65COMFORT AND SAFETY-
FRONT LAYOUT
4. Courtesy lights 5. Sun visors
Permanently off.
On entering the vehicle: - they come on when the vehicle is unlocked or
when a door is opened,
- they switch off after approxi- mately 30 seconds with the doors
closed, or when the ignition is
switched on.
On leaving the vehicle:
- they come on when the key is removed from the ignition (timing
of approximately 30 seconds) or
when a door is opened,
- they switch off after approximately 30 seconds with all of the doors
closed, or immediately when the
vehicle is locked.
In this position, the courtesy light
m a y fl a s h w h i l e d r i v i n g i f a d o o r i s n o t
closed correctly.
If a door is open, it will switch off
automatically after approximately
10 minutes or when the ignition is
switched on. Permanently on when the
key is in the accessories
position or the ignition is on.
1. Storage in the doors
A. Bottle holder.
B. Can holder.
C. Storage compartment.
2. Overhead storage
Maximum load: 5 kg .
3. Map reading lights
Turn the dial to the right or to the left
to switch them on.
Place the dial in the centre to switch
them off. 6. Glove box
7. Lighter
It permits the connection of a telephone
charger, a baby’s bottle warmer, ...
8. Removable ashtray
Pull the cover to open the ashtray.
To empty, after opening, remove it by
pulling upwards.
9. Storage drawer (passenger)
To open the drawer, lift it slightly and
pull it forwards.
Page 78 of 115
77DRIVING-
If this warning light comes on,
accompanied by an audible
signal, contact a CITROËN
dealer to have the system
checked. The air bags may
no longer be triggered in the event of
a serious impact.
F r o n t a i r b a g m a l f u n c t i o n
D i s a r m i n g t h e p a s s e n g e r a i r b a g
T o e n s u r e t h e s a f e t y o f y o u r c h i l d ,
i t i s e s s e n t i a l t o d i s a r m t h e p a s -
s e n g e r a i r b a g w h e n y o u i n s t a l l a
r e a r - f a c i n g c h i l d s e a t o n t h e f r o n t
p a s s e n g e r s e a t . O t h e r w i s e , t h e
c h i l d w o u l d r i s k b e i n g k i l l e d o r s e -
r i o u s l y i n j u r e d i f t h e a i r b a g w e r e
t o i n fl a t e .
W i t h t h e i g n i t i o n s w i t c h e d o f f ,
insert the key into the passenger
air bag disarming switch 1 , turn
it to the "OFF" position, then re-
move the key keeping the slot in
this position. The air bag warning light
on the instrument panel is
lit throughout the period of
disarming.
In the "OFF" position, the passen-
ger air bag will not be triggered in the
event of an impact.
As soon as the child seat is removed,
turn the air bag slot to the "ON" po-
sition to re-activate the air bag and
thus ensure the safety of your pas-
senger in the event of an impact.
T h i s i s c o n fi r m e d b y a n i n d i -
cator light, accompanied by
a message on the display.
With the ignition on (2nd
notch), illumination of this warning
light indicates that the passenger air
bag is disarmed (switch in the "OFF"
position).
If the two air bag warning
lights are lit continuously, do
not install a rear-facing child
seat. Consult a CITROËN
dealer.
D i s a r m i n g c h e c k
Page 81 of 115
77DRIVING-
If this warning light comes on,
accompanied by an audible
signal, contact a CITROËN
dealer to have the system
checked. The air bags may
no longer be triggered in the event of
a serious impact.
F r o n t a i r b a g m a l f u n c t i o n
D i s a r m i n g t h e p a s s e n g e r a i r b a g
T o e n s u r e t h e s a f e t y o f y o u r c h i l d ,
i t i s e s s e n t i a l t o d i s a r m t h e p a s -
s e n g e r a i r b a g w h e n y o u i n s t a l l a
r e a r - f a c i n g c h i l d s e a t o n t h e f r o n t
p a s s e n g e r s e a t . O t h e r w i s e , t h e
c h i l d w o u l d r i s k b e i n g k i l l e d o r s e -
r i o u s l y i n j u r e d i f t h e a i r b a g w e r e
t o i n fl a t e .
W i t h t h e i g n i t i o n s w i t c h e d o f f ,
insert the key into the passenger
air bag disarming switch 1 , turn
it to the "OFF" position, then re-
move the key keeping the slot in
this position. The air bag warning light
on the instrument panel is
lit throughout the period of
disarming.
In the "OFF" position, the passen-
ger air bag will not be triggered in the
event of an impact.
As soon as the child seat is removed,
turn the air bag slot to the "ON" po-
sition to re-activate the air bag and
thus ensure the safety of your pas-
senger in the event of an impact.
T h i s i s c o n fi r m e d b y a n i n d i -
cator light, accompanied by
a message on the display.
With the ignition on (2nd
notch), illumination of this warning
light indicates that the passenger air
bag is disarmed (switch in the "OFF"
position).
If the two air bag warning
lights are lit continuously, do
not install a rear-facing child
seat. Consult a CITROËN
dealer.
D i s a r m i n g c h e c k
Page 86 of 115
PRACTICAL INFORMATION84 -
CHECKING THE LEVELS
Dipstick
Oil change
According to the information given in
the servicing booklet.
Note: a v o i d u s e d o i l c o m i n g i n t o
prolonged contact with the skin.
E m p t y t h e u s e d o i l i n t o t h e c o n t a i n -
e r s i n t e n d e d f o r t h i s p u r p o s e i n t h e
CITROËN network. Viscosity selection
I n a l l c a s e s , t h e o i l s e l e c t e d m u s t m e e t
t h e m a n u f a c t u r e r ’ s r e q u i r e m e n t s .
Note: the coolant does not need to
be changed.
For vehicles equipped with a parti-
c l e fi l t e r , t h e e n g i n e f a n m a y o p e r a t e
after the ignition has been switched
o f f , e v e n w h e n t h e e n g i n e i s c o l d .
There are two marks
on the dipstick:
A = m a x i m u m
N e v e r fi l l p a s t t h i s
mark.
B = m i n i m u m
To maintain the reliability
of engines and emission
c o n t r o l s y s t e m s , t h e u s e
of additives in engine oil
is prohibited. Brake fluid level:
T h e b r a k e fl u i d m u s t b e c h a n g e d a c -
c o r d i n g t o t h e m a n u f a c t u r e r ’ s s e r v i c i n g
s c h e d u l e .
U s e fl u i d s r e c o m m e n d e d b y t h e
m a n u f a c t u r e r , w h i c h f u l fi l D O T 4
standards.
Note: b r a k e fl u i d i s h a r m f u l t o h e a l t h
and very corrosive. Avoid all contact
with the skin.
C o o l i n g s y s t e m
U s e t h e fl u i d r e c o m m e n d e d b y t h e
m a n u f a c t u r e r .
When the engine is warm, the tem-
p e r a t u r e o f t h e c o o l a n t i s c o n t r o l l e d
by the engine fan. As this fan can op-
erate with the ignition key removed
a n d b e c a u s e t h e c o o l i n g s y s t e m i s
p r e s s u r i s e d , w a i t f o r a t l e a s t o n e h o u r
after the engine has stopped before
c a r r y i n g o u t a n y w o r k .
S l a c k e n t h e c a p b y t w o t u r n s t o r e -
l e a s e t h e p r e s s u r e t o p r e v e n t a n y
r i s k o f s c a l d i n g . W h e n t h e p r e s s u r e
has dropped, remove the cap and
t o p u p t h e l e v e l . Used oil
D o n o t d i s p o s e o f u s e d o i l , b r a k e fl u i d o r
c o o l a n t i n t o d r a i n s o r o n t o t h e g r o u n d .
Power steering reservoir
Open the reservoir, with the en-
g i n e a t a m b i e n t t e m p e r a t u r e . T h e
l e v e l s h o u l d a l w a y s b e a b o v e t h e
MIN. mark and close to the MAX.
mark.
W i n d s c r e e n a n d h e a d l a m p
wash level
F o r b e s t q u a l i t y c l e a n i n g a n d f o r
y o u r s a f e t y , w e w o u l d a d v i s e t h a t
y o u u s e p r o d u c t s r e c o m m e n d e d b y
CITROËN .
F o r o p t i m u m c l e a n i n g a n d t o p r e v e n t
f r e e z i n g , t h i s fl u i d m u s t n o t b e t o p p e d
u p o r r e p l a c e d w i t h w a t e r .
Oil level
C h e c k t h e l e v e l r e g u l a r l y a n d t o p
u p b e t w e e n c h a n g e s . T h e m a x i -
m u m c o n s u m p t i o n i s 0 . 5 l p e r
600 miles (1 000 km).
Check the level with the vehicle level,
e n g i n e c o l d , u s i n g t h e o i l l e v e l g a u g e
o n t h e i n s t r u m e n t p a n e l o r t h e d i p s t i c k .
Page 99 of 115
9 5PRACTICAL INFORMATION-
ECONOMY MODE FUNCTION
After the engine has stopped, with
the key in the "accessories" position,
c e r t a i n f u n c t i o n s ( w i n d s c r e e n w i p e r ,
e l e c t r i c w i n d o w s , c o u r t e s y l i g h t s ,
a u d i o e q u i p m e n t , e t c . ) c a n o n l y b e
u s e d f o r a c o m b i n e d d u r a t i o n o f a p -
p r o x i m a t e l y t h i r t y m i n u t e s , t o p r e v e n t
discharging the battery.
O n c e t h e t h i r t y m i n u t e s a r e o v e r , a
switching to economy mode mes-
s a g e a p p e a r s o n t h e m u l t i - f u n c t i o n
d i s p l a y a n d t h e a c t i v e f u n c t i o n s a r e
p u t o n s t a n d b y .
T h e s e f u n c t i o n s a r e r e a c t i v a t e d a u -
tomatically next time the vehicle is
driven.
I n o r d e r t o r e s u m e t h e u s e o f t h e s e
f u n c t i o n s i m m e d i a t e l y , t h e e n g i n e
m u s t b e s t a r t e d a n d l e f t t o r u n f o r a
f e w m i n u t e s .
T h e t i m e a v a i l a b l e t o y o u w i l l t h e n b e
d o u b l e t h e d u r a t i o n f o r w h i c h t h e e n -
g i n e i s l e f t r u n n i n g . H o w e v e r , t h i s p e r i o d
w i l l a l w a y s b e b e t w e e n fi v e a n d t h i r t y
m i n u t e s .
BATTERY
It is advisable to disconnect the
battery if the vehicle is not to be
u s e d f o r a p e r i o d o f m o r e t h a n
o n e m o n t h .
Before disconnecting the bat-
t e r y , y o u m u s t w a i t 2 m i n u t e s
after switching off the ignition.
Never disconnect a terminal
w h e n t h e e n g i n e i s r u n n i n g .
N e v e r c h a r g e a b a t t e r y w i t h o u t fi r s t
disconnecting the terminals.
Close the windows and the roof be-
fore disconnecting the battery.
After every reconnection of the bat-
tery, switch on the ignition and wait
1 m i n u t e b e f o r e s t a r t i n g t o a l l o w t h e
electronic systems to be initialised. If
s l i g h t d i f fi c u l t i e s a r e e x p e r i e n c e d a f -
ter this, please contact a CITROËN
dealer.
A fl a t b a t t e r y p r e v e n t s t h e
engine from starting.
T o s t a r t t h e v e h i c l e f r o m
another battery:
- Connect the red cable to the positive
(+) terminals of the two batteries,
- Connect one end of the green or black cable to the negative (-) ter-
minal of the slave battery,
- Connect the other end of the green or black cable to an earth
point on the broken down vehicle
as far as possible from the battery
(for example, right-hand engine
m o u n t i n g ) .
O p e r a t e t h e s t a r t e r , l e t t h e e n g i n e r u n .
W a i t f o r t h e e n g i n e t o r e t u r n t o i d l e ,
then disconnect the cables.
To charge the battery using a
battery charger:
- Disconnect the battery,
- F o l l o w t h e i n s t r u c t i o n s f o r u s e
given by the battery charger man-
u f a c t u r e r ,
- Reconnect starting with the nega- tive (-) terminal,
- Check that the terminals and connectors are clean. If they are
c o v e r e d w i t h s u l p h a t e ( w h i t e o r
greenish deposit), disconnect
them and clean them.
