2008.5 Citroen C5 key
[x] Cancel search: keyPage 22 of 306
40
2
M U L T I F U N C T I O N D I S P L A Y S Display
This menu allows you to set the
brightness of the screen, the screen
colour scheme and the colour of the
map (day/night or auto mode). Units
This menu allows you to select the units: temperature (°C or °F) and distance (km or miles).
System
This menu allows you to restore the
f a c t o r y c o n fi g u r a t i o n , d i s p l a y t h e
software version and activate the
s c r o l l i n g t e x t .
For safety reasons, it is imperative
t h a t c o n fi g u r a t i o n o f t h e m u l t i f u n c -
tion screen by the driver is carried
out when stationary.
Date & time
This menu allows you to set the date
and time, the format of the date and
the format of the time.
To set the date and time:
Press the "SETUP" control.
Turn the dial to select "DATE
&
TIME" .
P r e s s t h e d i a l t o c o n fi r m .
Turn the dial to select "SET
DATE
&
TIME" .
P r e s s t h e d i a l t o c o n fi r m .
T u r n t h e d i a l t o s e l e c t a fi e l d :
- C for the day,
- D for the month,
- E for the year,
- F for the time.
P r e s s t h e d i a l t o c o n fi r m .
Turn the dial or use the alphanu-
meric keypad to select the digits
which form the date and time.
P r e s s t h e d i a l t o c o n fi r m e a c h
fi e l d .
Turn the dial to select "DATE
FORMAT" .
Choose the format required and
p r e s s t h e d i a l t o c o n fi r m .
Turn the dial to select "TIME
FORMAT" .
Choose the format required and
p r e s s t h e d i a l t o c o n fi r m .
Refer to the MyWay User Guide.
Page 44 of 306
61
3
C O M F O R T
MIRRORS
Exterior mirrors
E a c h fi t t e d w i t h a n a d j u s t a b l e m i r r o r
glasses providing the lateral rear-
ward vision necessary for overtaking
or parking. They can also be folded.
Adjustment
With the ignition on:
move control A to the right or to
the left to select the correspond-
ing mirror,
move control B in all four direc-
tions to adjust,
return control A to the central po-
sition. T h e d e - i c i n g / d e m i s t i n g o f t h e e x t e -
rior mirrors is associated with that
of the rear screen.
Folding
from outside; lock the vehicle
using the remote control or the
key.
from inside; with the ignition on,
pull control A rearwards.
If the mirrors are folded using con-
trol A , they will not unfold when the
vehicle is unlocked. Control A must
be pulled again.
Unfolding
from outside; unlock the vehicle
using the remote control or the
key.
from inside; with the ignition on,
pull control A rearwards.
If the position is changed manually, a
long press on control A re-engages
the mirror.
T h e f o l d i n g a n d u n f o l d i n g o f t h e e x t e -
rior mirrors using the remote control
can be deactivated by a CITROËN
dealer. The objects observed are, in reality,
closer than they appear.
Take this into account in order to
correctly judge the distance of ve-
hicles approaching from behind.
Automatic tilting in reverse gear
System which provides a view of the
ground during parking manoeuvres
in reverse gear.
Programming
With the engine running, engage
reverse gear.
Select and adjust the left-hand
and right-hand mirrors in suc-
cession.
The adjustment is stored immediately.
Using
With the engine running, engage
reverse gear.
Move control A to the right or to
the left to select the correspond-
ing mirror.
The glass of the mirror selected tilts
downwards, in accordance with its
programming.
Stopping
E x i t r e v e r s e g e a r a n d w a i t t w e n t y
seconds.
or
Return control A to the central
position.
The mirror glass returns to its initial
position.
The mirror glass also returns to its
initial position if:
-
t h e s p e e d e x c e e d s 6 m p h ( 1 0 k m / h ) ,
- the engine is switched off.
Page 47 of 306
64
4
A C C E S S
REMOTE CONTROL KEY
System which permits central un-
locking or locking of the vehicle us-
ing the lock or from a distance. It
is also used to locate and start the
vehicle and provide guide-me-home
lighting, as well as providing protec-
tion against theft.
Unlocking the vehicle Complete unlocking using the
remote control
Unfolding the key
First press button A to unfold the
key.
Press the open padlock
to unlock the vehicle.
Complete unlocking using the
key
Turn the key to the left in the
driver’s door lock to unlock the
vehicle.
U n l o c k i n g i s c o n fi r m e d b y r a p i d
fl a s h i n g o f t h e d i r e c t i o n i n d i c a t o r s
f o r a p p r o x i m a t e l y t w o s e c o n d s a n d
lighting of the courtesy lamp (if the
function is activated).
A c c o r d i n g t o v e r s i o n , t h e e x t e r i o r
mirrors unfold at the same time.
Selective unlocking using the
remote control
Press the open padlock
once to unlock the driver’s
door only.
Press the open padlock again to
unlock the other doors and the
boot. A c c o r d i n g t o v e r s i o n , t h e e x t e r i o r
mirrors unfold at the same time as
t h e fi r s t u n l o c k i n g a c t i o n .
The complete or selective unlocking
parameter is set via the instrument
p a n e l s c r e e n c o n fi g u r a t i o n m e n u
(see "Instruments and controls" sec-
tion).
Complete unlocking is activated by
default.
Selective unlocking is not possible
using the key.
E a c h u n l o c k i n g i s c o n fi r m e d b y
r a p i d fl a s h i n g o f t h e d i r e c t i o n i n d i c a -
t o r s f o r a p p r o x i m a t e l y t w o s e c o n d s
and by switching on of the courtesy
lamp.
Electric boot opening
Press button B to open
the boot.
Page 48 of 306
65
4
A C C E S S
Normal locking using the key
Turn the key to the right in the
driver’s door lock to lock the ve-
hicle completely.
L o c k i n g i s c o n fi r m e d b y fi x e d l i g h t -
ing of the direction indicators for
a p p r o x i m a t e l y t w o s e c o n d s a n d b y
switching off of the courtesy lamp.
A c c o r d i n g t o v e r s i o n , t h e e x t e r i o r
mirrors fold at the same time. If one of the doors, the rear screen
or the boot is still open, the central
locking does not take place.
When the vehicle is locked, if it is
unlocked inadvertently, it will relock
automatically after thirty seconds
unless a door is opened.
When stationary with the engine
o f f , l o c k i n g i s c o n fi r m e d b y fl a s h i n g
of the interior locking control indi-
cator lamp.
The folding and unfolding of the
e x t e r i o r m i r r o r s u s i n g t h e r e m o t e
control can be deactivated by a
CITROËN dealer.
Deadlocking using the
remote control
Press the closed pad-
lock to lock the vehicle
completely or press the
closed padlock for more
than two seconds to
close the windows and
sunroof automatically in
addition to locking.
Press the closed padlock again
w i t h i n fi v e s e c o n d s t o d e a d l o c k
the vehicle.
Locking the vehicle
Normal locking using the remote
control
Press the closed pad-
lock to lock the vehicle
completely.
Press the closed padlock for
more than two seconds to close
the windows and sunroof auto-
matically in addition to locking. Deadlocking using the key
Turn the key to the right in the
driver's door lock to lock the ve-
hicle completely and hold it in
this position for more than two
seconds to close the windows
automatically in addition to locking.
Turn the key to the right again
w i t h i n fi v e s e c o n d s t o d e a d l o c k
the vehicle.
D e a d l o c k i n g i s c o n fi r m e d b y fi x e d
lighting of the direction indicators for
a p p r o x i m a t e l y t w o s e c o n d s .
A c c o r d i n g t o v e r s i o n , t h e e x t e r i o r
mirrors fold at the same time.
D e a d l o c k i n g r e n d e r s t h e e x t e r i o r a n d
interior door controls inoperative.
It also deactivates the manual central
control button.
When stationary with the engine
o f f , l o c k i n g i s c o n fi r m e d b y fl a s h i n g
of the indicator lamp on the interior
locking control.
If one of the doors or the boot is open
or has not been closed correctly, the
central locking will not work.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.
Page 49 of 306
66
4
A C C E S S
First press button A to fold the
key.
Locating your vehicle
Press the closed padlock to locate
your locked vehicle in a car park.
This is indicated by switching on
o f t h e i n t e r i o r l i g h t i n g a n d fl a s h i n g
of the direction indicators for a few
seconds.
The vehicle remains locked. Guide-me-home lighting Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code
must be recognised in order for
starting to be possible.
This electronic engine immobiliser
locks the engine management sys-
tem a few minutes after the ignition
is switched off and prevents starting
of the engine by anyone who does
not have the key. In the event of a mal-
function, you are in-
formed by lighting of
this warning lamp, an
audible signal and a message on
the multifunction screen.
In this case, your vehicle does not
start; contact a CITROËN dealer as
soon as possible.
Folding the key
A press on button B oper-
ates the guide-me-home
lighting (lighting of the
sidelamps, dipped beams
and number plate lamps).
A second press before the end of
the timing cancels the guide-me-
home lighting.
The timed duration can be set via the
"Lighting" menu on the "Main Menu"
of the instrument panel screen.
Page 50 of 306
67
4
A C C E S S
STOPPING
D o n o t fl i c k t h e a c c e l e r a t o r a t t h e
moment of switching off the ignition.
This could cause serious damage to
the turbocharger(s).
IGNITION SWITCH
1. "S": Steering lock
To unlock the steering, gently move
the steering wheel while turning the
key, without forcing it.
2. "M": Drive position
Depending on the version of your
vehicle, the orange and red warn-
ing lamps should also come on for
a short time.
3. "D": Starter
Release the key as soon the engine
has started.
I f t h e fi r s t a t t e m p t f a i l s , s w i t c h o f f t h e
ignition. Wait ten seconds then oper-
ate the starter again. Steering lock
1. "
S": After removing the key, turn the
steering wheel to lock the steering. The
key can only be removed in position S .
2. "M": Ignition switched on, the
steering is unlocked (by turning the
key to position M , move the steering
wheel gently if necessary).
3. "D": Starter position.
Never turn the key to this position
when the engine is running.
Key in ignition buzzer
If you forget to remove the key from
the ignition, a buzzer sounds when
the driver's door is opened.
Do not run the engine in an en-
closed space or where there is in-
s u f fi c i e n t v e n t i l a t i o n .
It is essential always to drive with
the engine running in order to retain
braking and steering assistance.
Never remove the ignition key
before the vehicle has come to a
complete stop.
Avoid attaching a heavy object to
the key which would weigh down
on its shaft in the switch and could
cause a malfunction. Vehicles equipped with a
turbocharger
Never stop the engine without having
allowed it to run for a few seconds at
idle, this being the time required for
the turbocharger to return to a normal
speed.
Page 51 of 306
68
4
A C C E S S
Malfunction
Following disconnection of the ve-
hicle battery, replacement of the re-
mote control battery or in the event
of a remote control malfunction, you
can no longer unlock, lock or locate
your vehicle.
First of all, use the key in the lock
to unlock or lock your vehicle.
Then, reinitialise the remote con-
trol.
If the problem persists, contact a
CITROËN dealer as soon as pos-
sible.
Reinitialisation
Switch off the ignition.
Turn the key to position 2
(
Drive
) .
Press the closed padlock imme-
diately for a few seconds, until
the operation requested is trig-
gered.
Switch off the ignition and re-
move the key from the ignition
switch.
The remote control is fully opera-
tional again. Battery ref.: CR0523/3 volts.
This replacement battery is avail-
able from CITROËN dealers.
I f t h e b a t t e r y i s fl a t ,
you are informed by
lighting of this warn-
ing lamp, an audible
signal and a message on the multi-
function screen.
Unclip the casing using a coin at
the notch.
S l i d e t h e fl a t b a t t e r y o u t o f i t s l o -
cation.
Slide the new battery into its lo-
cation observing the original di-
rection.
Clip the casing.
Reinitialise the remote control.
Changing the battery
Page 52 of 306
69
4
A C C E S S
Lost keys
Visit a CITROËN dealer with the vehi-
cle’s V5 registration document and your
p e r s o n a l i d e n t i fi c a t i o n d o c u m e n t s .
The CITROËN dealer will be able to re-
trieve the key code and the transponder
code required to order a replacement
key.
Remote control
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
cle, without you being aware of it.
Do not repeatedly press the buttons
of your remote control out of range
and out of sight of your vehicle. You
run the risk of stopping it from work-
ing and the remote control would
have to be reinitialised.
The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
o f f , e x c e p t f o r r e i n i t i a l i s a t i o n .
Locking the vehicle
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
m o r e d i f fi c u l t i n a n e m e r g e n c y .
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
even for a short time. Anti-theft protection
D o n o t m a k e a n y m o d i fi c a t i o n s t o
the electronic engine immobiliser
system; this could cause malfunc-
tions.
When purchasing a second-
hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the
keys in your possession are the only
ones which can start the vehicle.
Do not throw the remote
control batteries away, they
contain metals which are
harmful to the environment.
Take them to an approved collection
point.
