has normal driving ability,
but will not have VSA traction and
stability enhancement. For more
inf ormation, see page . This indicator comes on when you
turn on the fog lights. For more
inf ormation, see page .
This indicator comes on with the
high beam headlights. For more
inf ormation, see page .
This indicator also comes on with
reduced brightness when the
daytime running lights (DRL) are on
(see page ).
This indicator comes on when you
turn on the cruise control system by
pressing the CRUISE button on the
steering wheel (see page ).
1.
2.
3.
78 78142
140
142
378 378377
277
On models without adaptive cruisecontrol (ACC)
Instrument Panel Indicators
Vehicle Stability Assist
(VSA ) System Indicator VSA A ctivation Indicator Fog L ight Indicator
High Beam Indicator
Cruise Main Indicator
Inst rument s and Cont rols
65
\f—\f—
y\f\fy
(\fy\f\f\fy
2008 RL

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
When you push the ACC button on
the steering wheel, this indicator
comes on green. You will also see
‘‘ACC’’ on the multi-inf ormation
display.
If the indicator comes on orange,
there is a problem with the ACC
system. You will also see a ‘‘CHECK
ACC SYSTEM’’ message on the
multi-inf ormation display (see page). Take your vehicle to your
dealer to have it checked. For more
inf ormation, see page . This indicator is in the f uel gauge. It
comesonasareminderthatyou
must ref uel soon. You will also see a
‘‘FUEL LOW’’ message on the multi-
inf ormation display (see page ).
When the indicator comes on, there
is about 2.69 U.S. gal (10.2
)of fuel
remaining in the tank bef ore the
needle reaches E. There is a small
reserve of f uel remaining in the tank
when the needle does reach E. If the indicator blinks while driving,
pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If this indicator comes on at
any other time, there is a problem in
the SH-AWD system. You will also
see a ‘‘CHECK SH-AWD SYSTEM’’
message on the multi-inf ormation
display(seepage ).Takeyour
vehicle to a dealer to have it checked.
For more inf ormation, see page .
If it comes on while driving, it
indicates the dif f erential
temperature is too high.
You will also see a ‘‘SH-AWD DIFF
TEMP. HIGH’’ message on the
multi-inf ormation display (see page
).
79
79
280 78
356
78
On models with adaptive cruise control (ACC)
Instrument Panel Indicators
A daptive Cruise Control
(A CC) Indicator L ow Fuel Indicator Super Handling-A ll
Wheel Drive (SH-AWD)
Indicator
66
LOW FUEL INDICATOR
\f—\f—
y\f

\fy
(\fy\f\f
y
2008 RL
