In case of an electrical malfunction with the ABS, the ABS warning lamp, VDC OFF indicator lamp and SLIP
indicator lamp will turn on. In case of an electrical malfunction with the EBD system, the BRAKE warning lamp,
ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp will turn on.
The system will revert to one of the following conditions of the Fail-Safe function.
1. For ABS malfunction, only the EBD is operative and the condition of the vehicle is the same condition of
vehicles without ABS/TCS/VDC system.
2. For EBD malfunction, the EBD and ABS become inoperative, and the condition of the vehicle is the same
as the condition of vehicles without ABS/TCS/VDC or EBD system.
VDC/TCS SYSTEM
In case of TCS/VDC system malfunction, the VDC OFF indicator lamp and SLIP indicator lamp are turned on
and the condition of the vehicle is the same as the condition of vehicles without TCS/VDC system. In case of
an electrical malfunction with the TCS/VDC system, the ABS control continues to operate normally without
TCS/VDC control.
DTC No. IndexINFOID:0000000001731342
DTC Items (CONSULT screen terms) Reference
C1101 RR RH SENSOR-1
BRC-30, "
Description"C1102 RR LH SENSOR-1
C1103 FR RH SENSOR-1
C1104 FR LH SENSOR-1
C1105 RR RH SENSOR-2
BRC-33, "
Description"C1106 RR LH SENSOR-2
C1107 FR RH SENSOR-2
C1108 FR LH SENSOR-2
C1109 BATTERY VOLTAGE [ABNORMAL]BRC-36, "
Description"
C1110 CONTROLLER FAILUREBRC-38, "DTC Logic"
C 1111 P U M P M O T O RBRC-39, "Description"
C1113 G-SENSORXX-XX, "*****"
C1115 ABS SENSOR [ABNORMAL SIGNAL]BRC-41, "Description"
C1116 STOP LAMP SWBRC-44, "Description"
C1120 FR LH IN ABS SOLBRC-46, "Description"
C1121 FR LH OUT ABS SOLBRC-49, "Description"
C1122 FR RH IN ABS SOLBRC-46, "Description"
C1123 FR RH OUT ABS SOLBRC-49, "Description"
C1124 RR LH IN ABS SOLBRC-46, "Description"
C1125 RR LH OUT ABS SOLBRC-49, "Description"
C1126 RR RH IN ABS SOLBRC-46, "Description"
C1127 RR RH OUT ABS SOLBRC-49, "Description"
C1130 ENGINE SIGNAL 1
BRC-52, "
Description"
C1131 ENGINE SIGNAL 2
C1132 ENGINE SIGNAL 3
C1133 ENGINE SIGNAL 4
C1136 ENGINE SIGNAL 6
C1140 ACTUATOR RLYBRC-54, "
Description"
C1142 PRESS SEN CIRCUITXX-XX, "*****"
C1143 ST ANG SEN CIRCUIT
XX-XX, "*****"
C1144 ST ANG SEN SIGNAL

ABS
BRC-73
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SYMPTOM DIAGNOSIS
ABS
Symptom TableINFOID:0000000001731343
If ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp turn ON, perform self-diagnosis.
NOTE:
 1: The ABS does not operate when the speed is 10 km/h (6 MPH) or less.
 2: Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed. However, this is normal.
- When shifting gears
- When driving on slippery road
- During cornering at high speed
- When passing over bumps or grooves [at approximately 50 mm (1.97 in) or more]
- When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]Symptom Check item Reference
Excessive ABS function operation fre-
quencyBrake force distribution
BRC-74, "
Diagno-
sis Procedure"Looseness of front and rear axle
Wheel sensor and rotor system
Unexpected pedal reactionBrake pedal stroke
BRC-75, "
Diagno-
sis Procedure"Make sure the braking force is sufficient when the ABS is not operating.
The braking distance is long Check stopping distance when the ABS is not operating.BRC-76, "
Diagno-
sis Procedure"
ABS function does not operate (Note 1) ABS actuator and electric unit (control unit)BRC-77, "Diagno-
sis Procedure"
Pedal vibration or ABS operation sound
occurs (Note 2)Brake pedal
BRC-78, "Diagno-
sis Procedure"ABS actuator and electric unit (control unit)

BRC-78
< SYMPTOM DIAGNOSIS >[ABS]
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
Diagnosis ProcedureINFOID:0000000001731348
CAUTION:
Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly
depressed. However, this is normal.
 When shifting gears
 When driving on slippery road
 During cornering at high speed
 When passing over bumps or grooves [at approximately 50 mm (1.97 in) or more]
 When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]
1.SYMPTOM CHECK 1
Check that there are pedal vibrations when the engine is started.
Do vibrations occur?
YES >> GO TO 2
NO >> Inspect the brake pedal.
2.SYMPTOM CHECK 2
Check that there are ABS operation noises when the engine is started.
Do the operation noises occur?
YES >> GO TO 3
NO >> Perform self -diagnosis. Refer to BRC-25, "
CONSULT-III Function (ABS)".
3.SYMPTOM CHECK 3
Check symptoms when electrical component (headlamps, etc.) switches are operated.
Do symptoms occur?
YES >> Check if there is a radio, antenna, antenna lead wire, or wiring close to the control unit. If there is,
move it farther away.
NO >> Normal

BRC-80
