2008.5 Citroen C4 PICASSO buttons

20
F A M I L I A R I S A T I O N
Driver's and front passenger's control panel
Automatic air conditioning
Rear passengers' control panel
V E N T I L A T I O N

1. Automatic comfort regulation.

2. Adjustment and display of driver's
temperature.

3. Adjustment of air blower speed.
Maintaining of ventilation with the engine switched off (REST).

4. Adjustment and display of air distri-
bution.

5. Air recirculation.

6. Mode of adjustment for rear pas-
sengers.
7. Panel and buttons display mode
(black panel).

8. De-icing/Demisting of rear screen
and rear view mirrors.

9. Rapid de-icing/demisting of wind-
screen and windows.

10. Air conditioning.

11. Adjustment and display of front pas-
senger's temperature.

 49, 54
12. Adjustment of air blower speed.

 52

13. Temperature adjustment (no warm
air distribution).

14. Adjustment of air blower speed.

 53

22
F A M I L I A R I S A T I O N
Seat belts not fastened/
unfastened warning lamp This warning lamp informs you
if the driver’s or front passen-
ger’s seat belt is not fastened
(depending on model), and if
the front passenger’s (depend-
ing on model) or the second-
row passengers’ seat belts are
unfastened. The lit up positions
represent those whose seat belts are
not fastened/unfastened.
You can use electrical central locking or
unlocking by pressing on button A .
If one of the doors is open or is not
closed properly, central locking will not
work. Tyre deflation detection
This function warns you if a tyre is de-
fl ated or punctured.
This system does not absolve the driver
of the need to regularly check the tyre
pressures.
The service warning lamp
lights up, and a vehicle out-
line is displayed, accompa-
nied by a message and a
sound signal.
Defl ation warning
The STOP warning lamp lights
up, and a vehicle outline is
displayed, accompanied by a
message and a sound signal.
Puncture

 30

 115
Anti-intrusion security
Once the function has been activated,
when starting the engine, the system
automatically locks the doors once you
reach approximately 10 km/h (approxi-
mately 6 mph).
This function can be deactivated
by pressing button
A for more than
two seconds.
 79
M O N I T O R I N G
Locking from inside
Instrument panel
with multifunction screen A

 24
with multifunction screen C
 25
with NaviDrive multifunction screen
 26

1. Instrument panel.

2. Multifunction screen.

3. Control buttons.

4. Warning lamps display zone.

24
I
I N S T R U M E N T S a n d C O N T R O L S
MONO - TONE INSTRUMENT PANEL
MULTIFUNCTION SCREEN A
The instrument panel groups all the driving and comfort information at the centre of the dashboard.
Central display

1. Rev counter

2. Electronic gearbox or automatic
gearbox selector position and
gear

3. Electronic gearbox or automatic
gearbox "Foot on brake" warning
lamp

4. Speed indicator

5. Cruise control or speed limiter
reference

6. Fuel gauge
7. Trip mileage recorder

8. Multifunction screen A

9. Total mileage recorder
In this zone, the following infor- mation appears in succession
when the ignition is switched on:
- maintenance indicator,
- engine oil level indicator,
- total mileage recorder. Control buttons

A. Lighting rheostat (available day
and night)

B. Trip mileage recorder reset

C. Personalisation of the instru-
ment panel (display of desired
information)

D. CHECK (list of alerts)

25
I
I N S T R U M E N T S a n d C O N T R O L S
BI - TONE INSTRUMENT PANEL
MULTIFUNCTION SCREEN C
The instrument panel groups all the driving and comfort information at the centre of the dashboard.
Central display

1. Rev counter

2. Electronic gearbox or automatic
gearbox selector position and
gear

3. Electronic gearbox or automatic
gearbox "Foot on brake" warning
lamp

4. Speed indicator

5. Cruise control or speed limiter
reference

6. Fuel gauge
7. Trip mileage recorder

8. Multifunction screen C

9. Total mileage recorder
In this zone, the following infor- mation appears in succession
when the ignition is switched on:
- maintenance indicator,
- engine oil level indicator,
- total mileage recorder. Control buttons

A. Lighting rheostat (available day
and night)

B. Trip mileage recorder reset

C. Personalisation of the instru-
ment panel (display of desired
information)

D. COLOUR (choice of background
colour ranging from white to
blue)

26
I
I N S T R U M E N T S a n d C O N T R O L S
NAVIDRIVE INSTRUMENT PANEL
NAVIDRIVE MULTIFUNCTION SCREEN
The instrument panel groups all the driving and comfort information at the centre of the dashboard.
Central display

1. Cruise control or speed limiter
reference

2. Speed indicator

3. NaviDrive multifunction screen
(see "NaviDrive instructions")

4. Rev counter

5. Electronic gearbox or automatic
gearbox "Foot on brake" warning
lamp

6. Fuel gauge

7. Electronic gearbox or automatic
gearbox selector position and
gear
8. Trip mileage recorder

9. Total mileage recorder
In this zone, the following infor- mation appears in succession
when the ignition is switched on:
- maintenance indicator,
- engine oil level indicator,
- total mileage recorder. Control buttons

A. Personalisation of the instru-
ment panel (display of desired
information)

B. COLOUR (choice of background
colour ranging from white to
blue)

C. Lighting rheostat (available day
and night)

D. Trip mileage recorder reset

51
III
C O M F O R T

Closing of the air inlet

 Press on button 5 to
close off the entry of air
from outside.
Whilst retaining the other adjust-
ments, this position enables the
driver at any time to exclude any dis-
agreeable odours or fumes coming
from outside the vehicle. It should
be cancelled as soon as possible to
permit renewal of cabin air and to
prevent misting.

Entry of air (manual mode)

 Press on button 5 to activate en-
try of air from the outside. The
warning lamp goes out.

 Press once on button 5 to return
to the initial status (entry of air in
automatic mode).
The air recirculation can also be ac-
cessed by means of a press on the
control, located low down to one side
of the steering wheel (see "§ Fixed
centred controls steering wheel"). 6. Adjustment mode for the
rear passengers
This button decides whether
or not the rear passengers
may use their adjustment
controls.
There are three possible statuses
for this button:

Locking of the rear
passenger controls

Authorisation of
the rear passenger
controls

Closing of the air
fl ow for the rear
passengers
The supply of air is cut off.
With additional air conditioning, in
cold weather you are advised to
close the supply of air to the rear
passengers (no hot air distribution
possible via these air vents).
The rear passengers can use their
adjustment controls at their con-
venience.
The driver imposes his adjustment
on the rear passengers. In this case,
the rear passenger controls are de-
activated. 7. Panel display mode:
black panel function
This function turns the dis-
plays and panel backlighting
on or off.
- Function activated, a press on any button will light up the screen
temporarily.
- press on button 7 deactivates
the function, lighting buttons and
screen is again permanent.
This function optimises notably the
visual comfort for driving at night.
8. Deicing/Demisting of the rear screen
This can only operate when the en-
gine is running.

 Press on button 8 to activate/de-
activate the electric deicing of
the rear screen and, according to
version, of the exterior rear view
mirrors. The warning lamp lights
up and the symbol appears on
the display.
It switches off automatically
to prevent excessive con-
sumption of power.

52
C O M F O R T
9. Rapid Deicing/Demisting of the front and rear windows
- Press on button 9 . The warning
lamp lights up.
This function gives a rapid
deicing/demisting of the ve-
hicle simultaneously with:
- front deicing at optimum temper- ature,
- optimum air fl ow,
- recirculation prohibition,
- deicing of the rear view mirrors and heated rear screen,
- air conditioning, if necessary.
Press again on button 9 or on AUTO
to stop the function. Deicing of the
rear view mirrors and heated rear
screen remains activated.
10. Air conditioning

 Press on button 10 to activate
the air conditioning.
The A/C warning lamp lights up.
B. PASSENGER CONTROL PANELS
11. Front passenger
The front passenger can adjust his/
her temperature control independ-
ently at any time by pressing buttons

+ and - .
The front passenger controls
the adjustment of his/her
own temperature.
The temperature for the pas-
senger is indexed on that for
the driver. 12. Rear passengers
(right/left)
By default, in AUTO
position, the adjust-
ment of the air fl ow is
aligned on the front
ventilation.

 Rotate the button
to decrease or in-
crease the air fl ow.
You can adjust the air fl ow only if
the driver enables you to (see but-
ton 6 of the driver’s control panel).

51
III
C O M F O R T

Closing of the air inlet

 Press on button 5 to
close off the entry of air
from outside.
Whilst retaining the other adjust-
ments, this position enables the
driver at any time to exclude any dis-
agreeable odours or fumes coming
from outside the vehicle. It should
be cancelled as soon as possible to
permit renewal of cabin air and to
prevent misting.

Entry of air (manual mode)

 Press on button 5 to activate en-
try of air from the outside. The
warning lamp goes out.

 Press once on button 5 to return
to the initial status (entry of air in
automatic mode).
The air recirculation can also be ac-
cessed by means of a press on the
control, located low down to one side
of the steering wheel (see "§ Fixed
centred controls steering wheel"). 6. Adjustment mode for the
rear passengers
This button decides whether
or not the rear passengers
may use their adjustment
controls.
There are three possible statuses
for this button:

Locking of the rear
passenger controls

Authorisation of
the rear passenger
controls

Closing of the air
fl ow for the rear
passengers
The supply of air is cut off.
With additional air conditioning, in
cold weather you are advised to
close the supply of air to the rear
passengers (no hot air distribution
possible via these air vents).
The rear passengers can use their
adjustment controls at their con-
venience.
The driver imposes his adjustment
on the rear passengers. In this case,
the rear passenger controls are de-
activated. 7. Panel display mode:
black panel function
This function turns the dis-
plays and panel backlighting
on or off.
- Function activated, a press on any button will light up the screen
temporarily.
- press on button 7 deactivates
the function, lighting buttons and
screen is again permanent.
This function optimises notably the
visual comfort for driving at night.
8. Deicing/Demisting of the rear screen
This can only operate when the en-
gine is running.

 Press on button 8 to activate/de-
activate the electric deicing of
the rear screen and, according to
version, of the exterior rear view
mirrors. The warning lamp lights
up and the symbol appears on
the display.
It switches off automatically
to prevent excessive con-
sumption of power.
