59
3
C O M F O R T
Storing driving positions
System which takes into account the
settings of the driver's seat, exterior
mirrors and air conditioning. It ena-
bles you to store up to two positions
using the buttons on the side of the
driver's seat. Storing a position
Using buttons M/1/2
Switch on the ignition.
Adjust your seat and your exte-
rior mirrors.
Press button M , then press but-
ton 1 or 2 within four seconds.
An audible signal is heard indi- cating that the storing has been
taken into account.
Storing a new position cancels the
previous position.
Recalling a stored position
Ignition on or engine running
B r i e fl y p r e s s b u t t o n 1 or 2 to re-
call the corresponding position.
An audible signal is heard indicating
the end of the adjustment.
When the ignition is on, after a few
consecutive position recalls, the
function will be deactivated until the
engine is started, to prevent dis-
charging of the battery. For your safety, avoid storing a
driving position while driving.
REAR HEAD RESTRAINTS
The rear head restraints can be re-
moved and have two positions;
- high, position for use,
- low, storage position.
To raise a head restraint, pull it up-
wards.
To lower it, press the lug then the
head restraint.
To remove it, place it in the high po-
sition, push the lug and pull it up-
wards.
T o r e fi t i t , e n g a g e t h e h e a d r e s t r a i n t
rods in the holes taking care to re-
main in the centreline of the seat
back.
Never drive with the head restraints
removed, they must be in place
and correctly adjusted.
Page 42 of 306
59
3
C O M F O R T
Storing driving positions
System which takes into account the
settings of the driver's seat, exterior
mirrors and air conditioning. It ena-
bles you to store up to two positions
using the buttons on the side of the
driver's seat. Storing a position
Using buttons M/1/2
Switch on the ignition.
Adjust your seat and your exte-
rior mirrors.
Press button M , then press but-
ton 1 or 2 within four seconds.
An audible signal is heard indi- cating that the storing has been
taken into account.
Storing a new position cancels the
previous position.
Recalling a stored position
Ignition on or engine running
B r i e fl y p r e s s b u t t o n 1 or 2 to re-
call the corresponding position.
An audible signal is heard indicating
the end of the adjustment.
When the ignition is on, after a few
consecutive position recalls, the
function will be deactivated until the
engine is started, to prevent dis-
charging of the battery. For your safety, avoid storing a
driving position while driving.
REAR HEAD RESTRAINTS
The rear head restraints can be re-
moved and have two positions;
- high, position for use,
- low, storage position.
To raise a head restraint, pull it up-
wards.
To lower it, press the lug then the
head restraint.
To remove it, place it in the high po-
sition, push the lug and pull it up-
wards.
T o r e fi t i t , e n g a g e t h e h e a d r e s t r a i n t
rods in the holes taking care to re-
main in the centreline of the seat
back.
Never drive with the head restraints
removed, they must be in place
and correctly adjusted.
Page 43 of 306
60
3
C O M F O R T
REAR SEATS
Bench seat, the left-hand (2/3) or
right-hand (1/3) section of which
can be folded to adapt the boot load
space.
Removing the seat cushion
Move the corresponding front
seat forwards if necessary.
Raise the front of the seat cush-
ion 1 .
Tilt the seat cushion 1 fully
against the front seat.
Remove the seat cushion 1 from
i t s fi x i n g s b y p u l l i n g u p w a r d s . Refitting the seat cushion
Position the seat cushion 1 verti-
c a l l y i n i t s fi x i n g s .
Fold down the seat cushion 1 .
Press on the seat cushion to se-
cure it.
Folding the seat
In order to fold a rear seat without
any risk of damage, always start
with the seat cushion, never with
the seat back:
move the corresponding front
seat forwards if necessary,
raise the front of the seat cushion 1 ,
tilt the seat cushion 1 fully against
the front seat,
check that the seat belt is posi-
tioned correctly on the side of
the seat back,
lower or remove the head re-
straints if necessary,
pull the control 3 forwards to re-
lease the seat back 2 ,
tilt the seat back 2 .
The seat cushion 1 can be removed
to increase the loading volume. Returning the seat back to its
original position
When returning the rear seat back to
its original position:
put the seat back 2 in the upright
position and secure it,
fold the seat cushion 1 ,
r e fi t t h e h e a d r e s t r a i n t s o r p u t
them back in place.
When returning the rear seat back
to its original position, take care not
to trap the seat belts and ensure
that their buckles are positioned cor-
rectly.
The red indicator on the control 3
should no longer be visible; if it is,
push the seat fully back.
Page 94 of 306
98
6
L A Y O U T
BOOT LAYOUT (SALOON)
1. Battery for vehicles with V6 HDi
engine.
2. Pull strap (spare wheel storage).
3. Boot lamp.
4. 6 CD changer. Luggage securing rings
Use the 4 securing rings on the
b o o t fl o o r t o s e c u r e y o u r l u g g a g e .
F o r s a f e t y r e a s o n s , i n c a s e o f t h e
n e e d f o r s h a r p b r a k i n g , y o u a r e
a d v i s e d t o p l a c e h e a v y o b j e c t s a s
f a r f o r w a r d i n t h e b o o t a s p o s s i b l e .
Page 95 of 306
99
6
L A Y O U T
BOOT LAYOUT (TOURER)
1. Hook
A l l o w s y o u t o h o o k s h o p p i n g b a g s .
2. Torch
T o r e c h a r g e , r e t u r n i t t o i t s s t o r - age position.
3.
Storage net or Battery compart-
ment (for vehicles with V6 2.7 HDi
engine).
T h i s p r o v i d e s a c c e s s t o t h e b a t t e r y .
1. Luggage-cover blind
(see details on following page)
2. Luggage securing rings
Use the 4 stowing rings provided o n t h e b o o t fl o o r t o s e c u r e y o u r
loads.
For safety reasons in the event o f s h a r p b r a k i n g , y o u a r e a d -
v i s e d t o p l a c e h e a v y o b j e c t s a s
f a r f o r w a r d s a s p o s s i b l e .
3. Hooks
T h e s e a l l o w a c a r g o n e t t o b e fi t t e d (see details on following page).
1. Boot lamp
2. 12 V accessories socket
(100 W maximum)
C i g a r - l i g h t e r t y p e 1 2 v o l t s s o c k e t . It is located on the rear right-hand
t r i m , a n d i s s u p p l i e d f r o m t h e i g n i -
tion position.
3. Loading assistance
You can change the height of the v e h i c l e i n o r d e r t o m a k e l o a d i n g
or unloading easier.
4. Hook
A l l o w s y o u t o h o o k s h o p p i n g b a g s .
5. Storage net or 6 CD changer
Page 96 of 306
1 0 0
6
L A Y O U T
LUGGAGE COVER (TOURER)
To roll up
Press the handle (PRESS) gently.
The luggage cover rolls up auto-
matically.
The moving part A c a n b e f o l d e d
a l o n g t h e r e a r b e n c h s e a t b a c k r e s t .
To remove
Compress the control 1 and lift
the luggage cover on the right
then on the left to remove it.
To install
Position the left-hand end of the lug-
gage cover roller in its location B
b e h i n d t h e r e a r b e n c h s e a t .
Compress the roller control 1
and put the roller in place in its
location C on the right.
Release the control to secure
the luggage cover.
Unroll it to its fastening on the
b o o t p i l l a r . High load retaining net
(Tourer)
H o o k e d o n t o t h e s p e c i a l u p p e r a n d
l o w e r fi x i n g s , t h i s p e r m i t s u s e o f t h e
entire loading volume up to the roof:
- b e h i n d t h e r e a r s e a t s ( r o w 2 ) ,
- b e h i n d t h e f r o n t s e a t s ( r o w 1 )
when the rear seats are folded.
W h e n p o s i t i o n i n g t h e n e t , c h e c k t h a t
t h e s t r a p l o o p s a r e v i s i b l e f r o m t h e
b o o t ; t h i s w i l l m a k e s l a c k e n i n g o r
tightening easier.
Page 99 of 306
103
C H I L D S A F E T Y
Passenger air bag OFF
CHILD SEATS RECOMMENDED BY CITROËN
CITROËN offers a complete range of recommended child seats which are
secured using a three point seat belt :
Group 0: from birth to 10 kg
Group 0+: from birth to 13 kg
G r o u p s 1 , 2 a n d 3 : f r o m 9 t o 3 6 k g
L1
"RÖMER
B a b y - S a f e P l u s "
Installed in the
rearwards-facing p o s i t i o n .
L2
"KIDDY Life" The use of
the restraining cushion is
c o m p u l s o r y f o r
the transportation o f y o u n g c h i l d r e n ( f r o m 9 t o 1 8 k g ) .
G r o u p s 2 a n d 3 : f r o m 1 5 t o 3 6 k g
L3
"RECARO Start''
L4
" K L I P P A N O p t i m a "
From the age
o f 6 y e a r s
( a p p r o x i m a t e l y 2 2 k g ) ,
t h e b o o s t e r
i s u s e d o n i t s o w n .
Page 101 of 306
105
7
C H I L D S A F E T Y
"ISOFIX" MOUNTINGS
Y o u r v e h i c l e h a s b e e n a p p r o v e d i n
accordance with the new ISOFIX
regulation
s .
The rear side seats and the front
p a s s e n g e r s e a t a r e fi t t e d w i t h r e g u -
l a t i o n I S O F I X m o u n t i n g s . In the front
These are three rings for the front
passenger seat:
- two rings
A , l o c a t e d b e t w e e n t h e
v e h i c l e s e a t b a c k a n d c u s h i o n ,
i n d i c a t e d b y a l a b e l ,
- a ring B , fi x e d a t t h e b o t t o m o f
t h e r e a r o f t h e s e a t b a c k , u s e d
to secure the upper strap of the
c h i l d s e a t . These are three rings for each rear
side seat:
- two lower rings
C , l o c a t e d b e -
t w e e n t h e v e h i c l e s e a t b a c k a n d
c u s h i o n , i n d i c a t e d b y a l a b e l ,
- an upper ring D , fi x e d t o t h e r e a r
s h e l f , c o n c e a l e d u n d e r a fl a p
w i t h t h e l o g o T O P T E T H E R b e -
h i n d t h e h e a d r e s t r a i n t .
Tourer
- two lower rings C , l o c a t e d b e -
t w e e n t h e v e h i c l e s e a t b a c k a n d
c u s h i o n , i n d i c a t e d b y a l a b e l ,
- an upper ring E , fi x e d t o t h e
r o o f o n t h e b o o t s i d e , c o n c e a l e d
u n d e r a fl a p w i t h t h e l o g o T O P
T E T H E R .
In the rear
Saloon
