2008 Acura MDX Vehicle stability

This section gives you tips on
starting the engine under various
conditions, and how to operate the
automatic transmission. It also
includes important inf ormation on
parking your vehicle, the braking
system, the super handling-all wheel
stability assist (VSA) system, active
damper system, the tire pressure
monitoring system (TPMS), and
f acts you need if you are planning to
tow a trailer or drive off-high way.........................
Driving Guidelines .338
........................
Preparing to Drive .338
.......................
Starting the Engine .339
Check Starting System .................................
Message .340
..............
Automatic Transmission .341
Super Handling-All Wheel Drive
...........................................
Parking .350
Tire Pressure Monitoring System
......................................
(TPMS) .351
.............................
Braking System .356
...............
Anti-lock Brakes (ABS) .357
Vehicle Stability Assist (VSA)
........................................
System .359
................
Active Damper System .361
...........................
Towing a Trailer .363
..................
Trailer Stability Assist .375
Of f -Highway Driving
..................................
Guidelines .377
Driving
Driving
337
\f—\f—\fy
\f\fy
()-
\fy\fy
drive(SH-AWD®) system, the vehicle(SH-AWD®) System ....................348
2008 MDX

Each torque indicator is displayed
as a bar graph divided into 5
segments. The number of
segments represents the amount
of torque distributed to each
wheel.
monitor on the multi-inf ormation
display shows you the amount of
torque being sent to the wheels.
Each wheel: right f ront (RF), lef t
front(LF),rightrear(RR),andleft
rear (LR), has its own torque
indicator.
The super handling-all wheel drive
wheel-drive system that
automatically controls and transfers
varying amounts of engine torque to
all wheels independently, according
to the driving conditions.
enhance the vehicle’s driving
stability in all situations, it is still
your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety.
When there is only a slight change in
torque distribution while driving,
such as cruising on level roads at the
same speed, the torque distribution
monitor may stop displaying the
amount of torque. This is not a
system problem. The monitor will
show the amount if the system
senses any change in torque
distribution.
Monitor
348
TORQUE INDICATOR
TORQUE INDICATOR
\f—\f—\fy
\f\fy
()-
\fy\fy
) System®SuperHandling-AllWheelDrive(SH-AWD
(SH-AWD®) system is a f ull time all-
SH-AWD®T orque Distribution
WhiletheSH-AWD®system helps to
TheSH-AWD®torque distribution
2008 MDX

Your vehicle still has normal f ront-
wheel drive with vehicle stability
assist (VSA), but does not have
your vehicle checked by a dealer
as soon as possible.
instrument panel stays on, and the
message also appears on the multi-
inf ormation display, there is problem
driving, it indicates the dif f erential
temperature is too high. You will also
HIGH’’ message on the multi-
inf ormation display. If this happens,
pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out. If
the indicator does not go out, take
your vehicle to a dealer to have it checked.
Driving
349
\f—\f—\fy
\f\f
y
()-
\fy\fy
SuperHandling-AllWheelDrive(SH-AWD®) System
®If the SH-AWD
indicator blinks while
seean‘‘SH-AWD®DIFF TEMP.
IftheSH-AWD®indicator on the
‘‘CHECKSH-AWD®SYSTEM’’
withtheSH-AWD®system.
theadvantagesofSH-AWD®. Have
2008 MDX

on loose or
uneven surf aces, such as gravel or
snow, than a vehicle without anti-
lock. It only helps with steering
control during braking.
such as trying to take a
corner too f ast or making a sudden
lane change. Always drive at a safe
speed f or the road and weather
conditions.
Always steer moderately
when you are braking hard. Severe
or sharp steering wheel movement
can still cause your vehicle to veer
into oncoming traffic or off the road.
If the ABS indicator and the brake
system indicator come on together,
and the parking brake is f ully
released, the EBD system may also
be shut down.
Test your brakes as instructed on
page . If the brakes f eel normal,
drive slowly and have your vehicle
repaired by your dealer as soon as
possible. Avoid sudden hard braking
which could cause the rear wheels to
lock up and possibly lead to a loss of
control.
The VSA indicator will come on
alongwiththeABSindicator.
If this indicator comes on, the anti-
lock f unction of the braking system
has shut down. The brakes still work
like a conventional system, but
without anti-lock. You should have
your dealer inspect your vehicle as
soon as possible.
You will also see a ‘‘CHECK ABS
SYSTEM’’ message on the multi-
inf ormation display (see page ).
If the indicator comes on while
driving, test the brakes as instructed
on page .
81
438 438
Anti-lock Brakes (ABS)
A vehicle with A BS may require a
longer distance to stop
A BS does not reduce the time or
distance it takes to stop the
vehicle.
Important Saf ety Reminders
A BS will not prevent a skid that
results f rom changing direction
abruptly,
A BS cannot prevent a loss of
stability.
ABS Indicator
358
\f—\f—\fy
\f
\fy
()-
\fy\fy
2008 MDX

The vehicle stability assist (VSA)
system helps to stabilize the vehicle
during cornering if the vehicle turns
more or less than desired. It also
assists you in maintaining traction
while accelerating on loose or
slippery road surf aces. It does this
by regulating the engine’s output and
by selectively applying the brakes.
When VSA activates, you may notice
that the engine does not respond to
the accelerator in the same way it
does at other times. There may also
be some noise f rom the VSA
hydraulic system. You will also see
the VSA activation indicator blink.
The VSA system cannot enhance the
vehicle’s driving stability in all
situations and does not control your
vehicle’s entire braking system. It is
still your responsibility to drive and
corner at reasonable speeds and to
leave a sufficient margin of safety.When VSA activates, you will see the
VSA activation indicator blink.
If this indicator comes on while
driving, pull to the side of the road
when it is saf e, and turn of f the
engine. Reset the system by
restarting the engine. If the VSA
system indicator stays on or comes
back on while driving, have the VSA
system inspected by your dealer.
If the indicator does not come on
when the ignition switch is turned to
the ON (II) position, there may be a
problem with the VSA system. Have
your dealer inspect your vehicle as
soon as possible.
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display if there is a
problem with the VSA system.
If the low tire pressure/TPMS
indicator comes on, or the multi-
inf ormation display shows a
‘‘CHECK TPMS SYSTEM’’ message,
the VSA system automatically turns
on even when the VSA system is
turned of f by pressing the VSA OFF
switch (see page ). If this
happens, you cannot turn the VSA
system of f by pressing the VSA OFF
switch again.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
360
VSA A ctivation Indicator
Vehicle Stability Assist
(VSA ) System Indicator
Vehicle Stability Assist (VSA) System
Driving
359
\f—\f—\fy
\f
\fy
()-
\fy\fy
2008 MDX

This switch is under the driver’s side
vent. To turn the VSA system on and
of f , press and hold it until you hear a
beep.
When VSA is off, the VSA activation
indicator comes on as a reminder.
With the VSA of f , the trailer stability
assist f unction is also turned of f (see
page ).VSA is turned on every time you
start the engine, even if you turned it
off the last time you drove the
vehicle.
In certain unusual conditions when
your vehicle gets stuck in shallow
mud or f resh snow, it may be easier
to free it with the VSA temporarily
switched of f . When the VSA system
is of f , the traction control system is
alsooff.Youshouldonlyattemptto
f ree your vehicle with the VSA of f if
you are not able to f ree it when the
VSA is on.
Immediately af ter f reeing your
vehicle, be sure to switch the VSA on
again. We do not recommend driving
your vehicle with the VSA and
traction control systems switched off.
Driving with varying tire or wheel
sizes may cause the VSA to
malf unction. When replacing tires,
make sure they are of the same size
and type as your original tires (see
page ).
If you install winter tires, make sure
they are the same size as those that
were originally supplied with your
vehicle. Exercise the same caution
during winter driving as you would if
your vehicle was not equipped with
VSA.
419
375
Vehicle Stability Assist (VSA) System
VSA Of f Switch VSA and Tire Sizes
360
\f—\f—\fy
\f

\fy
()-
\fy\fy
2008 MDX

If you see this warning indicator and
message, have your vehicle checked
at your dealer as soon as possible.
In this case, your vehicle still has the
normal damper f unction, but it will
not have the active damper function.Your vehicle has been designed
primarily to carry passengers and
their cargo. You can also use it to
tow a trailer if you caref ully observe
the load limits, use the proper
equipment, and f ollow the guidelines
in this section.
Be sure to read the
sectiononpage
if you plan to tow of f paved
surf aces.
Avoid towing a trailer during your
vehicle’s f irst 600 miles (1,000 km)
(see page ).
Your vehicle is equipped with a
trailer stability assist to help stabilize
the vehicle/trailer combination by
reducing the vehicle speed. For
more information, see page . 322
377
375
A ctive Damper System, Towing a Trailer
Towing a Trailer
Off-Highway
Driving Guidelines
Break-In Period
Driving
363
Exceeding any load limit or
improperly loading your vehicle
and trailer can cause a crash in
which you can be seriously hurt
or killed.
Check the loading of your
vehicle and trailer carefully
beforestartingtodrive.
\f—\f—\fy
\f

y
()-
\fy\fy
2008 MDX

CONT INUED
A 4-pin gray connector is available as
an option at your dealer. This
connector has all of the circuits
required to install most electric
trailer brake controllers. A jumper
harness to adapt your electric trailer
brake controller to the vehicle is
included with the optional Acura
Genuine trailer hitch kit. To obtain a
connector and a trailer hitch kit, see
your dealer.
Have a qualif ied mechanic install
your trailer brake controller
f ollowing the trailer brake controller
manuf acturer’s instructions. Failure
to properly install the trailer brake
controller may increase the distance
it takes f or you to stop your vehicle
when towing a trailer.
Acura requires that any trailer with a
total trailer weight of 1,000 lbs (455
kg) or more have its own brakes.
There are two common types of
trailer brakes: surge and electric.
Surge brakes are common f or boat
trailers, since the brakes will get wet.
If you choose electric brakes, be
sure they are electronically actuated.
Do not attempt to tap into your
vehicle’s hydraulic system. No
matter how successf ul it may seem,
any attempt to attach trailer brakes
to your vehicle’s hydraulic system
will lower braking ef f ectiveness and
create a potential hazard.
Seeyourtrailermanufacturerfor
more inf ormation on installing
electric brakes.
We strongly recommend that you
have your dealer install a class 3
hitch. Using non-Acura equipment
may result in serious damage to your
vehicle.
Read the trailer manufacturer’s
instructions, and select the
appropriate draw bar f or the height
of the trailer you will be towing.
A weight distributing hitch is not
recommended f or use with your
vehicle, as an improperly adjusted
weight distributing hitch may reduce
handling, stability, and braking
perf ormance.
Towing a Trailer
Trailer Brakes
Hitch
Weight Distributing Hitch
Driving
369
\f—\f—\fy
\f

y
()-
\fy\fy
2008 MDX
