2007 NISSAN 350Z tires

WHEELS AND TIRES
Road wheelModel Type Position SizeOffset
in (mm)
Coupe AluminumFront 18 x 8JJ 1.18 (30)
Rear 18 x 8-1/2JJ 1.30 (33)
Front 18 x 9JJ* 1.18 (30)
Rear 19 x 10JJ* 1.18 (30)
Roadster AluminumFront 18 x 8JJ 1.18 (30)
Rear 18 x 8-1/2JJ 1.30 (33)TireModel Type Position Size Pressure (COLD)
CoupeConventionalFront 225/45R18 91W 240 kPa (35 psi)
Rear 245/45R18 96W 240 kPa (35 psi)
Front 245/40R18 93W* 240 kPa (35 psi)
Rear 265/35R19 94W* 240 kPa (35 psi)
Spare — T145/80D17 107M 420 kPa (60 psi)
Road-
sterConventionalFront 225/45R18 91W 240 kPa (35 psi)
Rear 245/45R18 96W 240 kPa (35 psi)
Spare — T145/80D17 107M 420 kPa (60 psi)
*: For option
DIMENSIONS AND WEIGHTS
Vehicle body Coupe Roadster
Overall length in (mm) 169.8 (4,314) 169.8 (4,314)
Overall width in (mm) 71.5 (1,815) 71.5 (1,815)
Overall height in (mm) 52.1 (1,323) 52.5 (1,333)
Front tread in (mm) 60.5 (1,536) 60.5 (1,536)
Rear tread in (mm)60.6 (1,540)*1
60.9 (1,546)*260.6 (1,540)
Wheelbase in (mm) 104.3 (2,650) 104.3 (2,650)
Gross vehicle weight rating
(GVWR)lb(kg)
See the F.M.V.S.S. or C.M.V.S.S. cer-
tification label on the driver’s side
lock pillar. Gross axle weight rating
(GAWR)
Front lb(kg)
Rear lb(kg)
*1: For model with 245/45R 18 tires
*2: For model with 265/35R 19 tires
9-8
Technical and consumer information


06.10.24/Z33-D/V5.0


Before driving a loaded vehicle, confirm
that you do not exceed the Gross Vehicle
Weight Rating (GVWR) or the Gross
Axle Weight Rating (GAWR) for your
vehicle. See “Measurement of Weights”
later in this section.
Also check tires for proper inflation pres-
sures. See the Tire and Loading Informa-
tion label.LOADING TIPS
The GVW must not exceed GVWR or
GAWR as specified on the
F.M.V.S.S./C.M.V.S.S. certification la-
bel.

Do not load the front and rear axle to
the GAWR. Doing so will exceed the
GVWR.
WARNING

Properly secure all cargo with
ropes or straps to help prevent
it from sliding or shifting. Donot place cargo higher than the
seatbacks. In a sudden stop or
collision, unsecured cargo
could cause personal injury.

Do not load your vehicle any
heavier than the GVWR or the
maximum front and rear
GAWRs. If you do, parts of your
vehicle can break, tire damage
could occur, or it can change
the way your vehicle handles.
This could result in loss of con-
trol and cause personal injury.

Overloading not only could
shorten the life of your vehicle
and the tire, but can also cause
unsafe vehicle handling and
long braking distances. This
may cause a premature tire fail-
ure, which could result in a se-
rious accident and personal in-
jury. Failures caused by over
loading are not covered by thevehicle’s warranty.
MEASUREMENT OF WEIGHTSSecure loose items to prevent weight
shifts that could affect the balance of
your vehicle. When the vehicle is loaded,
drive to a scale and weigh the front and
the rear wheels separately to determine
axle loads. Individual axle loads should
not exceed either of the gross axle weight
ratings (GAWR). The total of the axle
loads should not exceed the gross ve-
hicle weight rating (GVWR). These rat-
ings are given on the vehicle certification
label. If weight ratings are exceeded,
move or remove items to bring all weights
below the ratings.
9-16
Technical and consumer information


06.10.24/Z33-D/V5.0


no more than 1/16″smaller than the hole in
the ball mount.

The threaded shank of the hitch ball must be
long enough to be properly secured to the
ball mount. There should be at least 2 threads
showing beyond the lock washer and nut.
Class I hitchClass I trailer hitch equipment (receiver, ball
mount and hitch ball) can be used to tow trailers
of a maximum weight of 2,000 lb(909 kg).
You may add Class I trailer hitch equipment to
the vehicle that has a 2,000 lb(909 kg) maxi-
mum weight rating, but your vehicle is only
capable of towing the maximum trailer weights
shown in the Towing Load/Specification Chart
earlier in this section.
CAUTION

Do not use axle-mounted hitches.

The hitch should not be attached to
or affect the operation of the impact-
absorbing bumper.

Do not modify the vehicle exhaust
system, brake system, etc. to install atrailer hitch.

To reduce the possibility of addi-
tional damage if a vehicle is struck
from the rear, where practical, re-
move the hitch and/or receiver when
not in use.

After the hitch is removed, seal the
bolt holes to prevent exhaust fumes,
water or dust from entering the pas-
senger compartment.

Regularly check that all trailer hitch
mounting bolts are securely mounted.Tire pressures
When towing a trailer, inflate the ve-
hicle tires to the recommended cold
tire pressure indicated on the Tire and
Loading Information label.

Trailer tire condition, size, load rating
and proper inflation pressure should
be in accordance with the trailer and
tire manufacturers’ specifications.
Safety chainsAlways use a suitable chain between a vehicle
and the trailer. The safety chain should be
crossed and should be attached to the hitch, not
to the vehicle bumper or axle. Be sure to leave
enough slack in the chain to permit turning
corners.Trailer lights
CAUTION
When splicing into the vehicle electrical
system, a commercially available
power-type module/converter must be
used to provide power for all trailer
lighting. This unit uses the vehicle bat-
tery as a direct power source for all
trailer lights while using the vehicle tail
light, stoplight and turn signal circuits
as a signal source. The module/
converter must draw no more than 15
milliamps from the stop and tail lamp
circuits. Using a module/converter that
exceeds these power requirements may
damage the vehicle’s electrical system.
See a reputable trailer dealer to obtainTechnical and consumer information
9-19


06.10.24/Z33-D/V5.0


AUTOMATIC TRANSMISSIONTo tow a vehicle equipped with an automatic
transmission, an appropriate vehicle dollyMUST
be placed under the towed vehicle’s drive
wheels.Alwaysfollow the dolly manufacturer’s
recommendations when using their product.MANUAL TRANSMISSION
Always tow with the manual transmission in
Neutral.

After towing 500 miles, start and idle the
engine with the transmission in Neutral for
two minutes. Failure to idle the engine after
every 500 miles of towing may cause damage
to internal transmission parts.DOT (Department Of Transportation) Quality
Grades: All passenger car tires must conform to
federal safety requirements in addition to these
grades.
Quality grades can be found where applicable
on the tire sidewall between tread shoulder and
maximum section width. For example:
Treadwear 200 Traction AA Temperature A
TreadwearThe treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified gov-
ernment test course. For example, a tire graded
150 would wear one and one-half (1 1/2) times
as well on the government course as a tire
graded 100. The relative performance of tires
depends upon the actual conditions of their use,
however, and may depart significantly from the
norm due to variations in driving habits, service
practices and differences in road characteristics
and climate.Traction AA, A, B and CThe traction grades, from highest to lowest, are
AA, A, B, and C. Those grades represent the
tire’s ability to stop on wet pavement as mea-
sured under controlled conditions on specified
government test surfaces of asphalt and con-crete. A tire marked C may have poor traction
performance.
WARNING
The traction grade assigned to this tire
is based on straight-ahead braking trac-
tion tests, and does not include accel-
eration, cornering, hydroplaning, or
peak traction characteristics.Temperature A, B and CThe temperature grades are A (the highest), B,
and C, representing the tire’s resistance to the
generation of heat and its ability to dissipate heat
when tested under controlled conditions on a
specified indoor laboratory test wheel. Sus-
tained high temperature can cause the material
of the tire to degenerate and reduce tire life, and
excessive temperature can lead to sudden tire
failure. The grade C corresponds to a level of
performance which all passenger car tires must
meet under the Federal Motor Safety Standard
No. 109. Grades B and A represent higher levels
of performance on the laboratory test wheel than
the minimum required by law.
UNIFORM TIRE QUALITY
GRADING
9-22
Technical and consumer information


06.10.24/Z33-D/V5.0


Supplemental restraint system............................... 1-28
Precautions on supplemental restraint
system.................................................................... 1-28
Supplemental side and curtain side-impact
air bag system............................................................ 1-39
Switch
Audio control steering wheel switch ............. 4-29
Hazard warning flasher switch ........................ 2-27
Headlight switch ................................................. 2-24
Ignition switch ........................................................ 5-6
Ignition switch automatic transmission
models .......................................................... 5-7, 5-10
Ignition switch manual transmission
models .......................................................... 5-7, 5-13
Power door lock switch....................................... 3-4
Rear window and outside mirror defroster
switch..................................................................... 2-23
Traction control system (TCS) off switch .... 2-29
Turn signal switch .............................................. 2-26
Vehicle dynamic control (VDC) off switch ... 2-29
T
Tachometer.................................................................... 2-5
Temperature display .................................................... 2-9
Temperature gauge, Engine coolant
temperature gauge ...................................................... 2-5
Theft (NISSAN Vehicle Immobilizer System),
Engine start................................................................. 2-19
Three-way catalyst....................................................... 5-3
Tilting passenger’s seat ............................................. 1-7
Tilting steering wheel ............................................... 3-25
Tire pressure, Low tire pressure warning
light ............................................................................... 2-13Tires
Flat tire ..................................................................... 6-2
Low tire pressure warning system .................... 5-3
Spare tire .............................................................. 8-38
Tire and Loading information label ................. 8-31
Tire and Loading Information label................. 9-11
Tire chains ............................................................ 8-36
Tire dressing ........................................................... 7-4
Tire pressure ........................................................ 8-29
Tire pressure monitoring system (TPMS) ...... 5-3,
6-2
Tire rotation .......................................................... 8-36
Types of tires ....................................................... 8-35
Uniform tire quality grading .............................. 9-22
Wheel/tire size ....................................................... 9-8
Wheels and tires ................................................ 8-29
Top tether strap child restraints ............................ 1-24
Top, Soft top .............................................................. 3-13
Towing
Flat towing ............................................................ 9-21
Tow truck towing ................................................ 6-10
Towing a trailer.................................................... 9-17
Towing load/specification chart ...................... 9-17
Towing safety....................................................... 9-18
TPMS, Tire pressure monitoring system................ 5-3
TPMS, Tire pressure warning system..................... 6-2
Traction control system (TCS)............................... 5-23
Traction control system (TCS) off switch ........... 2-29
Trailer towing .............................................................. 9-17
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-42
Transmission
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission ..... 5-7, 5-10Driving with manual transmission .......... 5-7, 5-13
Transmission selector lever lock release ...... 5-13
Transmitter (See remote keyless entry system) ... 3-5
Traveling or registering your vehicle in another
country ............................................................................ 9-9
Trip computer ............................................................... 2-8
Trip odometer ............................................................. 2-10
Trunk
Interior trunk lid release .................................... 3-11
Light ....................................................................... 2-42
Secondary trunk lid release ............................. 3-12
Trunk lid................................................................. 3-10
Turn signal switch ..................................................... 2-26
U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-22
Up-shift indicator (M/T models) ............................ 5-14
Up-shift indicator setting (rpm) (M/T models) ... 2-10
V
Vanity mirror light ...................................................... 2-41
Vehicle
Dimensions and weights ..................................... 9-8
Identification number (VIN) ................................. 9-9
Loading information............................................ 9-13
Recovery (freeing a stuck vehicle) ................. 6-12
Security system ................................................... 2-18
Vehicle dynamic control (VDC) off switch ... 2-29
Vehicle dynamic control (VDC) system ........ 5-23
Ventilated net seats..................................................... 1-6


06.10.24/Z33-D/V5.0

10-6

Ventilators ...................................................................... 4-8
Voice command (See Bluetooth
Hands-Free
Phone System)........................................................... 4-37
Volt meter ...................................................................... 2-8
W
Warning labels, Air bag warning labels .............. 1-42
Warning light
Air bag warning light .............................. 1-43, 2-14
Anti-lock Braking System (ABS) warning
light......................................................................... 2-11
Brake warning light ............................................ 2-12
Door open warning light ................................... 2-12
Low tire pressure warning light ...................... 2-13
Seat belt warning light ...................................... 2-14
Warning lights ............................................................ 2-11
Warning, Hazard warning flasher switch ............ 2-27
Warning, Tire pressure monitoring system
(TPMS) .................................................................. 5-3, 6-2
Warning, Warning/indicator lights and audible
reminders ..................................................................... 2-11
Warranty, Emission control system warranty ..... 9-23
Washer switch
Rear window wiper and washer switch........ 2-22
Windshield wiper and washer switch ........... 2-21
Washing ......................................................................... 7-2
Waxing............................................................................ 7-3
Weights (See dimensions and weights) ............... 9-8
Wheel/tire size.............................................................. 9-8
Wheels and tires ....................................................... 8-29
Cleaning aluminum alloy wheels ....................... 7-4
Window washer fluid ............................................... 8-14Window(s)
Automatic adjusting function ........................... 2-40
Cleaning................................................................... 7-3
Power windows................................................... 2-38
Windshield wiper and washer switch .................. 2-21
Wiper
Rear window wiper and washer switch........ 2-22
Windshield wiper and washer switch ........... 2-21
Wiper blades ....................................................... 8-18
X
Xenon headlights....................................................... 2-24


06.10.24/Z33-D/V5.0

10-7
