2007 VOLVO XC90 warning light

2007 Volvo XC90
The indicator and warning symbols light up when you turn the ignition ke\
y to the driving position
(position II) before starting. This shows that the symbols are functio\
ning. When the engine starts, all
symbols go out. If the engine is not started within 5 seconds, all symbo\
ls except CHECK ENGINE and
go out. Certain symbols may not have their functions illustrated, depen\
ding on the vehicle's
equipment. The symbol for the parking brake goes out when the parking br\
ake is released.
Warning symbol
in center of the instrument panel
This symbol shines as a red or yellow light depending on the severity of\
the discovered fault.
Red symbol - Stop the vehicle as soon as possible in a suitable location and read t\
he message shown in
the text window. The symbol and accompanying text will remain on until t\
he fault has been corrected.
Yellow symbol - Follow the instructions shown in the text window. The text can be eras\
ed by pressing
the READ button (see
page 50), or will disappear automatically after two minutes.
NOTE: When the message "TIME FOR REGULAR SERVICE" is displayed, the text can \
be erased and
the yellow symbol light can be turned off by pressing the READ button. T\
he text will disappear and the
symbol light will go out automatically after two minutes.
Seat belt reminder
This symbol lights up to indicate that the driver has not fastened his/h\
er seat belt.
Supplemental Restraint System SRS
If this light comes on while the vehicle is being driven, or remains on \
for longer than approximately 10
seconds after the vehicle has been started, the SRS system's diagnostic \
functions have detected a fault in
a seat belt lock or tensioner, a front airbag, side impact airbag, and/o\
r an inflatable curtain. Have the
system(s) inspected by a trained and qualified Volvo service technicia\
n as soon as possible.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (6 of 40)12/30/2006\
5:53:37 PM

2007 Volvo XC90
pg. 48 Instruments and controls
Indicator and warning symbols
BRAKE Brake failure warning light If the light comes on while driving or brak\
ing, stop immediately,
open the hood and check the brake fluid level in the reservoir. See
page 185 for reservoir position and
page 189 for instructions.
Canadian models are equipped with this warning light
If the BRAKE and ABS warning lights come on at the same time, this could\
indicate a fault in the
brake system.
- Stop the vehicle in a suitable place and switch off the engine.
- Restart the engine.
- If both warning lights go off, no further action is required.
- If both lights are still on after the engine has been restarted, switc\
h off the engine again and check the
brake fluid level (see
page 185 for the location of the brake fluid reservoir).
- If the brake fluid level is above the MIN mark, drive carefully to an \
authorized Volvo retailer and have
the brake system inspected.
WARNING!
If the fluid level is below the MIN mark in the reservoir or if a "Brake\
failure - Service urgent"
message is displayed in the text window: DO NOT DRIVE. Have the vehicle \
towed to an authorized
Volvo retailer and have the brake system inspected.
PARK BRAKE Parking brake applied This light will be on when the parking brake (ha\
nd brake) is
applied. applied. The parking brake pedal is located on the left side of\
the driver's footwell. See also
page 66 for additional information.
Canadian models are equipped with this symbol.
Oil pressure warning light If the light comes on while driving, stop the\
vehicle and then stop
the engine immediately and check the engine oil level. See
page 187. If the light stays on after restart,
have the vehicle towed to the nearest authorized Volvo retailer. After h\
ard driving, the light may come
on occasionally when the engine is idling. This is normal, provided it g\
oes off when the engine speed is
increased.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (7 of 40)12/30/2006\
5:53:37 PM

2007 Volvo XC90
Generator warning light
If the light comes on while the engine is running, have the charging sys\
tem checked.
Rear fog light
This light indicates that the fog light is on.
CHECK ENGINE Malfunction indicator light
On-Board Diagnostics II (OBDII): As you drive, a computer called "OBDI\
I" monitors your vehicle's
engine, transmission, electrical and emission systems. The CHECK ENGINE \
light will light up if the
computer senses a condition that potentially may need correcting. When t\
his happens, please have your
vehicle checked by a Volvo retailer as soon as possible.
A CHECK ENGINE light may have many causes. Sometimes, you may not notice\
a change in your
vehicle's behavior. Even so, an uncorrected condition could hurt fuel ec\
onomy, emission cleanliness, and
driveability. Extended driving without correcting the cause could even d\
amage other components in
your vehicle.
Canadian models are equipped with this warning light.
pg. 49 Instruments and controls
Indicator and warning symbols
Anti-lock brake system ABS
If the warning light comes on, there is a malfunction of the ABS system \
(the standard braking system
will still function). The vehicle should be driven to a Volvo retailer \
for inspection. See
page 128 for
additional information.
DSTC system
The Dynamic Stability and Traction Control system (DSTC) is explained \
in greater detail on
page 130.
Tire pressure monitoring light
See
page 154 for more information on this function.
Turn signal indicator - trailer (certain models)
If you are towing a trailer, this light will flash simultaneously with t\
he turn signals on the trailer. If the
light does not flash when signaling, neither the trailer's turn signals \
nor the vehicle's turn signals are
functioning.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (8 of 40)12/30/2006\
5:53:37 PM

2007 Volvo XC90
pg. 50 Instruments and controls
Indicator and warning symbols
Messages in the text window
When a warning light in the instrument panel comes on, a message is also\
displayed in the text window.
After you have read the message, you can erase it by pressing button A (\
see illustration).
NOTE: Certain messages cannot be erased until the condition has been correcte\
d. If a warning message
is displayed when e.g. you are using the trip computer, this message mus\
t be erased before you can
access the function of your choice. Press button A to erase the warning \
message.
You can scroll through the stored messages by pressing button A (see il\
lustration). The text window can
be cleared (the message will be returned to memory) by pressing button\
A again.
pg. 51 Instruments and controls
Indicator and warning symbols
STOP SAFELYStop and switch off the engine - to help prevent serious risk of
damage.
STOP ENGINE Stop and switch off the engine - to help prevent serious risk of
damage.
SERVICE URGENT Take your vehicle to a trained and qualified Volvo service
technician for inspection immediately.
SEE MANUAL Refer to your owner's manual. For additional information,
please contact your Volvo retailer.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (9 of 40)12/30/2006\
5:53:37 PM

2007 Volvo XC90
Active Bi-Xenon headlights (ABL) - option
The beams of ABL headlights adjust laterally to help light up a curve ac\
cording to movements of the
steering wheel when the vehicle is turning. This function is activated a\
utomatically when the engine is
started and can be deactivated/reactivated by pressing the button. The i\
ndicator light in the button is on
when the function is activated. See also
page 55.
Rear seat air conditioning (option)
This button controls the optional rear seat air conditioning system on s\
even-seat models.
Folding sideview mirrors (option)
Press the button and release it to fold the sideview mirrors in or out. \
On certain models, when the button
is pressed, there may be a long pause before the mirrors move. Pressing \
the button again during this
pause may erase your first button press. If this happens, wait ten secon\
ds and press the button one more
time.
The mirrors cannot be adjusted during the first ten seconds after they h\
ave been folded out.
NOTE: If the sideview mirrors have been inadvertently pushed out of position \
(in a car wash, parking
lot, etc.) manually return them to normal position. If mirror adjustmen\
t does not seem to operate after
manual folding, reset the folding mirrors as follows:
- Turn the ignition key to position II.
- Manually fold the mirror(s) to the normal position.
- Press the button to fold both mirrors in.
- Press the button again to fold the mirrors out to their normal positio\
n.
Park Assist (option/ accessory as available)
This system provides an audible warning when the vehicle is being parked\
or if it is driven close to a
person or object. See
page 131 for more information.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (11 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
pg. 54 Instruments and controls
Steering wheel adjustment
Both the height and the reach of the steering wheel can be adjusted to a\
comfortable position for the
driver. Pull down the lever on the left of the steering column. Adjust t\
he steering wheel to a suitable
position and press the lever back into place to lock the steering wheel \
in the new position. Check that the
steering wheel is locked in the new position.
WARNING!
Never adjust the steering wheel while
driving.
pg. 55 Instruments and controls
Lighting panel
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (13 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Hazard warning flashers
The four-way flasher should be used to indicate that the vehicle has bec\
ome a traffic hazard. To activate
the flashers, press the triangular button in the center dash. Press the \
button again to turn off the flashers.
NOTE: Regulations regarding the use of the hazard warning flasher may vary, d\
epending on where you
live.

Rear window and sideview mirror defroster
Press the switch to start heating the rear window and sideview mirrors t\
o remove ice or condensation. A
light in the switch will light up.
A timer automatically switches off the heating after approximately 12 mi\
nutes. The LED will go out
correspondingly.
pg. 62 Instruments and controls
Trip computer (option)
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (22 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
warning will be displayed in the text window.
l The covers should be kept on when the auxiliary sockets are not in use. \
l Maximum current from the sockets is 15A.
Ashtrays/cigarette lighter
The auxiliary sockets can also be used for cigarette lighters.
Ashtrays and lighters are available as accessories. Please contact your \
Volvo retailer.
pg. 66 Instruments and controls
Parking brake
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (27 of 40)12/30/200\
6 5:53:37 PM
