26
I
I N S T R U M E N T S a n d C O N T R O L S Maximum coolant temperature If this comes on, it indicates
that the temperature in the
cooling system is too high.
Stop the vehicle as soon as
it is safe to do so.
Low fuel level When the tank is full, all the
bars are lit.
If the fuel low warning lamp
comes on accompanied by
an audible signal and a message on
the multifunction screen, there are ap-
proximately 7 litres of fuel remaining
in the tank and 2 or 3 bars are lit.
When the last bar goes out, there
are approximately 2 litres of fuel re-
maining in the tank.
Lighting is associated
with the lighting of an-
other warning lamp:
Service If this comes on, it indi-
cates the occurrence
of a problem in one
of the systems which
does not have a spe-
c i fi c w a r n i n g l a m p .
It is accompanied by a message on
the multifunction display.
The warning lamp comes on tempo-
rarily in the case of minor faults.
In the case of major faults, the warn-
ing lamp remains on until the op-
e r a t i n g f a u l t i s r e c t i fi e d . C o n t a c t a
CITROËN dealer as soon as pos-
sible. Braking
If this comes on, it indicates
the occurrence of a fault in
one of the braking systems:
- s i g n i fi c a n t d r o p i n t h e fl u i d l e v e l in the circuit,
- electronic brake force distribu- tion (EBFD) faulty (simultane-
ous lighting of the ABS warning
lamp),
stop the vehicle as soon as it is safe
to do so.
Contact a CITROËN dealer.
Dynamic stability control
(ESP/ASR).
The ESP/ASR system is put
into service automatically
when the vehicle is started.
Unless the system has been de-
activated, if this warning lamp and
the indicator lamp on the button
come on continuously, this indi-
cates the occurrence of a fault in the
ESP/ASR system or in the hill start
assistance. Engine autodiagnostics system
If this comes on, it indicates
the occurrence of a fault in
the engine management
system.
I f i t fl a s h e s , i t i n d i c a t e s t h e o c c u r -
rence of a fault in the emission con-
trol system.
Central alert
- punctured wheel,
- braking,
- coolant temperature,
stop the vehicle as soon as it is safe
to do so.
Contact a CITROËN dealer.
Anti-lock braking system (ABS) If this comes on, it indicates
the occurrence of a fault in
the anti-lock braking system.
However, this does not prevent op-
eration of the vehicle's servo-assist-
ed braking system.
Page 31 of 282
28
I
I N S T R U M E N T S a n d C O N T R O L S
5 seconds after the ignition is switched
on, the spanner is switched off ; the
distance recorder resumes its normal
operation. The display then indicates
the total and trip distances. Less than 620 miles (1 000 km)
remain before the next service is
due
Example: 500 miles remain before
the next service is due.
For 5 seconds after the ignition is
switched on, the display indicates: Service overdue
For 5 seconds after the ignition is
switched on,
t h e s p a n n e r fl a s h e s
to indicate that the service must be
carried out as soon as possible.
Example: the service is overdue by
300 miles.
For 5 seconds after the ignition is
switched on, the display indicates:
5 seconds after the ignition is
switched on, the distance recorder
resumes its normal operation. The
spanner remains on to indicate that
a service must be carried out soon. 5 seconds after the ignition is
switched on, the distance recorder
resumes its normal operation.
The
spanner remains lit .
More than 620 miles (1 000 km)
remain before the next service is
due
For 5 seconds after the ignition is
switched on, the spanner symbolis-
ing the service operations comes on.
The distance recorder display line
indicates the distance remaining be-
fore the next service is due.
Example: 1 900 miles remain be-
fore the next service is due.
For 5 seconds after the ignition is
switched on, the display indicates:
The distance remaining may be
weighted by the time factor, depend-
ing on the driver's driving habits.
Therefore, the spanner may also
come on if you have exceeded the
two year service interval.
Page 32 of 282
29
I
I N S T R U M E N T S a n d C O N T R O L S
Maintenance indicator zero reset Engine oil level indicator
After each service, the maintenance
indicator must be reset to zero.
Your CITROËN technician resets the
indicator to zero after each service.
However, if you do your own serv-
icing, the procedure for resetting to
zero is as follows:
switch off the ignition,
press and hold the trip distance
recorder zero reset button,
switch on the ignition; the dis-
tance recorder display begins a
countdown,
when the display indicates "=0" ,
release the button; the spanner
disappears. System which informs the driver
whether the engine oil level is cor-
rect or not.
This information is displayed for a
few seconds when the ignition is
switched on, after the service infor-
mation.
The level read will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 15 minutes.
Oil level correct
Oil level low
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL" , accompanied by an audible
signal and a message on the multi-
function screen.
I f t h e l o w o i l l e v e l i s c o n fi r m e d b y a
check using the dipstick, it is essen-
tial that the level is topped up to pre-
vent damage to the engine. Oil level gauge fault
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL --" . Contact a CITROËN dealer.
Dipstick
Refer to the "Checks" section to lo-
c a t e t h e d i p s t i c k a n d t h e o i l fi l l e r c a p
on your engine. There are 2 marks on
the dipstick:
- A = max; never ex-
ceed this level,
- B = min; top up the
l e v e l v i a t h e o i l fi l l e r
cap, using the type
of oil suited to your
engine.
Following this operation, if you wish
to disconnect the battery, lock the
v e h i c l e a n d w a i t a t l e a s t fi v e m i n u t e s
for the zero reset to be taken into ac-
count.
Page 33 of 282
30
I
I N S T R U M E N T S a n d C O N T R O L S
Total distance recorder
System which measures the total
distance travelled by the vehicle
during its life.
The total and trip distances are dis-
played for thirty seconds when the
ignition is switched off, when the
driver's door is opened and when
the vehicle is locked or unlocked.
Trip distance recorder
System which measures a distance
travelled during a day or other period
until it is reset to zero by the driver.
With the ignition on, press the
button until zeros appear. Dashboard lighting rheostat
Activation
Turn control A or press control B
to adjust the brightness of the
dashboard lighting,
With control B , press until the
brightness is at maximum, release,
press until you reach minimum.
Deactivation
When the lights are off, or in day
m o d e i n t h e c a s e o f v e h i c l e s fi t t e d
with daytime running lights, the but-
ton has no effect.
System permitting manual adjust-
ment of the brightness of the dash-
board to suit the level of ambient
light.
The rheostat is active if the sidela-
mps are on and applies to:
- the instrument panel,
- the display screens.
Page 34 of 282
31
II
M U L T I F U N C T I O N D I S P L A Y S
MULTIFUNCTION SCREEN A
Presentation
1. Time
2. Date and display zone
3. Ambient temperature
When the ambient temperature is
between +3 °C and -3 °C, the tem-
p e r a t u r e d i s p l a y fl a s h e s ( i c e r i s k ) .
The ambient temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
T h e d i s p l a y o f c e r t a i n t y p e s o f i n -
f o r m a t i o n i s s o m e t i m e s b y s c r o l l i n g
and sometimes by alternating be-
t w e e n t h e m .
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. C o n fi r m a t i o n a n d s e l e c t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a -
tion to be displayed in zone 2
( d a t e , r a d i o - C D a n d t r i p r e c o r d e r )
B or F. W i t h i n t h e m e n u s , c h o i c e
o f a c t i v a t i o n / d e a c t i v a t i o n o f
f u n c t i o n s a n d s e l e c t i o n o f
adjustments By pressing button
A , then using
button B , y o u h a v e a c c e s s t o t h e f o l -
l o w i n g f u n c t i o n s :
Page 36 of 282
33
II
M U L T I F U N C T I O N D I S P L A Y S
MULTIFUNCTION SCREEN C M a i n M e n u
Presentation
Radio-CD
( s e e " A u d i o " )
T r i p c o m p u t e r
T h i s p e r m i t s :
B l u e t o o t h
®
h a n d s - f r e e k i t
( s e e " A u d i o " )
Controls
1. Time
2. Ambient temperature
3. Date and display zone
When the ambient temperature is
between +3 °C and -3 °C, the tem-
p e r a t u r e d i s p l a y fl a s h e s ( i c e r i s k ) .
The ambient temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
I t i s r e c o m m e n d e d t h a t t h e d r i v e r
s h o u l d n o t o p e r a t e t h e c o n t r o l s
w h i l e t h e v e h i c l e i s i n m o t i o n .
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. C o n fi r m a t i o n a n d s e l e c t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a -
tion to be displayed permanently
( d a t e , r a d i o - C D , t r i p c o m p u t e r )
o n t h e r i g h t o f t h e s c r e e n ( S e e
" T r i p c o m p u t e r " ) Press button
A t o v i e w t h e " M a i n
M e n u " o f t h e m u l t i f u n c t i o n s c r e e n .
T h i s m e n u g i v e s y o u a c c e s s t o t h e
f o l l o w i n g f u n c t i o n s :
- e n t e r i n g t h e d i s t a n c e t o y o u r destination,
- a c c e s s t o t h e l o g o f a l e r t s ( r e c a l l o f a l e r t s s i g n a l l e d p r e v i o u s l y ) ,
- a c c e s s t o t h e s t a t u s o f f u n c t i o n s , s u c h a s t h e a c t i v a t i o n / d e a c t i v a -
t i o n o f t h e a u t o m a t i c h e a d l a m p s ,
o f t h e a u t o m a t i c w i n d s c r e e n w i p -
e r s , o f t h e E S P . . .
Page 39 of 282
36
II
M U L T I F U N C T I O N D I S P L A Y S
NAVIDRIVE MULTIFUNCTION COLOUR SCREEN
Presentation
1. Outside temperature
2. D i r e c t o r y
3. Date
4. Telephone
5. Time
When the outside temperature is be-
tween +3 °C and -3 °C, the tempera-
t u r e d i s p l a y fl a s h e s ( i c e r i s k ) .
The outside temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
I t i s r e c o m m e n d e d t h a t t h e d r i v e r
s h o u l d n o t o p e r a t e t h e c o n t r o l s
w h i l e t h e v e h i c l e i s i n m o t i o n . Controls
M a i n M e n u
T r a f fi c I n f o r m a t i o n
N a v i g a t i o n / G u i d a n c e
Map
A u d i o F u n c t i o n s
T e l e m a t i c s
C o n fi g u r a t i o n ,
for adjusting various param-
e t e r s ( d a t e , t i m e , u n i t s )
Video
V e h i c l e D i a g n o s t i c s
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. C o n fi r m a t i o n a n d s e l e c t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a -
tion to be displayed permanently
( d a t e , r a d i o - C D , t r i p c o m p u t e r )
o n t h e r i g h t o f t h e s c r e e n Press on the button
A to view the
" M a i n M e n u " o f t h e m u l t i f u n c t i o n
s c r e e n .
T h i s m e n u g i v e s y o u a c c e s s t o t h e
f o l l o w i n g f u n c t i o n s ( s e e " N a v i D r i v e
I n s t r u c t i o n s " ) :
Page 40 of 282
37
II
M U L T I F U N C T I O N D I S P L A Y S
TRIP COMPUTER
S y s t e m w h i c h p r o v i d e s c u r r e n t
i n f o r m a t i o n c o n c e r n i n g t h e r o u t e
t r a v e l l e d ( r a n g e , c o n s u m p t i o n . . . ) .
M o n o c h r o m e s c r e e n A Data displays
P r e s s t h e c o n t r o l f o r m o r e t h a n
t w o s e c o n d s t o r e s e t t o z e r o t h e
d i s t a n c e t r a v e l l e d , t h e a v e r a g e
c o n s u m p t i o n a n d t h e a v e r a g e
s p e e d .
Zero reset
T h e t r i p c o m p u t e r p r o v i d e s t h e f o l -
l o w i n g i n f o r m a t i o n :
- range,
- c u r r e n t c o n s u m p t i o n ,
- d i s t a n c e t r a v e l l e d ,
- a v e r a g e c o n s u m p t i o n ,
- a v e r a g e s p e e d .
The next press then returns you
t o t h e n o r m a l d i s p l a y .
P r e s s t h e b u t t o n , l o c a t e d a t t h e
end of the wiper
s t a l k , to display
t h e v a r i o u s i t e m s o f t r i p c o m p u -
t e r d a t a i n s u c c e s s i o n .
