Dismantling the High Voltage System
Dismantling of the Altima Hybrid may be performed like conventional Nissan vehicles, except as noted in these
guidelines.
Service Disconnect
1. Immobilize the vehicle
a. Move the shift lever to the P (Park) position.
b. Shut the vehicle OFF by pressing the push-button
ignition switch.
c. Chock the wheels.
d. Set the parking brake.
4. Open the trunk using one of the following methods:
• Intelligent Key button:
Push and hold the trunk release button for longer than
0.5 second to open the trunk.
NOTE:
The trunk release button on the Intelligent Key will not
operate when the ignition switch is in the ON position or
when the trunk cancel switch (located in the glove box) i
in the OFF position.
s
• Trunk release switch:
The trunk switch is located on the left side of the
instrument panel. To open the trunk, push the switch
downward.
- 16 -
