RSU-2
PRECAUTIONS
Revision: 2006 November2007 350Z
PRECAUTIONSPFP:00001
CautionsNES0000K
When installing rubber bushings, final tightening must be carried out under unladen conditions with tires
on ground. Oil will shorten the life of rubber bushings. Be sure to wipe off any spilled oil.
Unladen conditions mean that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and
mats are in designated positions.
After servicing suspension parts, be sure to check wheel alignment.
Caulking nuts are not reusable. Always use new ones when installing. Since new caulking nuts are pre-
oiled, tighten as they are.
RSU-18
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 November2007 350Z
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Wheel Alignment (Unladen*)NES00010
*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
Ball JointNES00011
Wheelarch Height (Unladen*)NES00012
*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.Camber
Degree minute (Decimal degree)Minimum –2° 05′ (–2.08°)
Nominal –1° 35′ (–1.58°)
Maximum –1° 05′ (–1.08°)
Total toe-inDistanceMinimum 1.1 mm (0.043 in)
Nominal 1.9 mm (0.075 in)
Maximum 2.7 mm (0.106 in)
Angle (left wheel or right wheel)
Degree minute (Decimal degree)Minimum 0° 02′ 54″ (0.05°)
Nominal 0° 04′ 54″ (0.08°)
Maximum 0° 06′ 54″ (0.12°)
Axial end play0 mm (0 in)
Swing torque 0.5 - 3.4 N·m (0.06 - 0.34 kg-m, 5 - 30 in-lb)
Measurement on spring balance (cotter pinhole position) 8.06 - 54.8 N (0.83 - 5.5 kg, 1.81 - 12.32 lb)
Rotating torque 0.5 - 3.4 N·m (0.06 - 0.34 kg-m, 5 - 30 in-lb)
Applied model225/45R18 (Front)
245/45R18 (Rear)245/40R18 (Front)
265/35R19 (Rear)
Coupe Roadster Coupe
Front (Hf) 683 mm (26.89 in) 683 mm (26.89 in)
Rear (Hr) 706 mm (27.80 in) 705 mm (27.76 in) 703 mm (27.68 in)
SFA818A
