As an example, if you initially perform the
lubrication procedure and tow your vehicle for
three hours, then park for four hours, the
lubrication procedure will need to be performed
again, prior to dinghy towing the vehicle.
Notice:Towing your vehicle after shifting the
automatic transaxle (four-speed or ve-speed)
from anything other than DRIVE (D) to
NEUTRAL (N) can cause internal damage to
the automatic transaxle. Always shift the
automatic transaxle (four-speed or ve-speed)
from DRIVE (D) to NEUTRAL (N) as the last
shift before towing.
5. Locate and remove the large IGN fuse from
the underhood fuse block. SeeUnderhood
Fuse Block on page 411.
Notice:If you tow your vehicle without
performing each of the steps listed under
“Dinghy Towing,” you could damage the
automatic transmission. Be sure to follow all
steps of the dinghy towing procedure prior
to and after towing your vehicle.Notice:If your vehicle has a four-speed
automatic transmission, it can be dinghy towed
from the front for unlimited miles at 65 mph
(105 km/h). If you exceed 65 mph (105 km/h)
while towing your vehicle, it could be damaged.
The repairs would not be covered by your
warranty. Never exceed 65 mph (105 km/h)
while towing your vehicle.
Notice:If your vehicle has a ve-speed
automatic transmission and it is towed for
more than seven hours without performing
lubrication process or at speeds greater than
65 mph (105 km/h), you could damage the
automatic transmission. The repairs would
not be covered by your warranty. Do not tow
your vehicle for extended periods of time or at
speeds greater than 65 mph (105 km/h).
After seven hours, repeat Step 4 above for the
ve-speed automatic transmission.
287
ProCarManuals.com

Once you have reached your destination, do the
following:
1. Set the parking brake.
2. Shift the transmission to REVERSE (R) for a
manual transmission. Shift the transmission to
PARK (P) for an automatic transmission.
3. Turn the ignition key to LOCK and remove the
key from the ignition.
4. Reinstall the large IGN fuse.
Notice:Too much or too little uid can
damage the transmission. Be sure that the
transaxle uid is at the proper level before
towing with all four wheels on the ground.
Notice:Don’t tow a vehicle with the front drive
wheels on the ground if one of the front tires
is a compact spare tire. Towing with two
different tire sizes on the front of the vehicle
can cause severe damage to the transmission.Dolly Towing (All-Wheel-Drive Vehicles)
All-wheel-drive vehicles should not be towed with
two wheels on the ground. To properly tow
these vehicles, they should be placed on a
platform trailer with all four wheels off of the
ground or dinghy towed from the front.
Dolly Towing
(Front-Wheel-Drive Vehicles)
288
ProCarManuals.com

Trailer Wiring
Additional wire length has been provided for
connecting trailer wiring to your vehicle. A loop of
ve wires is stored below the jack, which is located
on the driver’s side of the cargo area. The wires are
fused in both the underhood and instrument fuse
block. SeeInstrument Panel Fuse Block on
page 410andUnderhood Fuse Block on page 411.The wires do not have a connector and should be
wired to the trailer by a qualied electrical
technician. The technician can use the following
information when connecting a trailer wiring
harness to your vehicle.
Yellow: Left Turn Signal
Brown: Parking Lamps
Light Blue: Stop Lamps
Black: Ground Wire
Dark Green: Right Turn Signal
When connecting a trailer harness, be sure you
leave it loose enough so the wiring does not bend
or break, but not so loose that it drags on the
ground. Store harness below jack in the cargo area
when it is not in use. Wrap the harness together
and tie it neatly so it will not be damaged.
300
ProCarManuals.com

Electrical System........................................ 409
Add-On Electrical Equipment..................... 409
Windshield Wiper Fuses............................ 409
Power Windows and Other Power
Options.................................................. 409Fuses and Circuit Breakers....................... 409
Instrument Panel Fuse Block..................... 410
Underhood Fuse Block.............................. 411
Capacities and Specications.................... 414
Section 5 Service and Appearance Care
303
ProCarManuals.com

California Proposition 65 Warning
Most motor vehicles, including this one,
contain and/or emit chemicals known to
the State of California to cause cancer
and birth defects or other reproductive harm.
Engine exhaust, many parts and systems
(including some inside the vehicle), many uids,
and some component wear by-products
contain and/or emit these chemicals.
Doing Your Own Service Work
{CAUTION:
You can be injured and your vehicle could
be damaged if you try to do service work
on a vehicle without knowing enough
about it.
Be sure you have sufficient knowledge,
experience, the proper replacement
parts, and tools before you attempt any
vehicle maintenance task.
Be sure to use the proper nuts, bolts,
and other fasteners. English and metric
fasteners can be easily confused. If you
use the wrong fasteners, parts can later
break or fall off. You could be hurt.
If you want to do some of your own service work,
you should use the proper service manual. It
tells you much more about how to service your
vehicle than this manual can. To order the proper
service manual, seeService Publications
Ordering Information on page 453.
305
ProCarManuals.com

A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 324.
B. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 318.
C. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 318.
D. Remote Negative (−) Terminal. SeeJump
Starting on page 348.
E. Brake/Clutch Cylinder Fluid. SeeBrakes on
page 343andHydraulic Clutch on page 331.F. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 411.
G. Battery. SeeBattery on page 347.
H. Remote Positive (+) Terminal. SeeJump
Starting on page 348.
I. Engine Coolant Surge Tank. See “Checking
Coolant” underEngine Coolant on page 331.
J. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 341.
315
ProCarManuals.com

A. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 324.
B. Engine Oil Dipstick (Out of View). See
“Checking Engine Oil” underEngine Oil on
page 318.
C. Engine Oil Fill Cap (Out of View). See “When
to Add Engine Oil” underEngine Oil on
page 318.
D. Remote Negative (−) Terminal. SeeJump
Starting on page 348.
E. Brake Fluid Reservoir. SeeBrakes on
page 343.F. Battery. SeeBattery on page 347.
G. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 411.
H. Remote Positive (+) Terminal (Out of View).
SeeJump Starting on page 348.
I. Engine Coolant Surge Tank. See “Checking
Coolant” underEngine Coolant on page 331.
J. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 341.
317
ProCarManuals.com

Notice:If you leave your radio or other
accessories on during the jump starting
procedure, they could be damaged. The repairs
would not be covered by your warranty.
Always turn off your radio and other
accessories when jump starting your vehicle.
3. Turn off the ignition on both vehicles.
Unplug unnecessary accessories plugged into
the cigarette lighter or the accessory power
outlet. Turn off the radio and all lamps that are
not needed. This will avoid sparks and help
save both batteries. And it could save
the radio!
4. Open the hood on the other vehicle and
locate the positive (+) and negative (−)
terminal locations on that vehicle.
Open the hood on your vehicle and nd the
remote positive (+) and remote negative (−)
jump starting terminals.A. Remote Positive
B. Remote Negative
Vehicles equipped with the 2.2L L4 engine,
the remote positive (+) terminal is located
in the engine compartment on the driver’s side
of the vehicle, on the underhood fuse block.
SeeEngine Compartment Overview on
page 314for more information on location.
Access the remote positive (+) terminal
by removing the fuse block cover.
The remote negative (−) terminal is the lift
hook, which is located towards the rear of the
engine on the driver’s side.
2.2L L4 Engine
