Familiarisation INSTRUMENTS AND CONTROLS

1. Steering wheel adjustment control.

2. Lights and direction indicators controls.

3. Instrument panel.

4. Driver's air bag.
Horn.

5. Cruise control/speed limiter switch.

6. Gear lever.

7. Handbrake.

8. Bonnet release.

9. Exterior mirror controls.

10. Fuse box.

11. Manual headlamp height adjustment.

12. Side adjustable and closing vent.

13. Front side window demisting vent.

14. Windscreen demisting vent.

15. Steering lock and ignition.

16. Wipers/wash-wipe/trip computer controls.

17. Central adjustable and closing vents.

18. Passenger air bag.

19. MENU button.

20. Glove box.

21. Lighter.

22. Ashtray.

23. Heating/air conditioning controls.

24. Audio equipment.

25. Electric window controls.

26. 12 V socket.

13
Familiarisation
FAMILIARISATION
Ring B: rear wiper

 39 Intermittent wipe.
Wash-wipe.
Park.
SEE CLEARLY
Lighting
Ring
Fog lamps

 37 Direction indicators
"Motorway" function
Press up or down once, without passing the
point of resistance; the corresponding direction
indicators will fl ash three times.

 37 Wipers
Ring A: windscreen wipers

 39
Lights off.
Side lights.
Dipped/main beam headlamps.
Rear fog lamp.
or
Front and rear fog lamps. Park.
Intermittent.
Slow continuous.
Rapid continuous.
Single wipe.
Wash-wipe.

19
1
READY TO SET OFF
Instruments and controls
INSTRUMENT PANELS

1. Distance recorder in kilometres/miles.

2. Display.

3. Fuel gauge.

4. Coolant temperature.

5. Rev counter.
Instrument panel with level 1 display Instrument panel with level 2 display
Instrument panel display level 1
- Time,
- Kilometres/Miles travelled,
- Trip computer/range, consumption,
average speed,
- Headlamp height,
- Programmable overspeed warning,
- Arming or disarming of the passenger air bag.
Instrument panel display level 2
- Time,
- Date,
- Radio,
- Kilometres/Miles travelled,
- Exterior temperature,
- Modes and gears engaged on the piloted manual gearbox,
- Trip computer/range, consumption, average speed
- Headlamp height,
- Programmable overspeed warning,
- Selection of the display language,
- Arming or disarming of the passenger air bag,
- Activation or deactivation of the automatic locking of the doors while driving.

20
Instruments and controls
Instrument panel with level 3 display
Instrument panel display level 3
- Cruise control/Speed limiter,
- Time,
- Date,
- Radio,
- Kilometres/Miles travelled,
- Exterior temperature,
- Modes and gears engaged on the piloted manual gearbox, - Trip computer/range, consumption,
average speed,
- Headlamp height,
- Programmable overspeed warning,
- Selection of the display language,
- Arming or disarming of the passenger air bag,
- Activation or deactivation of the automatic locking of the doors while
driving.

24
Instruments and controls

Warning light
is indicates Solution - action
Water in diesel filter on, accompanied by
a message on the
display. that there is water in the
diesel fuel filter.
Have the filter bled by a PEUGEOT dealer.
Refer to the "Checks" section of chapter 7.
Low fuel level on with the gauge
needle in zone E. that the fuel reserve is
being used. Fill up with fuel without delay. The evaluation
of the fuel reserve is a parameter which is
sensitive to the style of driving, the profile of
the road, the time elapsed and the distance
travelled since the warning light first came on.
Diesel pre-heating on. that the weather
conditions impose pre-
heating. Wait for the warning light to switch off before
operating the starter.
Side lights on. manual selection. Turn the ring on the lights stalk to the first
position.
Dipped headlamps on. manual selection.
Turn the ring on the lights stalk to the second
position.
Main beam headlamps pulling of the stalk
towards you. Pull the lights stalk to return to dipped
headlamps.

25
1
READY TO SET OFF
Instruments and controls

Warning light
is indicates Solution - action
Direction indicators flashing with buzzer. a change of direction
using the lights stalk, to
the left of the steering
wheel. To the Right: press the stalk upwards.
To the Left: press the stalk downwards.
Front fog lamps on. that the button on the
fascia panel has been
pressed. Manual selection.
The fog lamps only operate if the side lights or
dipped headlamps are on.
Rear fog lamps on. that the button on the
fascia panel has been
pressed. Manual selection. The fog lamps only operate if
the dipped headlamps are on. When visibility is
normal, please switch the fog lamps off on penalty
of being booked. "This light is a dazzling red."
Faulty bulb on, accompanied by
a message on the
display. that one or more bulbs
have blown. Have the bulb changed.
Refer to the "Changing a bulb" section of
chapter 7 or consult a PEUGEOT dealer.
Cruise control on. that the cruise control has
been selected. Manual selection. Refer to the "Gearbox and
steering wheel" section of chapter 1.
Speed limiter on. that the speed limiter has
been selected. Manual selection. Refer to the "Gearbox and
steering wheel" section of chapter 1.

26
Instruments and controls

Warning light
is indicates Solution - action
Rear parking
assistance on. failure of the system. The audible assistance is no longer active.
Have the system checked by a PEUGEOT
dealer without delay.
Piloted manual gearbox on, accompanied
by the flashing of
"AUTO". failure of the gearbox.
Have the system checked by a PEUGEOT
dealer without delay.

Display displays indicates Solution - action
Exterior temperature the temperature which
flashes accompanied
by a message on the
display. weather conditions
which could result in the
presence of ice on the
road.
Be especially vigilant and do not brake
sharply. Refer to the "Driving safety" section of
chapter 5.
Date
11:00:00 a setting:
of the Date.
of the Time. a configuration via the
MENU menu.
Refer to the "Menu" section of chapter 3.
Headlamp beam height a headlamp height
setting. a position from 0 to 3
depending on the load
carried. Adjust using the control on the fascia panel.
Refer to the "Steering wheel controls" section
of chapter 1.
