SB-4
SEAT BELTS
Revision: 2006 November2007 350Z
SEAT BELTSPFP:86884
System DescriptionNHS00004
SEAT BELT WARNING CHIME
With ignition switch turned ON and seat belt unfastened (seat belt switch ON), warning chime will sound
for approximately 6 seconds.
If warning chime does not sound. Refer to DI-88, "Seat Belt Buckle Switch (Driver Side) Signal Inspection"
.
SEAT BELT WARNING LAMP
Fasten driver's seat belt.
The seat belt warning lamp should go out.
If the seat belt warning lamp does not go out. Refer to DI-58, "Wiring Diagram — WARN —" .
Removal and Installation of Seat Belt (Coupe) NHS00005
CAUTION:
Before servicing SRS, turn the ignition switch OFF, disconnect both battery cables and wait at least 3
minutes.
REMOVAL OF SEAT BELT RETRACTOR
1. Remove the shoulder anchor cover on the seat belt anchor.
2. Remove the anchor bolt.
3. Slide up outer anchor cover, and remove the anchor bolt.
4. Remove the rear side finisher and rear pillar finisher. Refer to EI-35, "
Removal and Installation (for Coupe
Models)" .
5. Remove the center console. Refer to IP-10, "
Component Parts Drawing" .
6. Remove the luggage floor finisher lower. Refer to EI-39, "
Removal and Installation (for Coupe Models)" .
7. Remove the woofer and woofer amp. (BOSE system) bracket mounting bolts. Refer to AV- 4 9 , "
Removal
and Installation of Woofer and Woofer Amp. (BOSE System)" .
8. Remove the rear floor box. Refer to EI-39, "
Removal and Installation (for Coupe Models)" .
PHIA0530E
