SERVICE DATA AND SPECIFICATIONS (SDS)
RFD-59
C
E
F
G
H
I
J
K
L
MA
B
RFD
Revision: 2006 November2007 350Z
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsNDS0000L
Inspection and AdjustmentNDS0000M
DRIVE GEAR RUNOUT
DIFFERENTIAL SIDE GEAR CLEARANCE
PRELOAD TORQUE
BACKLASH
COMPANION FLANGE RUNOUT
Applied modelVQ35DE
M/T A/T
Final drive model R200 R200V (With LSD)
Gear ratio3.538 3.357
Number of teeth (Drive gear/Drive pinion) 46/13 47/14
Oil capacity (Approx.)
(US pt, lmp pt)1.4 (3, 2-1/2)
Number of pinion gears 2 4
Drive pinion adjustment spacer type Collapsible
Item Runout limit
Drive gear back face 0.05 mm (0.0020 in) or less
ItemSpecification
R200 R200V (With LSD)
Side gear backlash
(Clearance between side gear and differential case)0.2 mm (0.008 in) or less
(Each gear should rotate smoothly
without excessive resistance during
differential motion.)0.15 mm (0.0059 in) or less
(Each gear should rotate smoothly
without excessive resistance during
differential motion.)
Item Specification
Pinion bearing (P
1 ) 2.65 – 3.23 N·m (0.27 – 0.32 kg-m, 24 – 28 in-lb)
Side bearing (P
2 ) 0.20 – 0.52 N·m(0.02 – 0.05 kg-m, 2 – 4 in-lb)
Side bearing to pinion bearing (Total preload)
(Total preload = P
1 + P2 )2.85 – 3.75 N·m(0.29 – 0.38 kg-m, 26 – 33 in-lb)
Item Specification
Drive gear to drive pinion gear 0.10 – 0.15 mm (0.0039 – 0.0059 in)
Item Runout limit
Companion flange face 0.08 mm (0.0031 in) or less
Inner side of the companion flange 0.08 mm (0.0031 in) or less
