8-40
82. Make sure to properly connect the battery
leads to the battery terminals.
CAUTION:ECB00630Always keep the battery charged. Storing a
discharged battery can cause permanent
battery damage.To charge a sealed-type (MF) battery, a spe-
cial constant-voltage battery charger is re-
quired. Using a conventional battery charger
will damage the battery. If you do not haveaccess to a constant-voltage battery charg-
er, have a Yamaha dealer charge your bat-
tery.EBU25323Replacing a fuse
1. Positive battery terminal
2. Negative battery terminal
1. Main fuse
2. Spare main fuse
3. Fuse box
U4S260E0.book Page 40 Tuesday, October 3, 2006 1:53 PM
8-41
8
The main fuse and the fuse box are located under
the seat. (See page 4-17.)
If a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off all electrical
circuits.
CAUTION:ECB00640To prevent accidental short-circuiting, turn off
the main switch when checking or replacing afuse.
2. Remove the blown fuse, and then install a
new fuse of the specified amperage.
1. Headlight fuse
2. Ignition fuse
3. Auxiliary DC jack fuse (for optional auxiliary DC jack)
4. Four-wheel-drive motor fuse
5. Signaling system fuse
6. Spare fuse
Specified fuses:
Main fuse:
30.0 A
Headlight fuse:
15.0 A
Ignition fuse:
15.0 A
Four-wheel-drive motor fuse:
10.0 A
Signaling system fuse:
10.0 A
Auxiliary DC jack fuse:
10.0 A
