2007 SUZUKI ALTO engine

Downloaded from www.Manualslib.com manuals search engine 18
76G-74E
NOTE:
Moving the lock knob on passenger's
door locks or unlocks the passenger's
door only.
Be sure to hold the door handle up
when you close a locked front door, or
the door will not remain locked.
w ww w
w WARNING
Child-Proof Locks (if equipped)
As illustrated, a child-proof lock is provided
for both rear doors. When the lock lever is
down, position 1, the child proof lock is
activated, and when up, in position 2 the
child-proof lock is deactivated, when the
child-proof lock is activated, the rear door
cannot be opened from the inside even if
the inside door lock is unlocked but can be
opened from the outside.
Be sure to place the child-proof lock
in the locked position whenever
children are seated in the rear.
Rearend Door Lock
To unlock the door, insert the key into the
lock knob and turn it clockwise.
76G-03-008 76G-03-009
TYPE-1 (ALTO) EXAMPLE
3-5BEFORE DRIVING

Downloaded from www.Manualslib.com manuals search engine 1976G-74E
BEFORE DRIVING
3-6
w ww w
w WARNING
76G-03-009A
Always make sure that the rearend
door is closed and latched securely.
Closing the door completely helps to
prevent exhaust gases from entering
the vehicle. Completely closing the
rearend door also helps prevent
occupants from being thrown from the
vehicle in the event of an accident.TYPE-2 (ALTO K10)
WINDOWSRaise or lower the door windows by turning
the handle located on the door panel.
76G-03-011
Electric window controls (if equipped)
The driver’s door has switches 1 & 2 to
operate the driver’s window and front
passenger’s window respectively.
The passenger’s door only has a switch 3
to operate the passenger’s window. The
electric windows can only be operated when
the ignition switch is in the “ON” position.
To open a window with the driver's door
switches, push the top part of the switch
and to close the window lift up the top part
of the switch.
76G-03-012

Downloaded from www.Manualslib.com manuals search engine 20
76G-74E
The driver’s window has an “auto-down”
feature for added convenience (at toll
booths or drive-through restaurants, for
example). This means you can open the
window without holding the window switch
in the “Down” position. Press the driver’s
window switch completely down and release
it. To stop the window before it reaches the
bottom, lift up the switch briefly.
To open or to close a window with the
passenger's door switch, push the top part
of the switch or lift up the top part of the
switch respectively.
76G-03-013
3-7BEFORE DRIVING
The driver’s door also has a lock switch for
the passenger’s window. When you push in
the lock switch, the passenger’s window
can not be raised or lowered by operating
either of the switches 2 or 3. To restore
normal operation, push the switch again.
76G-03-014
w ww w
w WARNING
You should always push in the lock
switch when there are children in the
vehicle. Children can be seriously
injured if they get part of their body
caught by the window during
operation.
Since the electric windows consumes
a large amount of electricity, the same
should not be used excessively with
engine in “OFF” condition.
CAUTION

Downloaded from www.Manualslib.com manuals search engine 2176G-74E
BEFORE DRIVING
3-8
MIRRORSInside Rearview Mirror
To adjust the inside rearview mirror, move
the mirror up, down, or sideways to obtain
the best view.
76G-03-015
Outside Rearview Mirrors
Adjust the outside rearview mirrors (with the
help of control lever, if equipped), so that
you can just see the side of your vehicle
in the mirrors.
Be careful when judging the size or
distance of a vehicle or other object
seen in the side convex mirror (if
equipped). Be aware that objects look
smaller and appear farther away than
when seen in a flat mirror.
w ww w
w WARNING
76G-03-017
76G-03-017A
TYPE-1 (ALTO)
TYPE-2 (ALTO K10)

Downloaded from www.Manualslib.com manuals search engine 22
76G-74E
3-9BEFORE DRIVINGFRONT SEAT ADJUSTMENT
76G-03-018
TYPE-1 (ALTO)
76G-03-018A
TYPE-2 (ALTO K10)
ADJUSTING SEAT POSITION
76G-03-019A76G-03-019B
TYPE-1 (ALTO)TYPE-2 (ALTO K10) Never attempt to adjust the driver’s
seat or seatback while driving. The
seat or seatback could move
unexpectedly, causing loss of control.
Make sure that the driver’s seat and
seatback are properly adjusted before
you start driving.
w ww w
w WARNING

Downloaded from www.Manualslib.com manuals search engine 2376G-74E
BEFORE DRIVING
3-10
The adjustment lever for each front seat is
located under the front of the seat. To
adjust the seat position, pull up on the
adjustment lever and slide the seat forward
or rearward. After adjustment, try to move
the seat forward and rearward to ensure
that it is securely latched.
w ww w
w WARNING
To avoid excessive seat belt slack,
which reduces the effectiveness of the
seat belts as a safety device, make
sure that the seats are adjusted
before the seat belts are fastened.
Seatbacks should always be in an
upright position when driving, or seat
belt effectiveness may be reduced.
Seat belts are designed to offer
maximum protection when seatbacks
are in the fully upright position.
Front Seats
The seatbacks can be adjusted to different
angles. To adjust the seatback angle, pull
up the lever on the outboard side of the
seat, move the seatback to the desired
position, and release the lever to lock the
seatback in place.
w ww w
w WARNING
76G-03-022
76G-03-023
TYPE-1 (ALTO)
TYPE-2 (ALTO K10)ADJUSTING SEATBACKS

Downloaded from www.Manualslib.com manuals search engine 24
76G-74E
BEFORE DRIVING3-11Seat belts are good help to protect
occupants from injury or death in the
event of accidents. We urge you to
wear seat belts at all times if the belts
are equipped. If seat belts are not
equipped at the rear seating positions,
we recommend you to install optional
or after market high quality seat belts
to increase occupant's safety.SEAT BELTS
w ww w
w WARNING
76G-03-026
Never allow persons to ride in the
cargo area of a vehicle. In the event
of an accident, there is a much
greater risk of injury for persons
who are not riding in a seat with
their seat belt securely fastened.
Seat belts should always be
adjusted so the lap portion of the
belt is worn low across the pelvis,
not across the waist. Shoulder
straps should be worn on the
outside shoulder only, and never
under the arm. Seat belts should
never be worn with the straps
twisted and should be adjusted as
w ww w
w WARNING
V VV V
V
76G-03-027
tightly as is comfortable to provide
the protection for which they have
been designed. A slack belt will
provide less protection than one
which is snug.
Make sure that each seat belt buckle
is inserted into the proper buckle
catch.
Do not wear your seat belt over
hard or breakable objects in your
pockets or on your clothing. If an
accident occurs, objects such as
glasses, pens, etc. under the seat
belt can cause injury.
w ww w
w WARNING
V VV V
V
V VV V
V
76G-03-028

Downloaded from www.Manualslib.com manuals search engine 2576G-74E
BEFORE DRIVING
3-12
Never use the same seat belt on
more than one occupant and never
attach a seat belt over an infant or
child being held on an occupant’s
lap. Such seat belt use could cause
serious injury in the event of an
accident.
Pregnant women should use seat
belts, although specific recommen-
dations about restraint use should
be made by the woman’s medical
advisor. Remember that the lap
portion of the belt should be worn
as low as possible across the hips,
as shown in the diagram.
w ww w
w WARNING
V VV V
V
V VV V
V
76G-03-029
Periodically inspect seat belt
assemblies for excessive wear and
damage. Seat belts should be
replaced if webbing becomes frayed,
contaminated, or damaged in any
way. It is essential to replace the
entire seat belt assembly after it has
been stressed in an impact, even if
damage to the assembly is not
obvious.
Infants and small children should
never be transported unless they are
properly restrained. Restraint
systems for infants and small
children can be purchased locally
and should be used. Make sure that
the system you purchase meets
applicable safety standards. Read
and follow all the directions
provided by the manufacturer.
Avoid contamination of seat belt
webbing by polishes, oils,
chemicals, and particularly battery
acid. Cleaning may safely be carried
out using mild soap and water.
For children, if the shoulder belt
irritates the neck or face, move the
child closer to the center of the
vehicle.
w ww w
w WARNING
V VV V
V
V VV V
V
Be sure to inspect all seat belt
assemblies after any collision. Any
seat belt assembly which was in use
during a collision (other than a very
minor one) should be replaced, even
if damage to the assembly is not
obvious. Any seat belt assembly
which was not in use during a
collision should be replaced if it does
not function properly or is damaged
in any way.
w ww w
w WARNING
V VV V
V
