2007 SAAB 9-5 tailgate

4Exterior
IB3831
Driving with a roof rack load______ 179
Fitting the roof carriers3________ 179
Maximum roof load ____________ 258
Rearview mirror _______________ 118
Hood _______________________ 190
Engine compartment: washing ___ 242
Central locking __________ 44
Trunk lid lock, 9-5 Sedan __ 47
Tailgate, 9-5 SportCombi __ 48
Child safety locks ________ 47
Car alarm3____________ 50Headlights _____________ 73
High/low beam __________ 73
Turn signal and lane change
indicators______________ 75
Headlight washers3_____ 77
Changing bulbs _________ 204
Fuel gauge___________________ 65
Refueling ____________________ 146
Economical motoring ___________ 170
Fuel ________________________ 260
b Tires pressure ________________ 267
Wheels and tires ______________ 266
Braking______________________ 160
Driving in cold weather__________ 172
Compact spare tire_____________ 234
Changing a wheel _____________ 236
Trunk _______________________ 129
Folding the rear seat, 9-5 Sedan __ 129
Folding the rear seat,
9-5 SportCombi ______________ 132
Trunk Release Handle __________ 138
Driving with a spare wheel fitted __ 183
Compact spare tire ____________ 234Towing a trailer3________ 174
Towing the car ___________ 183
Rear towing eye _________ 184Headlights ______________ 73
Rear light cluster, 9-5 Sedan 208
Rear lights clusters,
9-5 SportCombi _________ 210
Changing bulbs __________ 204Moonroof3_____________ 123
Washing the car _________ 241
Waxing and polishing _____ 242
Touching up the paint _____ 242
Anti-corrosion treatment ___ 24595_U S _M 07.book Page 4 Friday, June 9, 2006 8:58 AM
ProCarManuals.com

9
No sparks, fla-
mes or smo-
king.Buckle up
Use protective
gogglesAirbag
Keep out of
reach of
children.Never place a
rear-facing
child seat in
this seat.
Battery acid
contains
sulfuric acid.Electric
windows
Refer to the
Owner’s
Manual.Deactivating
of rear window
switches
Risk of
explosive gas.Central
locking, lock
.Central
locking,
unlock
Tr u n k
lid/tailgate,
opening
HeadlightsWindshield
wipers
Direction
indicatorsWindshield
washers
Parking lights Defroster
Hazard
warning lightsRear window
heating
Front fog
lightsVentilation fan
Rear fog
light
Coolant
temperatureRadiator fan
Battery
chargingFuel
Foot brake
Coolant level
Engine oil
pressure
ABS brakes
Examples of symbols that can be found in your car95_U S _M 07.book Page 9 Friday, June 9, 2006 8:58 AM
ProCarManuals.com

45 Security
Locking/unlocking the carWhen the car is locked and unlocked the
theft alarm is also affected.
Remote locking
Press once on the control: all doors
locked.
The hazard warning lights will flash once.
The trunk/tailgate release switch on the
driver´s door will not work when all doors are
locked.
It is now not possible to unlock the doors
from within using the button on the
center console.
Remote unlocking
Press once on the control: the driver´s
door is unlocked. Press a second time to
unlock the rest of the doors but not the
trunk/tailgate.
The hazard warning lights will flash twice.The central locking can also be operated
from inside the car by means of the
switch on the center console.
This switch is inoperative when the car is
locked from the outside using the remote
control.
The interior locking buttons on each door
affect only the respective door.
If the car is left with the doors open, the inte-
rior lighting and the courtesy lights in the
doors will be switched off automatically after
20 minutes, to prevent a drain on the bat-
tery. In such cases the electrically operated
seats will not function.
IB3153
3
2 1
Key / Remote control1To lock
2 To unlock
3 Opening the trunk (9-5 Sedan)
Unlocking the tailgate (9-5 SportCombi)
IB451
Switch for operation of central locking
95_U S _M 07.book Page 45 Friday, June 9, 2006 8:58 AM
ProCarManuals.com

46 Security
If remote unlocking should fail to work
Unlock the front door with the key. To
silence the alarm, insert the key into the igni-
tion switch and turn it to the ON position.
The car can now be started. Contact a work-
shop to have the system checked and
repaired. We recommend that you contact
an authorized Saab dealer.
Locking by key (1)
When the car is locked and unlocked the
theft alarm is also affected.
Turn the key clockwise: all doors locked.
The trunk/tailgate release/unlock switch on
the driver’s door will not work when all doors
are locked. Nor will the switch on the center
console.
Unlocking by key (2)
Turn the key counterclockwise once: the
driver´s door will unlock.
Turn the key counterclockwise twice: all
doors, but not tailgate, unlocked. Switch in
driver´s door and switch in center console
enabled.
WARNING
The remote control also works from inside
the car. Therefore, hold the key in such a
way that the buttons are not unintention-
ally pressed when the key is turned, or
inserted or removed from the ignition
switch.
Otherwise, the doors may be unintention-
ally locked or the tailgate unlocked. On
Sedan models, the trunk may even be
opened.
Having the doors locked when you are
driving will reduce the likelihood of:
Passengers, especially children,
opening doors and falling out of the
car.
Intruders entering the car when it is
moving slowly or at a standstill.
However, you must also remember that
locked doors can hamper rescuers in the
event of a crash.
IB1555
2
1
Locking/unlocking by key1To lock
2 To unlock
95_U S _M 07.book Page 46 Friday, June 9, 2006 8:58 AM
ProCarManuals.com

48 SecurityUnlocking
The trunk lid is slightly opened/unlocked
using:
The button on the key
The trunk lid switch on the inside of the
driver’s door (if the car is unlocked and at
a standstill)
Remote unlocking is confirmed by the direc-
tion indicators flashing three times.
The trunk lid switch on the driver’s door is
inoperative when the car is locked.
Locking
The trunk lid release is locked automatically
when closed.
Trunk Release HandleThere is a glow-in-the-dark trunk release
handle located inside the trunk on the latch.
This handle will glow following exposure to
light. Pull the release handle down to open
the trunk from the inside.
Tailgate, 9-5 SportCombiThe tailgate is not unlocked when the other
car doors are unlocked. The tailgate button
on the driver’s door is inoperative when the
car is locked from outside or moving at a
speed greater than 2.7 mph (4 km/h).
Unlocking
The tailgate is unlocked using:
The button on the key
The tailgate switch on the inside of the
driver’s door (if the car is unlocked and at
a standstill)
Unlocking is confirmed by the direction indi-
cators flashing three times.
NOTICEThe trunk release handle was not
designed to be used to tie down the trunk
lid or as a an anchor point when securing
items in the trunk. Improper use of the
trunk release could damage it.
IB1833
Trunk Release Handle
95_U S _M 07.book Page 48 Friday, June 9, 2006 8:58 AM
ProCarManuals.com

49 Security

Locking
The tailgate is locked using:
The button on the key
The button on the center console
The key in the driver’s door.
When vehicle speed exceeds 2.7 mph
(4 km/h).Electronic starting interlock
(immobilizer)Each time the key is removed from the igni-
tion, the electronic starting interlock is acti-
vated and the car is thus immobilized, see
also page 51.Reprogramming lock system
functionsCertain lock system functions can be repro-
grammed by your authorized Saab dealer;
see page 270.
Changing the key batteryWhen the battery voltage in the key falls
below a predetermined level the Saab Infor-
mation Display (SID) will issue the following
message:
”Remote control battery
low. Replace battery.”
Press the CLR button on the SID to
acknowledge this message. You must then
replace the battery without delay to avoid
malfunctions. The life of the battery is nor-
mally 4 years.Contact a Saab dealer to
have the battery replaced.
NOTICEUse the grab handle to assist in closing
the tailgate.
Avoid the following, due to the risk of lock
mechanism damage when the tailgate is
closed.
Never grasp the lock mechanism as
this can lock the mechanism.
Never close the lock mechanism
manually.
IB3160
Grab handle95_U S _M 07.book Page 49 Friday, June 9, 2006 8:58 AM
ProCarManuals.com

50 SecurityCar alarm The car alarm (anti-theft system) is acti-
vated/deactivated when the car is
locked/unlocked by the remote control or by
the key, see page 45.
The antenna for the alarm system is located
in the center console.
All the doors plus trunk lid/tailgate and hood
are monitored by microswitches.
Your Saab 9-5 is equipped with an Elec-
tronic starting interlock (immobilizer), see
page 51 for details. The car alarm is armed 10 seconds after the
car has been locked by the remote control.
During this ten-second delay period, the
doors, trunk lid/tailgate and hood may still
be opened without the alarm being trig-
gered.
The LED indicator on the instrument panel
fascia will be on continuously during this
period, at the end of which it will start to flash
(once every other second).
If a door or the trunk lid/tailgate or hood has
been left open when the car is locked, the
LED on the fascia will flash (three times per
second) for ten seconds to indicate this.
WARNING
Leaving children or pets unattended in a
locked car is dangerous. It is also danger-
ous to leave children in a vehicle with the
ignition key. A child or others could be
badly injured or even killed.
IB3153
3
2 1
Remote control 1 Activate/lock
2 Deactivate/unlock
3 Unlock trunk/tailgate
Unlocking the tailgate (9-5 SportCombi)
95_U S _M 07.book Page 50 Friday, June 9, 2006 8:58 AM
ProCarManuals.com

51 Security
Check to ensure that all the doors, plus
trunk lid/tailgate and hood, are closed prop-
erly.
If the fault persists (LED flashing when
another attempt is made to activate the car
alarm by remote control), lock the car using
the key instead. The car alarm will not have
been activated and you should contact an
authorized Saab dealer.
To avoid inconvenience caused by the
alarm being triggered inadvertently, make
sure that anyone else using the car is famil-
iar with how both the car alarm and the lock-
ing system work.
If the alarm is tripped (the direction indica-
tors are flashing and the horn is on) it can be
turned off by unlocking the car using the
button.
Activating the car alarm The car alarm cannot be activated if the
driver’s door is open or if the ignition switch
is in ON position.
If one of the other doors or the trunk or hood
is open or opened and not closed again
during the 10-second delay period, it will be
excluded from the alarm function.
If it is then closed, a new delay period of ten
seconds will start, and the door (or trunk or
hood) will once again be secured by the
alarm system.
As usual, the LED will be on continuously
during the new delay period and will start to
flash once every other second after the
10-second period has elapsed.
Electronic starting interlock
(immobilizer) When the key is inserted in the ignition, a
signal is sent to the receiver. If the signal is
verified, the engine can be started.
Each time the key is removed from the igni-
tion, the electronic immobilizer is activated.
This means that the car cannot be started
without the correct key inserted in the igni-
tion and the immobilizer thus deactivated.
If a fault is detected (e.g. in the transmitter)
”Key not accepted.
Contact service.”
will appear on the Saab Information Display
(SID).
In this case, you can still start the car if you
turn the ignition key to ON and press one of
the buttons on the key (providing that the
receiver gets the right signal from the key).
Take the car to an authorized Saab dealer
to have the system checked.
The LED double-flashes when the car is
immobilized.
95_U S _M 07.book Page 51 Friday, June 9, 2006 8:58 AM
ProCarManuals.com
