2007 RAM CHASSIS CAB service schedule

EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed in bold
type in this section (Section 8) must be done at the times
or mileages specified to assure the continued proper
functioning of the emission control system. These, and all
other maintenance services included in this manual,
should be done to provide best vehicle performance and
reliability. More frequent maintenance may be needed for
vehicles in severe operating conditions such as dusty
areas and very short trip driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE: Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations. MAINTENANCE SCHEDULES — 6.7L TURBO
DIESEL
CAUTION!Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
• Check the engine oil level about 15 minutes after a
fully warmed engine is shut off. Checking the oil level
while the vehicle is on level ground will improve the
accuracy of the oil level reading. Add oil only when
the level is at or below the ADD or MIN mark.
• Check the windshield washer solvent and add if
required. When refilling the washer fluid reservoir,474 MAINTENANCE SCHEDULES
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

take some washer fluid and apply it to a cloth or towel
and wipe clean the wiper blades, this will help blade
performance.
Once a Month
• Check tire pressure and look for unusual wear or
damage.
• Inspect the batteries and clean and tighten the termi-
nals as required.
• Check the fluid levels of coolant reservoir, brake
master cylinder, and transmission and transfer case (if
equipped), add as needed.
• Check Filter Minder™. Replace air cleaner filter
element if necessary.
• Check all lights and all other electrical items for correct
operation.
• Drain water from the fuel filter. At Each Oil Change
• Change the engine oil filter.
• Inspect the exhaust system.
• Inspect the brake hoses.
• Inspect the U-Joints ( if equipped) and front suspen-
sion components.
• Check the automatic transmission fluid level.
• Check the manual transmission fluid level.
• Check the coolant level, hoses, and clamps.
• Lubricate outer tie rod ends (4X4) models only.
• Lubricate Front Drive Shaft Fitting ( 4X4).
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts. MAINTENANCE SCHEDULES 475
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 112,500 120,000 127,500 135,000 142,500 150,000
(Kilometers) (181 000) (193 000) (205 000) (217 000) (229 000) (241 000)
[Months] [90] [96] [102] [108] [114] [120]
Change manual transmission fluid. X
Inspect fan hub. X X
Inspect damper. X X
Replace fuel filter element. X X X
Inspect front wheel bearings. X X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Adjust valve lash clearance. X
Replace Crankcase Ventilation Filter (CCV). X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts. *This maintenance is not required if belt was previously
replaced. MAINTENANCE SCHEDULES 483
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

WARNING!You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
MAINTENANCE SCHEDULES – GAS ENGINES
There are two maintenance schedules that show the
required service for your vehicle.
First is Schedule “B” . It is for vehicles that are operated
under one or more of the following conditions that are
listed below and at the beginning of the schedule.
• Day or night temperatures are below 32° F (0° C).
• Stop and go driving. • Extensive engine idling.
• Driving in dusty conditions.
• Short trips of less than 10 miles (16 km).
• More than 50% of your driving is at sustained high
speeds during hot weather, above 90° F (32°C).
• Trailer towing.
• Snowplowing.
• Heavy Loading.
• Taxi, police, or delivery service (commercial service).
• Off-road or desert operation.
• If equipped for and operating with E-85 (ethanol)
fuel.
NOTE: If ANY of these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,484 MAINTENANCE SCHEDULES
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule “B”
Follow schedule “B” if you usually operate your vehicle
under one or more of the following conditions.
• Day or night temperatures are below 32° F (0° C).
• Stop and go driving.
• Extensive engine idling.
• Driving in dusty conditions.
• Short trips of less than 10 miles (16 km).
• More than 50% of your driving is at sustained high
speeds during hot weather, above 90° F (32° C).
• Trailer towing.
• Snowplowing.
• Heavy Loading.
• Taxi, police, or delivery service (commercial service). • Off-road or desert operation.
• If equipped for and operating with E-85 (ethanol)
fuel.
NOTE: If ANY of these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow schedule “B” of the
 Maintenance Schedules  section of this manual.
NOTE: If ANY of these apply to you then flush and
replace your engine coolant every 102,000 miles (170 000
km) or 60 months, whichever comes first and follow
schedule “B” of the  Maintenance Schedules  section of
this manual.
NOTE: If none of these apply to you, then change your
engine oil at every interval shown on schedule  A  of the
 Maintenance Schedules  section of this manual. SCHEDULE “B” 487
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 105,000 108,000 111,000 114,000 117,000 120,000
(Kilometers) (175 000) (180 000) (185 000) (190 000) (195 000) (200 000)
Inspect engine air cleaner filter, replace if
necessary. XX
Replace spark plugs. X
Inspect PCV valve, replace as necessary. X
Inspect auto tension drive belt and replace if
required.* XX
Flush and replace engine coolant if not done
at 102,000 miles (170 000 km). X
*This maintenance is not required if the belt was previ-
ously replaced.
** This applies only if the vehicle is used for frequent
trailer towing, snowplowing, fleet vehicle or commercial
service. Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts. SCHEDULE “B” 497
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

* This maintenance is not required if the belt was
previously replaced.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts. WARNING!You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.502 SCHEDULE “A”
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Lug Nuts ............................. 376
Lumbar Support ........................ 116
Maintenance ........................... 396
Maintenance Free Battery .................. 418
Maintenance Procedures ................... 398
Maintenance Schedule ................. 474,484
Schedule “A” ......................... 498
Schedule “B” ......................... 487
Manual, Service ......................... 508
Manual Transmission .................. 279,438
Fluid Level Check ................... 437,438
Lubricant Selection ..................... 471
Shift Speeds .......................... 280
Map/Reading Lights ..................... 141
Mirrors ................................ 83
Automatic Dimming ..................... 84
Electric Powered ....................... 85
Outside .............................. 84 Rearview ............................. 83
TrailerTowing ...................... 86,354
Modifications/Alterations, Vehicle ............. 8
Mopar Parts ......................... 395,507
Multi-Function Control Lever ............... 125
Navigation Radio ........................ 218
Navigation System ....................... 218
New Vehicle Break-In Period ................ 72
Noise Control
Maintenance .......................... 445
Tampering Prohibited ................... 446
Noise Emission Warranty ............... 445,447
Occupant Restraints ....................... 34
Octane Rating, Gasoline (Fuel) .............. 327
Odometer .......................... 175,179
Trip ............................. 175,179
Off-Pavement Driving (Off-Road) ............ 298 INDEX 523
