7. Remove combination switch & spiral cable from steering column
assembly. Refer to SRS-42, "
Removal and Installation" .
8. Disconnect the following connector from steering column
assembly.
Steering lock harness connector
Ignition switch harness connector
Key switch harness connector
9. Remove control unit with VDC/TCS/ABS control unit. Refer to
BRC-129, "
VDC/TCS/ABS CONTROL UNIT" .
10. Disconnect brake switch harness connector.
11. Remove steering column shaft from lower shaft in the following
procedure.
a. Remove lock nut from yoke.
b. Turn steering wheel to the right to appear the head of bolt.
c. Remove the fixed part of collar for bolt to the outside of its head,
remove bolt.
d. Remove the set lib of steering column assembly side from yoke,
push it equal to the thick part of yoke.
NOTE:
Because collar is set in lower shaft, if the set lib is pushed
(action), joint center will be lifted in the opposite direction (reac-
tion), and then the set lib will be in squeezed to the thick part of
yoke.
SGIA0368E
SGIA0724E
SGIA0353E
SGIA0354E
