2402007 TUNDRA from Jul. ’07 Prod. (OM34463U)
The A.D.D. can be engaged or disen-
gaged by the shifting operations de-
scribed in “(c) Shifting procedure”.
You should drive in four−wheel drive for
at least 16 km (10 miles) each month.
This will assure that the front drive com-
ponents are lubricated. SHIFTING BETWEEN “2WD” AND “4H”
To shift from “2WD” to “4H”,
reduce the
vehicle speed to less than 100 km/h (62
mph) and turn the front drive control
switch knob fully clockwise.
When the ambient temperature is −15 C
(5.0 F) or lower, shifting can be performed
with the vehicle speed below 70 km/h (43
mph).
If the “4HI” (high speed four −wheel drive)
indicator light continues to blink when you
operate the front drive control switch knob
from the “2WD” to the “4H” position, this
reminds you that the transfer mode is not
securely in “4H” mode. Drive straight
ahead while accelerating or decelerating.
If the “4HI” (high speed four −wheel drive)
indicator light continues to blink and the
buzzer sounds when you operate the front
drive control switch knob from the “2WD”
to the “4H” position, this reminds you that
the transfer mode is not in “4H” mode.
Stop the vehicle or reduce the vehicle
speed to less than 100 km/h (62 mph).
(When the ambient temperature is −15 C
(5.0 F) or lower, it needs to be reduced
to below 70 km/h (43 mph).) Operate the
switch knob again.CAUTION
Never operate the front drive control
switch knob if the wheels are slip-
ping. Stop the slipping or spinning
before operating.
To shift from “4H” to “2WD”, reduce the
vehicle speed to less than 100 km/h (62
mph) and turn the front drive control
switch knob fully counterclockwise.
When you operate the front drive control
switch knob from “4H” to “2WD” with the
vehicle speed at 100 km/h (62 mph) or
higher, the “4HI” indicator light continues
to blink and buzzer sounds. When the
switch knob is returned from “2WD” to
“4H”, the indicator light turns off and the
buzzer stops sounding.
If the “4HI” (high speed four −wheel drive)
indicator light continues to blink when you
operate the front drive control switch knob
from the “4H” to the “2WD” position, this
reminds you that the transfer mode is not
securely in “2WD” mode. Drive straight
ahead while accelerating or decelerating,
or drive forward or backward in a short
distance.
(b) A.D.D. (automatic
disconnecting differential) (c) Shifting procedure
4712007 TUNDRA from Jul. ’07 Prod. (OM34463U)
Driving in the rain
Driving on a slippery road surface
Drive carefully when it is raining, because
visibility will be reduced, the windows may
become fogged− up, and the road will be
slippery.
Drive carefully when it starts to rain,
because the road surface will be espe-
cially slippery.
Refrain from high speeds when driving
on an expressway in the rain, because
there may be a layer of water between
the tires and the road surface, prevent-
ing the steering and brakes from oper-
ating properly.
CAUTION
Sudden braking, acceleration and
steering when driving on a slippery
road surface may cause tire slip-
page and reduce your ability to
control the vehicle, resulting in an
accident.
Sudden changes in engine speed,
such as sudden engine braking,
may cause the vehicle to skid, re-
sulting in an accident.
After driving through a puddle,
lightly depress the brake pedal to
make sure that the brakes are func-
tioning properly. Wet brake pads
may prevent the brakes from func-
tioning properly. If the brakes on
only one side are wet and not func-
tioning properly, steering control
may be affected, resulting in an ac-
cident.
When encountering flooded roads
Do not drive on a road that has flooded
after heavy rain etc. Doing so may cause
serious damage to the vehicle.
NOTICE
Driving on a flooded road may cause
the engine to stall as well as cause
serious vehicle malfunctions such as
shorts in electrical components and
engine damage from water immersion.
In the event that you drive on a
flooded road and the vehicle is
flooded, be sure to have your Toyota
dealer check brake function, changes
in quantity and quality of oil and fluid
used for the engine, transmission,
transfer (4WD vehicles), differentials,
etc. and lubricant condition for the
propeller shaft, bearings and suspen-
sion joints (where possible) and the
function of all joints and bearings.
4732007 TUNDRA from Jul. ’07 Prod. (OM34463U)
NOTICE
If driving through water, such as
when crossing shallow streams,
first check the depth of the water
and the bottom of the river bed for
firmness. Drive slowly and avoid
deep water.
Take all necessary safety measures
to ensure that water damage to the
engine or other components does
not occur.
Water entering the engine air intake
will cause severe engine damage.
Water entering the automatic trans-
mission will cause deterioration in
shift quality, locking up of your
transmission accompanied by vibra-
tion, and ultimately damage.
Water can wash the grease from
wheel bearings, causing rusting and
premature failure, and may also en-
ter the differentials, transmission
and transfer case, reducing the gear
oil’s lubricating qualities.
Sand and mud that has accumulated
in brake drums and around brake
discs may affect braking efficiency
and may damage brake system com-
ponents.
Always perform a maintenance in-
spection after each day of off road
driving that has taken you through
rough terrain, sand, mud, or water.
For scheduled maintenance in-
formation, refer to the “Scheduled
Maintenance Guide” or “Owner’s
Manual Supplement”.Make sure your coolant is properly pro-
tected against freezing.
Only use “Toyota Super Long Life Coolant”
or similar high quality ethylene glycol
based non −silicate, non −amine, non− nitrite,
and non −borate coolant with long −life hy-
brid organic acid technology. (Coolant with
long −life hybrid organic acid technology is
a combination of low phosphates and or-
ganic acids.)
See “Checking the engine coolant level”
on page 546 in Section 7 −2 for details of
coolant type selection.
For the U.S.A.—“Toyota Super Long Life
Coolant” is a mixture of 50% coolant and
50% deionized water. This coolant pro-
vides protection down to about −35 C
( − 31 F).
For Canada—“Toyota Super Long Life
Coolant” is a mixture of 55% coolant and
45% deionized water. This coolant pro-
vides protection down to about −42 C
( − 44 F).
NOTICE
Do not use plain water alone.
Winter driving tips
