2007 TOYOTA YARIS headlight

32007 YARIS HATCHBACK from Feb. ’07Prod. (OM52754U)
1. Headlight, turn signal and front fog lightswitches
2. Wiper and washer switches
3. Emergency flasher switch
4. Audio system
5. Front passenger airbag on −off indicator
lights
6. Front passenger ’s seat belt reminder light
7. Rear window defogger switch
8. Power outlet
9. Air conditioning controls
10. Ignition switch 11. Tilt steering lock release lever
PS11502

72007 YARIS HATCHBACK from Feb. ’07Prod. (OM52754U)
“AIRBAG ON” indicator light
Taillight indicator light
Turn signal indicator lights
Headlight high beam indicator light High engine coolant temperature warning light
∗
1
Headlight low beam indicator light
∗1: For details, see “Service reminder indicators and warning
buzzers” on page 114 in Section 1− 6.
∗
2: For details, see “Engine coolant temperature indicator and
warning light” on page 111 in Section 1− 6.
Low engine coolant temperature indicator light∗
2
Engine oil replacement reminder light∗1
“AIRBAG OFF” indicator light
Front fog light indicator light

182007 YARIS HATCHBACK from Feb. ’07Prod. (OM52754U)
—Activating panic mode
PS12515
Ty p e A
PS12541
Ty p e B
Pushing the panic switch for 1 second
blows the horn intermittently and
flashes the headlights, tail lights and
emergency flashers and turns on the
interior light.
The panic switch is used to deter vehicle
theft when you witness anyone attempting
to break into or damage your vehicle.
The panic mode will last for one minute.
To stop the panic mode midway, do the
following:
Push any switch on the key.
Turn the ignition key from the “LOCK”
to “ON” position.
The panic mode does not work when the
ignition key is in the “ON” position.
—Replacing battery
For replacement, use a CR2016 lithium
battery or equivalent and a flathead
screwdriver or equivalent.
CAUTION
Special care should be taken to pre-
vent small children from swallowing
the removed battery or components.
NOTICE
 When replacing the battery, be care-
ful not to lose the components.
 Replace only with the same or
equivalent type recommended by a
Toyota dealer.
 Dispose of used batteries according
to the local laws.
Replace the battery by following these
procedures:

282007 YARIS HATCHBACK from Feb. ’07Prod. (OM52754U)
PS12531
To deter vehicle theft, the system is
designed to sound an alarm if any of
the side doors, back door or hood is
forcibly unlocked and opened.
The alarm blows the horn intermittently
and flashes the headlights, tail lights and
turn signal lights, and turns on the interior
light.
PS12511
SETTING THE SYSTEM1. Turn the ignition key to the “LOCK” position and remove it.
2. Have all passengers get out of the vehicle.
3. Close and lock all the side doors, back door and hood.
Use the key to lock the last door.
When the back door is the last, turn
the key to the unlock position and then
turn to the door lock position.
The indicator light will remain on when all
the side doors, back door and hood are
closed and locked. The system will automatically be set after
30 seconds. When the system is set, the
indicator light will start flashing.
4. After making sure the indicator light starts flashing, you may leave the ve-
hicle.
Never leave anyone in the vehicle when
you set the system, because unlocking
from the inside will activate the system.
WHEN THE SYSTEM IS SET
Activating the system
The system will sound the alarm if any of
the side doors is unlocked or if the back
door or hood is forcibly opened without
the key.
The indicator light will come on when the
system is activated.
After one minute, the alarm will automati-
cally stop and the indicator light will starts
flashing again.
Reactivating the alarm
Once set, the system automatically resets
the alarm after the alarm stops.
The alarm will activate again under the
same circumstances described in
“Activating the system”.
Theft deterrent system
(vehicles sold in Puerto Rico
only)

982007 YARIS HATCHBACK from Feb. ’07Prod. (OM52754U)
—Folding rear view mirrors
PS14504
The rear view mirrors can be folded
backward for parking in compact areas.
To fold the rear view mirror, push back-
ward until you hear the click.
CAUTION
Do not drive with the mirrors folded
backward. Both the driver and pas-
senger side rear view mirrors must
be extended and properly adjusted
before driving.
NOTICE
Do not push backward more than the
click. It may damage the mirror or
vehicle.
PS14505
Adjust the mirror so you can just see
the rear of your vehicle in the mirror.
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror.
Daylight driving—Lever at position 1
The reflection in the mirror has greater
clarity at this position.
Night driving—Lever at position 2
Remember that by reducing glare you also
lose some rear view clarity.
Antiglare inside rear view
mirror

1012007 YARIS HATCHBACK from Feb. ’07Prod. (OM52754U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Lights, Wipers and Defogger
Headlights and turn signals102
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flashers 103
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Instrument panel light control 104
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front fog lights 104
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Interior light 105
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Personal lights 106
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Windshield wipers and washer 106
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window wiper and washer 107
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window defogger 107
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
SECTION 1 5

1022007 YARIS HATCHBACK from Feb. ’07Prod. (OM52754U)
Headlights and turn signals
PS15501
Except for Canada
PS15502
For Canada
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
For Canada—The tail light indicator (green
light) on the instrument panel will tell you
that the tail lights are on.
Position 2—Headlights and all of the
above
Except for Canada—The headlight low
beam indicator light (green light) on the
instrument panel will tell you that the low
beams are on.
Light reminder buzzer
A buzzer will remind you to turn the lights
off when the driver ’s door is opened if you
remove the key with the headlight switch
on.NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system
(on some models)
The daytime running light system can
make it easier for others to see the front
of your vehicle during the day. This sys-
tem can be helpful in many different driv-
ing conditions, but they can be especially
helpful in the short periods after dawn and
before sunset.
This system will make your headlights
come on at a reduced brightness when:
The engine is running.
The parking brake is released.
The headlight/turn signal lever knob is
in the “OFF” position.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
position 1.
Twist the knob to position 2 to turn the
headlights to full intensity for night driving.

1032007 YARIS HATCHBACK from Feb. ’07Prod. (OM52754U)
PS15503
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “OFF”.
PS15504
TURN SIGNALS
To signal a turn, push the headlight/
turn signal lever up or down to position
1.
The key must be in the “ON” position.
The lever automatically returns after you
make a turn, but you may have to return
it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position
2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal
bulb is burned out. See “Replacing light
bulbs” on page 288 in Section 7 −3.
Emergency flashers
PS15505
To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn
other drivers if your vehicle must be
stopped where it might be a traffic hazard.
Always pull as far off the road as pos-
sible.
The turn signal light switch will not work
when the emergency flashers are operat-
ing.
