13-8 Consumer information and Reporting safety defects
„Vehicle load limit – how to de-
termine
The load capacity of your vehicle is
determined by weight, not by avail-
able cargo space. The load limit of
your vehicle is shown on the vehicle
placard attached to the driver’s side
B-pillar. Locate the statement “The
combined weight of occupants and
cargo should never exceed XXX kg or
XXX lbs” on your vehicle’s placard.
The vehicle placard also shows seat-
ing capacity of your vehicle.
The total load capacity includes the
total weight of driver and all passen-
gers and their belongings, any cargo,
any optional equipment such as a
trailer hitch, roof rack or bike carrier,
etc., and the tongue load of a trailer.
Therefore cargo capacity can be cal-
culated by the following method.
Cargo capacity = Load limit – (total
weight of occupants + total weight of
optional equipment + tongue load of a
trailer (if applicable))
For towing capacity information and
weight limits, refer to “Trailer towing”
in Chapter 8. T
Calculating total and load capac-
ities varying seating configura- tions
Calculate the available load capacity
as shown in the following examples:
Example 1A
Vehicle capacity weight of the vehicle
is 900 lbs (408 kg), which is indicated
on the vehicle placard with the state-
ment “The combined weight of occu-
pants and cargo should never exceed
900 lbs or 408 kg”.
For example, if the vehicle has one
occupant weighing 154 lbs (70 kg)
plus cargo weighing 662 lbs (300 kg). 1. Calculate the total weight.
2. Calculate the available load capac-
ity by subtracting the total weight from
the vehicle capacity weight of 900 lbs
(408 kg).
3. The result of step 2 shows that a
further 84 lbs (38 kg) of cargo can be
carried.
D00106
Total weight = 154 lbs (70 kg) + 662 lbs (300 kg) =
816 lbs (370 kg)(Occupant) (Cargo)

Consumer information and Reporting safety defects 13-11
suspension, axles and other parts of
the body.
Therefore, this means that the vehicle
cannot necessarily be loaded up to
the tire’s maximum load rating on the
tire sidewall. „Adverse safety consequenc-
es of overloading on handling
and stopping and on tires
Overloading could affect vehicle han-
dling, stopping distance, vehicle and
tire as shown in the following. This
could lead to an accident and possibly
result in severe personal injury. y Vehicle stability will deteriorate.
y Heavy and/or high-mounted loads
could increase the risk of rollover. y Stopping distance will increase.
y Brakes could overheat and fail.
y Suspension, bearings, axles and
other parts of the body could break or
experience accelerated wear that will
shorten vehicle life. y Tires could fail.
y Tread separation could occur.
y Tire could separate from its rim. „
Steps for Determining Cor-
rect Load Limit
1. Locate the statement “The com-
bined weight of occupants and cargo
should never exceed XXX pounds” on
your vehicle’s placard.
2. Determine the combined weight of
the driver and passengers that will be
riding in your vehicle.
3. Subtract the combined weight of
the driver and passengers from XXX
kilograms or XXX pounds.
4. The resulting figure equals the
available amount of cargo and lug-
gage load capacity. For example, if
the “XXX” amount equals 1,400 lbs
(635kg). and there will be five- 150 lbs
(68 kg) passengers in your vehicle,
the amount of available cargo and
luggage load capacity is 650 lbs.
(1,400 – 750 (5 u 150) = 650 lbs)
5. Determine the combined weight of
luggage and cargo being loaded on
the vehicle. That weight may not safe-
ly exceed the available cargo and lug-
gage load capacity calculated in Step4.
6. If your vehicle will be towing a trail-
er, load from your trailer will be trans- ferred to your vehicle. Consult this
manual to determine how this reduc-
es the available cargo and luggage
load capacity of your vehicle.

14-6 Index
ReplacingAir cleaner element .................................................... 11-15
Battery (remote keyless entry) ....................................... 2-8
Bulbs ......................................................................... 11-44
Transmitters ................................................................... 2-9
Rocking the vehicle .......................................................... 8-11
Roof rail and crossbar ...................................................... 8-13 S
Safety
Precautions when driving .................................................. 4
Symbol .............................................................................. 2
Warnings ........................................................................... 2
Seat height adjustment (drivers seat) ................................. 1-4
Seatbelt .................................................................................. 4
Extender ...................................................................... 1-20
Maintenance ................................................................ 1-19
Pretensioners .............................................................. 1-21
Safety tips .................................................................... 1-10
Warning light and chime ....................................... 1-12, 3-9
Seatbelts .......................................................................... 1-10
Seats Fabric .......................................................................... 10-4
Heater ............................................................................ 1-7
Selector lever (AT vehicles) ............................................. 7-11
Self-leveling rear suspension ........................................... 7-25
Shift lock release .............................................................. 7-14
Shift position indicator ...................................................... 3-15
Shopping bag hook .......................................................... 6-14
Snow tires ........................................................................ 8-10
Snowy and icy roads .......................................................... 8-9
Spark plugs .................................................................... 11-17 Specifications ................................................................... 12-2
Speedometer ...................................................................... 3-6 SRS
Airbag system warning light ......................................... 3-10
Frontal airbag ............................................................... 1-40
Side airbag ................................................................... 1-52
SRS airbag (Supplemental Restraint System airbag) ... 4, 1-36
Steering wheel Power ........................................................................... 7-15
Tilt wheel ...................................................................... 3-28
Storage compartments ....................................................... 6-4
Sun visors ........................................................................... 6-3
Supplemental Restraint System airbag ............................ 1-36
Synthetic leather upholstery ............................................. 10-5 T
Tachometer ........................................................................ 3-7
Temperature gauge ............................................................ 3-8
Temperature warning (AT OIL TEMP) .............................. 3-12
Tie-down hooks ................................................................ 9-11
Tilt steering wheel ............................................................. 3-28
Tire Chains .......................................................................... 8-10
Inspection .................................................................. 11-30
Pressures and wear ................................................... 11-31
Replacement .............................................................. 11-34
Rotation ..................................................................... 11-34
Types ......................................................................... 11-30
Top tether anchorages ..................................................... 1-34
Towing .............................................................................. 9-10
All wheels on the ground ............................................. 9-12
Flat-bed truck ............................................................... 9-12

Index 14-7
TrailerConnecting .................................................................. 8-16
Hitch ................................................................... 8-16, 8-21
Towing ......................................................................... 8-18
Towing tips .................................................................. 8-23
Turn signal indicator lights ................................................ 3-15
Turn signal lever ............................................................... 3-19 U
Under-floor storage compartment ..................................... 6-15 V
Valet mode ....................................................................... 2-15
Vanity mirror ....................................................................... 6-3
Vehicle Capacity weight ........................................................... 8-12
Identification .............................................................. 12-10
Symbols ............................................................................ 3
Ventilator ............................................................................ 4-2 W
Warning and indicator lights ............................................... 3-9
Warning lights
ABS ............................................................................. 3-13
All-Wheel Drive ............................................................ 3-15
Anti-lock Brake system ................................................ 3-13
AT OIL TEMPerature ................................................... 3-12
Brake system ............................................................... 3-13
Charge ......................................................................... 3-12
CHECK ENGINE ......................................................... 3-11
Door open .................................................................... 3-14 Low fuel ........................................................................ 3-14
Oil pressure .................................................................. 3-12
Seatbelt ................................................................. 1-12, 3-9
SRS airbag system ...................................................... 3-10
Warranties and maintenance ............................................ 8-18
Washing ............................................................................ 10-2
Waxing and polishing ........................................................ 10-3
Wear indicators ............................................................... 11-33
Wheel Alignment ..................................................................... 12-5
Aluminum ................................................................... 11-35
Balance ...................................................................... 11-32
Replacement .............................................................. 11-35
Windows ........................................................................... 2-18
Windshield Washer fluid ............................................................... 11-35
Wiper and washer switches ......................................... 3-22
Wiper deicer ................................................................. 3-24
Windshield wiper blades
Replacement .............................................................. 11-37
Winter driving ...................................................................... 8-7
Wiper and washer ............................................................. 3-21

GAS STATION REFERENCE
Fuel: TNon-turbo models
Use only unleaded gasoline with an octane rating of 87 AKI or
higher. T Turbo models
Use premium unleaded gasoline with an octane rating of 91 AKI or
higher. If premium unleaded gasoline is not available, regular un-
leaded gasoline with octane rating of 87 AKI or higher may be tem-
porarily used. For optimum engine performance and driveability, it
is required that you use premium grade unleaded gasoline. „ Fuel octane rating
This octane rating is the average of the Research Octane and Mo-
tor numbers and is commonly referred to as the Anti Knock Index (AKI). Refer to “Fuel” section in this manual.
Fuel capacity:
15.9 US gal (60 liters, 13.2 Imp gal) Engine oil:
Use only API classification SM with the words “ENERGY CON-
SERVING” and the ILSAC certification mark (starburst mark) dis-
played on the container (ILSAC GF-4).
Engine oil capacity:
4.2 US qt (4.0 liters, 3.5 Imp qt)
Cold tire pressure:
NOTE
For the Canada specification non-turbo models, there is a c onventional tire installed under the floor of the cargo area.
Tire sizeP215/60R16 94HP215/55R17 93H
Wheel size16u 6 1
/2 JJ or 16
u 6 1
/2 J17
u 7 JJ
PressureFrontLight load29 psi (200 kPa, 2.0 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
Full load29 psi (200 kPa, 2.0 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
RearLight load28 psi (190 kPa, 1.9 kgf/cm 2
)30 psi (210 kPa, 2.1 kgf/cm 2
)
Full load36 psi (250 kPa, 2.5 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
Trailer towing41 psi (280 kPa, 2.8 kgf/cm 2
)36 psi (250 kPa, 2.5 kgf/cm 2
)
Temporary spare tireSizeT135/80D16
Pressure60 psi (420 kPa, 4.2 kgf/cm 2
)
