Bluetooth Telephone System Diagram
Bluetooth Control Unit
When the ignition switch is turned to ACC or ON, the Bluetooth con-
trol unit will power up. During power up, the Bluetooth control unit is
initialized and performs various self checks. Initialization may take
up to 10 seconds. During this time the Bluetooth ON indicator will
flash until initialization is complete. If a phone is present in the vehi-
cle and paired with the Bluetooth control unit, NISSAN Voice Recog-
nition will then become active and the Bluetooth ON indicator will
remain on. Bluetooth telephone functions can be turned off using the
NISSAN Voice Recognition system.
BCM
The BCM supplies power for the Bluetooth ON indicator (view with
glove box removed).
Steering Wheel Audio Control Switches
When buttons on the steering wheel audio control switch are
pushed, the resistance in steering wheel audio control switch circuit
changes depending on which button is pushed. The Bluetooth con-
trol module uses this signal to perform various functions while navi-
gating through the voice recognition system.
The following functions can be performed using the steering wheel
audio control switch:

Initiate Self Diagnosis of the Bluetooth telephone system

Start a voice recognition session

Answer and end telephone calls

Adjust the volume of calls
WKIA5468E
LKIA0771E
LKIA0772E
WKIA5426E

BCM (BODY CONTROL MODULE)
BCS-25
C
D
E
F
G
H
I
J
L
MA
B
BCS
Revision: June 20062007 Versa
Removal and Installation of BCMEKS00IA6
REMOVAL
1. Remove the glove box. Refer to IP-21, "GLOVE BOX ASSEMBLY" .
2. Remove the BCM screws, disconnect the connectors and
remove the BCM.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:

When replacing BCM, it must be configured. Refer to BCS-19, "Configuration" .

When replacing BCM, perform initialization of NATS system and registration of all NATS ignition key IDs.
Refer to BL-212, "
NATS (Nissan Anti-Theft System)" .

When replacing BCM, if new BCM does not come with keyfobs attached, all existing keyfobs must be re-
registered.
WKIA5672E

POWER DOOR LOCK SYSTEM
BL-23
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
POWER DOOR LOCK SYSTEMPFP:24814
Component Parts and Harness Connector LocationEIS0090U
LIIA2593E
1. BCM M18, M19, M20
(view with glove box removed)2. Intelligent Key unit M52
(if equipped)3. Front door key cylinder switch LH
D14
4. Front door switch LH B8, RH B108 5. Front door lock actuator LH D3, RH
D1146. Rear door switch LH B6, RH B116
7. Rear door lock actuator LH D205, RH
D3058. Key switch and ignition knob switch
M73 (with Intelligent Key)9. Key switch and key lock solenoid M27
(without Intelligent key)
10. Main power window and door lock/
unlock switch D7, D8
Power window and door lock/unlock
switch RH D10511. Fuse block (with Intelligent Key)
(view with instrument panel LH
removed)12. Passenger select unlock relay M2
(with Intelligent Key)
13. Back door lock assembly (back door
switch) D405 (view with back door open)

BL-54
REMOTE KEYLESS ENTRY SYSTEM
Revision: June 20062007 Versa
REMOTE KEYLESS ENTRY SYSTEMPFP:28596
Component Parts and Harness Connector LocationEIS00919
LIIA2594E
1. BCM M18, M19, M20
(view with glove box removed)2. Remote keyless entry receiver M23 3. Horn relay H-1
(front of battery)
4. IPDM E/R E46, E48 5. Front door switch LH B8, RH B108 6. Rear door switch LH B6, RH B116
7. Back door lock assembly (back door
switch) D405 (with back door open)8. Key switch and key lock solenoid
M279. Horn (low) E18, E20
10. Horn (high) E21, E22

REMOTE KEYLESS ENTRY SYSTEM
BL-79
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
Removal and Installation of Remote Keyless Entry ReceiverEIS0091U
REMOVAL
1. Remove glove box assembly. Refer to IP-11, "Removal and Installation" .
2. Disconnect remote keyless entry receiver connector, remove
screw and remote keyless entry receiver.
INSTALLATION
Installation is in the reverse order of removal.
PIIB6541E

INTELLIGENT KEY SYSTEM
BL-81
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
1. Horn (Low) E18, E20
(view with front fascia removed)2. Horn (High) E21, E22 3. Horn relay H-1
4. Instrument panel antenna M10
(view with glove box removed)5. BCM M18, M19, M20 6. Intelligent Key Unit M52
7. Combination meter M24 8. Intelligent key "KEY" warning indica-
tor9a.
9b.Intelligent key warning indicator (CVT)
Intelligent key warning indicator (M/T)
10. Stop lamp switch E13 11. Steering lock solenoid M6
(bottom view of steering column)12. Key switch and ignition knob switch
M73
13. CVT device (park position switch) M38 14. Intelligent key warning buzzer D6
(view with front door finisher LH
removed)15. Front outside antenna LH D10, RH
D106
16. Front door request switch LH D5, RH
D10317. Front door lock actuator LH (door
unlock sensor) D318. Front door switch LH B8, RH B108
19. Rear door switch LH B6, RH B116 20. Front console antenna B3
(view with front console removed)21. Rear floor antenna B12
(behind rear seat)
22. Back door request switch D406 23. Back door lock assembly (back door
switch) D405 (with back door open)24. Rear bumper antenna B2
(view with rear fascia removed)
LIIA2592E

INTELLIGENT KEY SYSTEM
BL-85
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
List of Operation Related Parts
Parts marked with × are the parts related to operation.
KEY REMINDER FUNCTION
Key reminder functions have the following 2 functions.
CAUTION:

The above function operates when the Intelligent Key is inside the vehicle. However, there may be
times when the Intelligent Key cannot be detected, and this function will not operate when the
Intelligent Key is on the instrument panel, rear parcel shelf or in the glove box. Also, this system
sometimes does not operate if the Intelligent Key is in the door pocket of an open door.
Door lock open function
Intelligent Key
Key switch
Ignition knob switch
Door switch
Back door lock assembly (back door switch)
Request switch (driver, passenger, back)
Door lock actuator
Inside key antenna
Outside key antenna
Intelligent Key warning buzzer (driver door)
Intelligent Key unit
CAN communication system
BCM
Hazard warning lamp
Door lock/unlock function by request switch× ×××××× ×××
Door lock/unlock function by mechanical key××
Hazard and buzzer reminder function×××××
Auto door lock function×××× × ×××
Key reminder function Operation condition Operation
Door is open to closeRight after all doors are closed under the following conditions.

Intelligent Key is inside the vehicle

Any door is opened

All doors are locked by door lock and unlock switch or door
lock knob

All doors unlock operation

Sound Intelligent Key warn-
ing buzzer for 3 seconds

BL-160
INTELLIGENT KEY SYSTEM
Revision: June 20062007 Versa
Removal and Installation of Intelligent Key UnitEIS0092V
REMOVAL
1. Remove glove box assembly. Refer to IP-11, "Removal and Installation" .
2. Disconnect Intelligent Key unit connector, remove screw and
Intelligent Key unit.
INSTALLATION
Installation is in the reverse order of removal.
PIIB6534E
