Tire and Loading Information Label
A vehicle speci c Tire and Loading Information
label is attached to the center pillar (B-pillar) of your
vehicle. With the driver’s door open, you will nd the
label attached below the door lock post (striker).
The tire and loading information label shows the
number of occupant seating positions (A), and the
maximum vehicle capacity weight (B) in kilograms
and pounds.The Tire and Loading Information label also shows
the size of the original equipment tires (C) and
the recommended cold tire in ation pressures (D).
For more information on tires and in ation see
Tires on page 462andIn ation - Tire Pressure
on page 469.
There is also important loading information on the
vehicle Certi cation/Tire label. It tells you the
Gross Vehicle Weight Rating (GVWR) and
the Gross Axle Weight Rating (GAWR) for the
front and rear axle. See “Certi cation/Tire Label”
later in this section.
Steps for Determining Correct Load Limit
1. Locate the statement “The combined
weight of occupants and cargo should never
exceed XXX kg or XXX lbs” on your
vehicle’s placard.
2. Determine the combined weight of the driver
and passengers that will be riding in your
vehicle.
3. Subtract the combined weight of the driver
and passengers from XXX kg or XXX lbs.Example Label
392
ProCarManuals.com
Page 410 of 570
Tires............................................................ 462
Tire Sidewall Labeling............................... 463
Tire Terminology and De nitions............... 466
In ation - Tire Pressure............................. 469
High-Speed Operation............................... 471
Tire Inspection and Rotation...................... 472
When It Is Time for New Tires.................. 473
Buying New Tires...................................... 474
Different Size Tires and Wheels................ 476
Uniform Tire Quality Grading..................... 477
Wheel Alignment and Tire Balance............ 478
Wheel Replacement.................................. 478
Tire Chains............................................... 480
Accessory In ator...................................... 480
If a Tire Goes Flat.................................... 483
Changing a Flat Tire................................. 484
Removing the Spare Tire and Tools.......... 485
Removing the Flat Tire and Installing
the Spare Tire....................................... 488
Secondary Latch System........................... 495
Storing a Flat or Spare Tire and Tools...... 497
Compact Spare Tire.................................. 500Appearance Care........................................ 501
Cleaning the Inside of Your Vehicle.......... 501
Fabric/Carpet............................................. 502
Leather...................................................... 503
Instrument Panel, Vinyl, and Other
Plastic Surfaces..................................... 504
Care of Safety Belts.................................. 504
Weatherstrips............................................ 504
Washing Your Vehicle............................... 505
Cleaning Exterior Lamps/Lenses................ 505
Finish Care............................................... 505
Windshield, Backglass, and
Wiper Blades......................................... 506
Aluminum Wheels...................................... 507
Tires......................................................... 507
Sheet Metal Damage................................. 508
Finish Damage.......................................... 508
Underbody Maintenance............................ 508
Chemical Paint Spotting............................ 508
Vehicle Care/Appearance Materials............ 509
Section 5 Service and Appearance Care
410
ProCarManuals.com
Page 463 of 570
Tire Sidewall Labeling
Useful information about a tire is molded into its
sidewall. The examples below show a typical
passenger vehicle tire and a compact spare tire
sidewall.(A) Tire Size:The tire size is a combination of
letters and numbers used to de ne a particular
tire’s width, height, aspect ratio, construction type,
and service description. See the “Tire Size”
illustration later in this section for more detail.
(B) TPC Spec (Tire Performance Criteria
Speci cation):Original equipment tires designed
to GM’s speci c tire performance criteria have
a TPC speci cation code molded onto the sidewall.
GM’s TPC speci cations meet or exceed all
federal safety guidelines.
(C) DOT (Department of Transportation):
The Department of Transportation (DOT) code
indicates that the tire is in compliance with the
U.S. Department of Transportation Motor Vehicle
Safety Standards.
(D) Tire Identi cation Number (TIN):The letters
and numbers following DOT (Department of
Transportation) code is the Tire Identi cation
Number (TIN). The TIN shows the manufacturer
and plant code, tire size, and date the tire
was manufactured. The TIN is molded onto both
sides of the tire, although only one side may have
the date of manufacture.
Passenger (P-Metric) Tire Example
463
ProCarManuals.com
Page 465 of 570
(B) Tire Ply Material:The type of cord and
number of plies in the sidewall and under the
tread.
(C) Tire Identi cation Number (TIN):The letters
and numbers following the DOT (Department of
Transportation) code is the Tire Identi cation
Number (TIN). The TIN shows the manufacturer
and plant code, tire size, and date the tire
was manufactured. The TIN is molded onto both
sides of the tire, although only one side may
have the date of manufacture.
(D) Maximum Cold In ation Load Limit:
Maximum load that can be carried and the
maximum pressure needed to support that load.
(E) Tire In ation:The temporary use tire
or compact spare tire should be in ated to
60 psi (420 kPa). For more information on tire
pressure and in ation seeIn ation - Tire Pressure
on page 469.
(F) Tire Size:A combination of letters and
numbers de ne a tire’s width, height, aspect
ratio, construction type, and service description.
The letter T as the rst character in the tire
size means the tire is for temporary use only.(G) TPC Spec (Tire Performance Criteria
Speci cation):Original equipment tires designed
to GM’s speci c tire performance criteria have
a TPC speci cation code molded onto the sidewall.
GM’s TPC speci cations meet or exceed all
federal safety guidelines.
Tire Size
The following illustration shows an example of a
typical passenger vehicle tire size.
(A) Passenger (P-Metric) Tire:The United
States version of a metric tire sizing system.
The letter P as the rst character in the tire size
means a passenger vehicle tire engineered
to standards set by the U.S. Tire and Rim
Association.
465
ProCarManuals.com
Page 466 of 570
(B) Tire Width:The three-digit number indicates
the tire section width in millimeters from sidewall
to sidewall.
(C) Aspect Ratio:A two-digit number that
indicates the tire height-to-width measurements.
For example, if the tire size aspect ratio is
60, as shown in item C of the illustration, it would
mean that the tire’s sidewall is 60 percent as
high as it is wide.
(D) Construction Code:A letter code is used
to indicate the type of ply construction in the tire.
The letter R means radial ply construction; the
letter D means diagonal or bias ply construction;
and the letter B means belted-bias ply
construction.
(E) Rim Diameter:Diameter of the wheel in
inches.
(F) Service Description:These characters
represent the load range and speed rating of the
tire. The load index represents the load carry
capacity a tire is certi ed to carry. The load index
can range from 1 to 279. The speed rating is
the maximum speed a tire is certi ed to carry
a load. Speed ratings range from A to Z.Tire Terminology and De nitions
Air Pressure:The amount of air inside the tire
pressing outward on each square inch of the
tire. Air pressure is expressed in pounds
per square inch (psi) or kilopascal (kPa).
Accessory Weight:This means the combined
weight of optional accessories. Some examples of
optional accessories are, automatic transmission/
transaxle, power steering, power brakes, power
windows, power seats, and air conditioning.
Aspect Ratio:The relationship of a tire’s height
to its width.
Belt:A rubber coated layer of cords that is
located between the plies and the tread. Cords
may be made from steel or other reinforcing
materials.
Bead:The tire bead contains steel wires wrapped
by steel cords that hold the tire onto the rim.
Bias Ply Tire:A pneumatic tire in which the plies
are laid at alternate angles less than 90 degrees
to the centerline of the tread.
466
ProCarManuals.com
Page 469 of 570
UTQGS (Uniform Tire Quality Grading
Standards):A tire information system that
provides consumers with ratings for a tire’s
traction, temperature, and treadwear. Ratings
are determined by tire manufacturers using
government testing procedures. The ratings
are molded into the sidewall of the tire. See
Uniform Tire Quality Grading on page 477.
Vehicle Capacity Weight:The number of
designated seating positions multiplied by
150 lbs (68 kg) plus the rated cargo load.
SeeLoading Your Vehicle on page 391.
Vehicle Maximum Load on the Tire:Load on
an individual tire due to curb weight, accessory
weight, occupant weight, and cargo weight.
Vehicle Placard:A label permanently attached
to a vehicle showing the vehicle’s capacity
weight and the original equipment tire size and
recommended in ation pressure. See “Tire
and Loading Information Label” underLoading
Your Vehicle on page 391.In ation - Tire Pressure
Tires need the correct amount of air pressure to
operate effectively.
Notice:Do not let anyone tell you that
under-in ation or over-in ation is all right.
It is not. If your tires do not have enough air
(under-in ation), you can get the following:
Too much exing
Too much heat
Tire overloading
Premature or irregular wear
Poor handling
Reduced fuel economy
If your tires have too much air (over-in ation),
you can get the following:
Unusual wear
Poor handling
Rough ride
Needless damage from road hazards
469
ProCarManuals.com
Page 471 of 570
High-Speed Operation
{CAUTION:
Driving at high speeds, 100 mph (160 km/h)
or higher, puts an additional strain on tires.
Sustained high-speed driving causes
excessive heat build up and can cause
sudden tire failure. You could have a
crash and you or others could be killed.
Some high-speed rated tires require
in ation pressure adjustment for high
speed operation. When speed limits and
road conditions are such that a vehicle
can be driven at high speeds, make sure
the tires are rated for high speed operation,
in excellent condition, and set to the
correct cold tire in ation pressure for the
vehicle load.If your vehicle has P225/60R17 size tires,
they will require in ation pressure adjustment
when driving your vehicle at speeds of
100 mph (160 km/h) or higher. Set the cold
in ation pressure to the maximum in ation
pressure shown on the tire sidewall, or
38 psi (262 kPa), whichever is lower. See the
example following. When you end this high-speed
driving, return the tires to the cold tire in ation
pressure shown on the Tire and Loading
Information label. SeeLoading Your Vehicle
on page 391andIn ation - Tire Pressure
on page 469.
Example:
You will nd the maximum load and in ation
pressure molded on the tire’s sidewall, in small
letters, near the rim ange. It will read something
like this: Maximum load 690 kg (1521 lbs)
300 kPa (44 psi) Max. Press.
For this example, you would set the
in ation pressure for high-speed driving at
38 psi (262 kPa).
471
ProCarManuals.com
Page 473 of 570
{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after a time. The wheel
could come off and cause an accident.
When you change a wheel, remove any
rust or dirt from places where the wheel
attaches to the vehicle. In an emergency,
you can use a cloth or a paper towel to
do this; but be sure to use a scraper or
wire brush later, if needed, to get all the
rust or dirt off. SeeChanging a Flat Tire
on page 484.
When It Is Time for New Tires
One way to tell when it
is time for new tires is
to check the treadwear
indicators, which will
appear when your tires
have only 1/16 inch
(1.6 mm) or less of tread
remaining.
You need a new tire if any of the following
statements are true:
You can see the indicators at three or more
places around the tire.
You can see cord or fabric showing through
the tire’s rubber.
The tread or sidewall is cracked, cut, or
snagged deep enough to show cord or fabric.
The tire has a bump, bulge, or split.
The tire has a puncture, cut, or other damage
that cannot be repaired well because of the
size or location of the damage.
473
ProCarManuals.com
